1783-ETAP1F

/ 4.9
1001 reviews | Need a Specific Revision?
The Allen-Bradley 1783-ETAP1F Ethernet/IP splitter features a built-in fiber optic interface, enabling reliable high-speed data transmission over long distances and is completely unaffected by electromagnetic interference.
Get a quick price for 1783-ETAP1F
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1783-ETAP1F

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1783-ETAP1F
  • Product Family:
    Stratix Managed Switches
  • Product Type:
    Ethernet Tap
  • Number of Copper Ports:
    2 Ports
  • Number of Fiber Ports:
    1 Port
  • Tap Type:
    Single-Port, Fiber Type
  • Maximum Current Consumption:
    200 mA at 24V DC
  • Power Supply Voltage:
    20.4-27.6V DC (24V DC)
  • Continuous Isolation Voltage:
    30 Volts
  • Maximum Power Consumption:
    4.8 Watts
  • Power Dissipation:
    4.8 Watts
  • Weight:
    0.2 kg
  • Estimated shipping dimensions:
    13.1x3.5x10.4cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Communication & Connectivity Certifications

Features:

  • Bridge Between Industrial Ethernet Networks and Diagnostic Monitoring Equipment
  • Integrates Copper and Fiber Connectivity with Passive Traffic Monitoring
  • Functions Alongside Ethernet/IP Devices and Standard Network Infrastructure
The Allen-Bradley 1783-ETAP1F Ethernet Tap operates as a dedicated network access point in industrial Ethernet systems, providing reliable passive monitoring capabilities for all connected devices. It continuously facilitates non-intrusive data traffic observation between two copper ports (10/100 Mbps) and one single-mode fiber port without introducing latency or packet loss into the active network path. Seamless traffic mirroring is standard with the 1783-ETAP1F, however using its dedicated monitor ports allows network administrators to capture and analyze data streams in real-time without disrupting ongoing industrial communications. The 1783-ETAP1F has been engineered to address the critical need for visibility into Ethernet/IP networks while maintaining complete electrical isolation between network segments.

The 1783-ETAP1F provides essential monitoring functions common to industrial diagnostic applications, and is a critical component of the network visibility path, directly affecting the ability to troubleshoot, analyze, and maintain proper operation of the overall automation system. One 1783-ETAP1F Ethernet Tap is required per monitored network segment depending on the desired diagnostic coverage. The 1783-ETAP1F occupies minimal panel space with its compact open-style design and can be DIN-rail mounted for flexible installation in control cabinets.

For comprehensive network monitoring applications, the 1783-ETAP1F Ethernet Tap requires connection to standard Ethernet/IP devices on the copper ports while the fiber port enables extended distance connectivity to monitoring stations. In addition to standard passive tapping functionality, the 1783-ETAP1F maintains complete electrical isolation between power and network channels as well as between the network channels themselves. The 1783-ETAP1F isolation system operates using basic insulation rated for 30 volts continuous isolation voltage, ensuring safe operation in industrial environments. Using this method, the 1783-ETAP1F continually protects the integrity of both the monitored network and the monitoring equipment. If the system detects electrical anomalies or ground potential differences, the isolation barriers prevent fault propagation while maintaining uninterrupted network operation.

The 1783-ETAP1F Allen-Bradley Ethernet Tap may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Allen-Bradley 1783-ETAP1F Ethernet Tap Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Allen-Bradley 1783-ETAP1F Ethernet Tap Specs

General

  • Manufacturer Allen-Bradley
  • Model 1783-ETAP1F
  • Condition New Original ready stock
  • Product Family 1783-ETAP,1783-ETAPK,1783-ETAP1FK,1783-ETAP2F
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Device-Level Ring (DLR) Integration: Connects standard, single-port Ethernet industrial devices (such as PLCs, drives, and HMIs) directly into a high-resilience DLR network topology.
  • Industrial Media Conversion: Converts local copper signals to fiber-optic signals. This enables long-distance networking across expansive factory floors.
  • Electrical Noise Isolation: Deployed in high-interference environments. The fiber interface provides inherent noise immunity against electromagnetic disturbances.
  • Factory and Process Automation: Used inside control cabinets to interface distributed I/O systems, SCADA platforms, and machine interface networks.
  • Port Configuration: Features two 10/100 Mbps copper RJ45 ports and one 100Base-FX multimode fiber port with an LC connector.
  • Copper Autonegotiation: Automatically negotiates optimal link speeds (10 or 100 Mbps) and duplex configurations (full or half).
  • Fiber Channel Performance: Delivers dedicated 100 Mbps full-duplex operation. It runs over an optical wavelength of 1310 nm.
  • Protocol Support: Optimized for the EtherNet/IP protocol. Includes IEEE 1588 Precision Time Protocol (PTP) for clock synchronization and Quality of Service (QoS) packet prioritization.
  • Flexible Operating Modes: Acts as a network ring component or as a standard 3-port unmanaged switch.
  • Electrical Safety: cULus Listed under Industrial Control Equipment standards (UL 508).
  • Hazardous Locations: Certified for potentially explosive atmospheres. Carries ATEX (Directive 2014/34/EU) and IECEx protection ratings designated as Ex nA IIC T4 Gc for Zone 2 areas.
  • Global Conformity: Bears the CE Mark, UKCA, and China CCC markings for open industrial trade.
  • Electromagnetic Compatibility: Meets C-Tick, KC, and AS/NZS CISPR 11 criteria for industrial emission and noise immunity.
  • Marine Applications: Holds a Product Design Assessment (PDA) certificate from the American Bureau of Shipping (ABS).
Description
The 1783-ETAP1F from Allen-Bradley represents a reliable networking solution functioning as an Ethernet/IP Tap. This unit, the 1783-ETAP1F, is designed to support connectivity in industrial settings, providing two copper ports and one dedicated fiber port. The fiber port on the 1783-ETAP1F is classified as single-port, which enhances flexibility when integrating various network configurations. This 1783-ETAP1F Ethernet Tap is specifically designed for industrial network monitoring and troubleshooting, enabling seamless data traffic analysis without disrupting ongoing network operations.

Current requirements for the 1783-ETAP1F reach a maximum of 200 mA, operating under a power supply voltage of 20.4 to 27.6 volts DC. With a maximum power consumption rating of 4.8 watts, the 1783-ETAP1F ensures minimal energy dissipation of the same value. Continuous isolation voltage for the 1783-ETAP1F measures up to 30 volts, promoting safe electrical operation across the device. The 1783-ETAP1F is engineered to solve the challenge of maintaining network visibility in harsh industrial environments while ensuring electrical safety and system integrity.

Isolation options for the 1783-ETAP1F include separation between power and network channels as well as between the network channels themselves. The 1783-ETAP1F uses a basic insulation type, providing essential safety when integrated into wider network systems. Notably, the 1783-ETAP1F comes in an open-style enclosure, eliminating bulk while allowing easy access for installation and maintenance. The 1783-ETAP1F is ideal for applications requiring real-time network diagnostics, protocol analysis, and secure data tapping in manufacturing plants, process control facilities, and automated production lines where uninterrupted network performance is critical.
Alternative Names
1783-ETAPIF 1783ETAP1F 1783ETAPIF 17B3-ETAP1F 17B3ETAP1F I783-ETAP1F 1783-ETAP 1783-ETAPK 1783-ETAP1FK 1783-ETAP2F
Technical notes
The Allen-Bradley 1783-ETAP1F Ethernet/IP switch that can be used as the main connector or as one of the focal points when it is sharing a connection between different equipment. The connectivity that is provided promotes data transfer.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How to set the I/P address of the 1783-ETAP1F?
I/P address can be set in different ways. It may set using the provided DIP switches, Using RSLogix 5000 or Studio 5000 Logix Designer, RSLinx Classic, DHCP server or using the BOOTP tool.
Does this 1783-ETAP1F Ethernet device include a Fiber port?
Yes, this version of ETAP has One (1) Fiber Optic port.
What is the required Fiber Optic connector for this 1783-ETAP1F?
The Fiber Optic cable must have a duplex LC connector to be able to establish connection with the device.
