B&R 7DM465.7 is a System 2003 mixed digital I/O module with sixteen 24 VDC sink inputs and sixteen 24 VDC transistor outputs.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 7DM465.7
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 7DM465.7

  • Manufacturer:
    B&R
  • Part Number:
    7DM465.7
  • Product Family:
    B&R System 2003
  • Product Type:
    System 2003 16-Input / 16-Output Digital Mixed Module
  • Stock:
    1
  • Digital inputs:
    16
  • Input voltage:
    24 VDC
  • Input delay:
    1 ms
  • Input circuit:
    Sink
  • Transistor outputs:
    16
  • Output voltage:
    24 VDC
  • Nominal output current:
    0.5 A per output
  • OK threshold:
    Supply voltage greater than 18 V and outputs OK
  • Power consumption:
    Maximum 1.1 W
  • Required terminal blocks:
    2 x TB718 ordered separately
  • Certifications:
    CE, UKCA, cULus HazLoc E180196
  • Tariff Code:
    8538900000
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Digital Inputs Digital Outputs Field Connection Application
  • Provides sixteen 24 VDC sink inputs
  • Provides sixteen 24 VDC transistor outputs
  • Requires two separately ordered TB718 terminal blocks

7DM465.7 is a System 2003 mixed digital I/O module with sixteen 24 VDC sink inputs and sixteen 24 VDC transistor outputs.

It combines sensor acquisition and actuator switching in one local module for compact System 2003 machine-control stations.

Before installation or replacement, verify the compatible CPU capacity, 24 VDC field supply, input commons, output group wiring, 0.5 A load limits, terminal-block selection, diagnostics and project I/O mapping.

Availability, condition, price, and shipping time for 7DM465.7 are confirmed during quotation.

B&R 7DM465.7 Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Provides sixteen 24 VDC sink inputs
  • Uses a documented 1 ms input delay
  • Maps local sensor states into the System 2003 project
  • Provides sixteen 24 VDC transistor outputs
  • Supports 0.5 A nominal current per output
  • Monitors field voltage and output status with the OK indication
  • Requires two separately ordered TB718 terminal blocks
  • Supports approved screw-clamp or cage-clamp TB718 variants
  • Requires commons, output groups and project mapping to match the original installation
  • Compact sensor-and-actuator wiring in System 2003 stations
  • Machine sequencing using 24 VDC inputs and transistor outputs
  • Retrofit replacement where the original 16-input and 16-output terminal map is preserved
Description
B&R 7DM465.7 is a System 2003 mixed digital I/O module with sixteen 24 VDC sink inputs and sixteen 24 VDC transistor outputs.

It combines sensor acquisition and actuator switching in one local module for compact System 2003 machine-control stations.

Before installation or replacement, verify the compatible CPU capacity, 24 VDC field supply, input commons, output group wiring, 0.5 A load limits, terminal-block selection, diagnostics and project I/O mapping.
Alternative Names
7DM465.7 7DM4657 7DM465 7 B&R 7DM465.7 B and R 7DM465.7 B&R System 2003 7DM465.7
Technical notes
B&R 7DM465.7 must be matched by complete material number, compatible System 2003 station or CPU, slot and terminal map, power and field wiring, saved project and connected devices. Back up the configuration and perform a controlled functional test after replacement.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can B&R 7DM465.7 replace separate input and output modules without project changes?
Not automatically. The CPU slot, I/O addresses, terminal map, commons and project declarations must match the mixed-module layout.
Are terminal blocks included with B&R 7DM465.7?
No. B&R states that two TB718 terminal blocks are ordered separately; confirm the approved screw-clamp or cage-clamp versions.
Why can the OK LED on B&R 7DM465.7 stay off when the PLC is running?
Check that the field supply exceeds the documented threshold, the output supply polarity and commons are correct, and no output fault is active.
Can every output of B&R 7DM465.7 switch a 0.5 A inductive load at the same time?
Do not decide from the per-channel rating alone. Verify group loading, ambient derating, inrush and the required external suppression for the actual load set.
How many B&R 7DM465.7 modules can a compatible System 2003 station support?
B&R documents up to two modules with CP430 or EX270; four with CP470, CP770, EX470, EX770, EX477 or EX777; six with CP474 or CP774; and eight with CP476. The installed station must also meet its slot and power requirements.
Why can inputs work while outputs remain inactive on B&R 7DM465.7?
The output field supply or group common may be missing even though the PLC and input circuits are powered; also check output enable logic and faults.
What acceptance tests matter after installing B&R 7DM465.7?
Test all sixteen inputs and outputs individually, measure loaded output voltage, verify fault indications and safe states, then run a controlled machine sequence.
