    Rockwell Automation lists a discontinuation date of September 30, 2022 and identifies 2711P-B10C22D9P as the engineering replacement.

2711P-K10C4D8

/ 4.9
1001 reviews | Need a Specific Revision?
The Allen-Bradley 2711P-K10C4D8 is a PanelView Plus 6 1000 keypad operator terminal with a 10.4-inch color display, Ethernet, RS-232 and 24 V DC input.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 2711P-K10C4D8
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 2711P-K10C4D8

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    2711P-K10C4D8
  • Product Family:
    Allen Bradley Panelviews
  • Product Type:
    PanelView Plus 6 1000 Keypad Operator Terminal
  • Stock:
    1
  • Display:
    10.4-inch color TFT
  • Resolution:
    640 × 480 pixels
  • Display Area:
    211 × 158 mm
  • Brightness:
    300 cd/m²
  • Operator Input:
    Keypad with 32 function keys
  • Input Voltage:
    18–32 V DC; 24 V DC nominal
  • Power Consumption:
    70 W maximum; 39 W typical
  • Memory:
    512 MB RAM and 512 MB nonvolatile memory
  • Available Nonvolatile Memory:
    Approximately 79 MB
  • Ethernet:
    10/100 Mbps
  • Serial Port:
    RS-232
  • USB:
    Two host ports
  • Storage:
    SD card support
  • Operating System:
    Windows CE 6.0
  • Runtime Software:
    FactoryTalk View Machine Edition 6.0 or later
  • Web Visualization:
    FactoryTalk ViewPoint 1.2 or later
  • Front Protection:
    IP65, NEMA 4X, 12 and 13
  • Dimensions:
    24.8 × 39.9 × 5.5 cm
  • Panel Cutout:
    22.4 × 37.5 cm
  • Weight:
    2.8 kg
  • Tariff Code:
    8537109090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Operator Interface Communications Migration Planning Application
  • 10.4-inch color TFT operator display with physical keypad input
  • FactoryTalk View Machine Edition runtime on Windows CE 6.0
  • Integrated Ethernet, RS-232 and USB connectivity

2711P-K10C4D8 is an Allen-Bradley PanelView Plus 6 1000 keypad operator terminal designed for machine-level visualization and control.

It combines a 640 × 480 color display, 32 function keys, application memory and industrial communication ports for FactoryTalk View ME projects.

Before installation or migration, verify the saved application, firmware, cutout and mounting, DC power, communication addressing, port use and replacement-terminal requirements.

Availability, condition, price, and shipping time for 2711P-K10C4D8 are confirmed during quotation.

Allen-Bradley 2711P-K10C4D8 PanelView Plus 6 1000 Keypad Operator Terminal Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Combines a 10.4-inch color TFT with a physical keypad
  • Provides dedicated function keys for repeatable machine operation
  • Runs FactoryTalk View Machine Edition visualization projects
  • Supports 10/100 Ethernet for controller and plant-network access
  • Provides RS-232 connectivity for compatible serial devices
  • Uses USB and optional communication modules for peripheral expansion
  • Back up the runtime application and communication configuration before removal
  • Compare cutout, mounting and keypad requirements with the replacement terminal
  • Validate firmware and application conversion before production startup
  • Machine-level operator control and status visualization
  • Alarm, recipe and production-data interaction at the equipment panel
  • Ethernet or serial HMI communication with compatible controllers
Description
2711P-K10C4D8 is an Allen-Bradley PanelView Plus 6 1000 operator terminal with keypad input and a 10.4-inch color TFT display.

The terminal runs Windows CE 6.0, supports FactoryTalk View Machine Edition applications, and communicates through 10/100 Ethernet, RS-232 and USB interfaces.

For replacement, confirm the keypad format, DC power, cutout, installed application and firmware, Ethernet or serial addressing, storage media, communication-module requirements and the engineering replacement path.
Alternative Names
2711P-K10C4D8 Allen-Bradley 2711P-K10C4D8 Rockwell Automation 2711P-K10C4D8 2711P K10C4D8 PanelView Plus 6 1000 2711P-K10C4D8
Technical notes
2711P-K10C4D8 migration requires application backup, cutout and DC-power checks, firmware compatibility, network-address verification, peripheral review, network communication testing and validation of the recommended 2711P-B10C22D9P replacement.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What should a buyer verify before choosing Allen-Bradley 2711P-K10C4D8 instead of a touch-screen PanelView terminal?
Confirm that the machine application was designed for the K10 physical-keypad layout and that operators require the same function-key workflow, rather than assuming a touch terminal is operationally interchangeable.
What should be backed up before replacing Allen-Bradley 2711P-K10C4D8?
Back up the FactoryTalk View ME application, communication settings, recipes, logs, security configuration and any removable-media content.
What communication details must be preserved when migrating from Allen-Bradley 2711P-K10C4D8?
Record Ethernet addressing, RS-232 parameters, controller shortcuts, optional communication-module use and connected peripheral settings so the replacement application can reproduce the installed communication path.
What mechanical risks should be checked before fitting a replacement for Allen-Bradley 2711P-K10C4D8?
Compare the existing enclosure cutout, mounting hardware, terminal depth, cable-clearance space and operator-key access with the replacement terminal before modifying the panel.
How should the FactoryTalk View application be prepared for replacement of Allen-Bradley 2711P-K10C4D8?
Preserve the editable project and runtime file, confirm the target firmware and FactoryTalk View ME version, and test converted displays, alarms, recipes, security and controller shortcuts offline before deployment.
What must be evaluated when using 2711P-B10C22D9P as the engineering replacement for Allen-Bradley 2711P-K10C4D8?
Review keypad-versus-touch operation, cutout and mounting changes, power wiring, port availability, application conversion and operator retraining; the replacement designation does not make it a blind drop-in exchange.
Is Allen-Bradley 2711P-K10C4D8 a drop-in replacement for another terminal?
Do not assume so; compare cutout, keypad/touch requirements, firmware, communication ports, runtime application and migration guidance.
