1747-OCVGA1

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1747-OCVGA1 is an Open Controller video interface module for VGA/SVGA monitors and supported LCD displays.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1747-OCVGA1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1747-OCVGA1

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1747-OCVGA1
  • Product Family:
    SLC 500
  • Product Type:
    Open Controller VGA/SVGA Video Interface Module
  • Stock:
    1
  • VGA/SVGA Modes:
    640 × 480, 800 × 600, and 1024 × 768 non-interlaced; 1280 × 1024 interlaced
  • LCD Support:
    800 × 600 full screen
  • Video Memory:
    2 MB
  • Included Driver Platforms:
    DOS, Windows 3.x, and Windows 95
  • Video Cable:
    User-supplied VGA-compatible cable
  • Installation Position:
    Open Controller PCI expansion-bus slot, not a standard 1746 I/O slot
  • Backplane Current:
    0.25 A at 5 V DC
  • Operating Temperature:
    0…60°C
  • Storage Temperature:
    -40…85°C
  • Relative Humidity:
    5…95%, noncondensing
  • Weight:
    0.17 kg
  • Tariff Code:
    8538900000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Display Modes Software Installation Application
  • VGA/SVGA interface for Allen-Bradley Open Controller systems
  • Supports documented monitor modes through 1280 × 1024 interlaced
  • Includes 2 MB video memory and legacy DOS/Windows drivers

1747-OCVGA1 supports maintenance of legacy Open Controller workstations where a directly connected display is required for local setup, diagnostics, or operator access.

Successful reuse depends on the original DOS or Windows driver package, the selected monitor mode, and a compatible display-and-cable combination rather than the interface board alone.

Before a swap, archive the driver disk and display configuration, then document the PCI slot, 5 V loading, cable type, and monitor capabilities used by the machine.

Availability, condition, price, and shipping time for 1747-OCVGA1 are confirmed during quotation.

Allen-Bradley 1747-OCVGA1 Manuals, Product Family, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Three common VGA/SVGA resolutions are non-interlaced
  • The 1280 × 1024 mode is documented as interlaced
  • LCD operation is documented at 800 × 600 full screen
  • DOS drivers are included
  • Windows 3.x drivers are included
  • Windows 95 drivers are included
  • The module uses an Open Controller PCI expansion slot
  • The VGA-compatible cable is user supplied
  • Monitor timing and selected resolution must be compatible
  • Local VGA/SVGA operator-interface display on an Open Controller
  • 800 × 600 LCD operator panel in an Open Controller system
  • DOS or legacy Windows diagnostic and visualization display for PC-based control
Description
1747-OCVGA1 supplies the display hardware needed to add a local monitor to an Allen-Bradley Open Controller installation.

Its legacy driver set covers DOS, Windows 3.x, and Windows 95, with documented VGA/SVGA and LCD modes stored in 2 MB of video memory.

Before replacement, preserve the driver disk and display settings, verify the PCI slot and 5 V load, and supply a compatible VGA cable and monitor.
Alternative Names
1747-OCVGA1 1747 OCVGA1 1747OCVGA1 Allen-Bradley 1747-OCVGA1 Allen Bradley 1747-OCVGA1 Rockwell Automation 1747-OCVGA1 Open Controller 1747-OCVGA1
Technical notes
1747-OCVGA1 requires an Open Controller PCI slot, preserved DOS/Windows driver, compatible display mode, user VGA cable, and adequate 5 V power; unsupported timing can produce no image.
