1747-ACN15

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1747-ACN15 is a single-connector ControlNet adapter for 1746 remote I/O in an SLC 500 chassis.
In Stock
Ships by Saturday, October 17
Fast Shipping Available
Get a quick price for 1747-ACN15
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1747-ACN15

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1747-ACN15
  • Product Family:
    SLC 500
  • Product Type:
    ControlNet Adapter Module
  • Stock:
    1
  • Communication Rate:
    5 Mbit/s
  • ControlNet Connectors:
    1 BNC connector for non-redundant media; 1 NAP RJ-45 8-pin shielded connecto
  • Connection Capacity:
    Up to 64 connections per adapter
  • Maximum Data per Connection:
    240 words
  • Module Location:
    Leftmost slot of a 1746 I/O chassis
  • Backplane Current:
    900 mA at 5 V DC
  • Power Dissipation:
    5 W
  • Thermal Dissipation:
    17.06 BTU/hr
  • Operating Temperature:
    0–60 °C
  • Storage Temperature:
    -40–85 °C
  • Relative Humidity:
    5–95%, noncondensing
  • Maximum Operating Altitude:
    2,000 m without derating
  • Weight:
    0.2 kg
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Network Setup Remote I/O Diagnostics Application
  • Single BNC ControlNet connector for the 1747-ACN15 adapter
  • Controls a configured 1746 remote I/O chassis on ControlNet
  • Uses scheduled connections, chassis-image configuration, and network diagnostics

Allen-Bradley 1747-ACN15 is a single-connector ControlNet adapter for 1746 remote I/O in an SLC 500 chassis.

Its ControlNet schedule and configured chassis image determine the data exchanged with the SLC 500 controller.

Before commissioning or replacement, verify node address, ControlNet media and termination, EDS file, firmware, chassis power, and installed I/O modules.

Availability, condition, price, and shipping time for Allen-Bradley 1747-ACN15 are confirmed during quotation.

Allen-Bradley 1747-ACN15 ControlNet Adapter Module Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Set a valid ControlNet node address before connection
  • Install the matching EDS file in the configuration workstation
  • Use the ControlNet scheduling tool after any I/O or connection change
  • Configure the remote chassis and I/O image before operation
  • Keep the slot count within the documented adapter limit
  • Match the actual installed I/O modules to the configured image
  • Check module and network status indicators before changing hardware
  • Investigate media and scheduling faults before altering the I/O image
  • Record node address and configuration information for replacement
  • Distributed SLC 500 I/O control over a ControlNet network
  • Remote chassis I/O acquisition for ControlNet-based control systems
  • Scheduled networked I/O integration where 1746 modules are installed remotely
Description
Allen-Bradley 1747-ACN15 is a single-connector ControlNet adapter for 1746 remote I/O in an SLC 500 chassis.

It exchanges scheduled and unscheduled ControlNet data, supports multicast outputs and diagnostics, and uses the configured chassis image for remote I/O communication.

Before replacement, verify chassis power, node address, ControlNet cable and termination, network schedule, EDS file, firmware, and installed 1746 I/O modules.
Revisions

Revision Part #

Also known as

1747-ACN15 Ser A
1747-ACN15/A,Series A,Rev A
Alternative Names
1747-ACN15 1747 ACN15 1747ACN15 Allen-Bradley 1747-ACN15 Rockwell Automation 1747-ACN15 SLC 500 1747-ACN15
Technical notes
Allen-Bradley 1747-ACN15 uses one ControlNet connector; verify chassis power, node address, NAP connections, ControlNet terminations, and the configured remote I/O image before commissioning.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Does Allen-Bradley 1747-ACN15 require a ControlNet schedule?
Yes. The configured adapter connections must be scheduled after the network and remote I/O configuration are established.
Can Allen-Bradley 1747-ACN15 use the same setup as 1747-ACNR15?
No. The two catalog numbers differ in ControlNet connector arrangement; use the instructions and hardware configuration for the installed model.
Why can Allen-Bradley 1747-ACN15 show a network fault after an I/O change?
Changing the remote I/O image can invalidate the scheduled connection or configuration. Recheck the chassis image, EDS revision, and schedule.
What should be retained when replacing Allen-Bradley 1747-ACN15?
Keep the node address, chassis image, installed I/O list, EDS revision, and ControlNet configuration file with the panel record.
Can Allen-Bradley 1747-ACN15 control an unconfigured remote chassis?
No. The scanner or controller must be configured for the adapter and its actual remote I/O image before dependable data exchange is possible.
What distinguishes a wiring fault from a scheduling issue on Allen-Bradley 1747-ACN15?
A media fault affects network communication, while a scheduling issue normally appears after configuration changes; inspect both before replacing hardware.
Can Allen-Bradley 1747-ACN15 be moved to another chassis without reconfiguration?
Not automatically. Reconfirm the chassis layout and its scheduled connections because the installed I/O image may change.
