Bently Nevada 21000-16-10-15-144-03-02
Bently Nevada 21000-16-10-15-144-03-02
Bently Nevada 21000-16-10-15-144-03-02
Bently Nevada 21000-16-10-15-144-03-02
Bently Nevada 21000-16-10-15-144-03-02
Bently Nevada 21000-16-10-15-144-03-02
Ask our team:
  • Phone: +86 181 0690 9650
  • E-Mail sales1@apterpower.com
  • Lifecycle status

    Active / Available from OEM
    Apter Power can quote this housing assembly and provide documentation for sleeve-support planning.

21000-16-10-15-144-03-02

/ 4.9
1001 reviews | Need a Specific Revision?
Bently Nevada 21000-16-10-15-144-03-02 is a 21000 probe housing assembly for a 3300 XL 8 mm probe, with 14.4 in penetration, 1.0 m probe cable, 3/4-14 NPT mounting and a sleeve-support requirement.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for 21000-16-10-15-144-03-02
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 21000-16-10-15-144-03-02

  • Manufacturer:
    Bently Nevada
  • Part Number:
    21000-16-10-15-144-03-02
  • Product Family:
    21000, 24701, and 164818 Proximity Probe Housing A
  • Product Type:
    Probe Housing Assembly
  • Stock:
    1
  • Probe Configuration:
    3300 XL 8 mm probe
  • Probe Cable Option:
    1.0 m
  • Minimum Standoff (C):
    1.5 in (38 mm)
  • Probe Penetration (D):
    14.4 in
  • Fittings Option:
    3/4-14 NPT plug, 3/4-to-1/2 NPT reducer, cable seal grip and grommets
  • Mounting Thread:
    3/4-14 NPT
  • Housing Materials:
    Aluminum body; 304 stainless steel sleeve
  • Weight:
    1.44 kg
  • Estimated shipping dimensions:
    60 x 8.5 x 8.5 cm
  • Tariff Code:
    7307910000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Probe & Cable Fittings & Thread Sleeve Support Product Applications

Features:

  • Probe arrangement: The 16 option specifies a 3300 XL 8 mm probe configuration.
  • Penetration: The 144 option denotes 14.4 in of probe penetration.
  • Mounting: The 02 option selects a 3/4-14 NPT thread.
Bently Nevada 21000-16-10-15-144-03-02 is a 21000 housing assembly for a 3300 XL 8 mm proximity probe.

The complete configuration includes a 1.0 m probe-cable option and the documented fittings package.

Its minimum standoff plus penetration exceeds 12 in, so the series drawing calls for sleeve support near the probe.

Apter Power can quote the Bently Nevada 21000-16-10-15-144-03-02 Probe Housing Assembly and provide sleeve-support documentation for its 14.4 in penetration option.
Bently Nevada 21000-16-10-15-144-03-02 21000 Probe Housing Manuals,Datasheets,Link Important Notice: Accessories, manuals and cables are included only when specified in the stock-item description. Prices are shown in USD.
  • Probe option: Code 16 identifies the 3300 XL 8 mm probe configuration.
  • Cable option: Code 10 selects a 1.0 m probe cable.
  • Penetration: Code 144 selects a 14.4 in D dimension.
  • Fittings code 03: The package lists a 3/4-14 NPT plug and a 3/4-to-1/2 NPT reducer.
  • Cable sealing: The listed cable seal grip includes grommets for the documented cable ranges.
  • Mounting code 02: The housing uses a 3/4-14 NPT mounting thread.
  • Standoff C: The code specifies a minimum 1.5 in (38 mm) standoff.
  • Penetration D: This assembly specifies 14.4 in from the housing geometry.
  • Support threshold: Even at minimum C, C+D is 15.9 in, so Bently Nevada calls for sleeve support near the probe.
  • External probe mounting: The 21000 housing positions a 3300 XL 8 mm probe at a machinery measurement point.
  • Threaded machinery ports: The specified 3/4-14 NPT thread defines the mounting interface.
  • Configured depth: The 14.4 in penetration option serves the corresponding installed probe position.
Description
For a longer probe reach in a 3300 XL 8 mm installation, Bently Nevada 21000-16-10-15-144-03-02 selects 14.4 in of penetration. Even with the minimum 1.5 in standoff, the C and D dimensions total 15.9 in, well beyond the series drawing’s 12 in sleeve-support threshold.

The extended projection of 21000-16-10-15-144-03-02 calls for sleeve support near the probe and sufficient clearance through the mounting path. Its 3/4-14 NPT thread, 1.0 m probe-cable option and listed fittings are separate ordering choices, not substitutes for the required support geometry.

Apter Power can quote 21000-16-10-15-144-03-02 and provide the Bently Nevada housing drawing. Comparing the existing depth, sleeve position and cable outlet helps determine whether this longer assembly is the correct configuration.
Alternative Names
Technical notes
Bently Nevada permits ±0.5 in adjustment of the probe-penetration setting. Even at the low end of that adjustment, the 21000-16-10-15-144-03-02 C-plus-D length remains above 12 in. Probe adjustment therefore cannot remove the series requirement for support near the probe. Apter Power can help review the support position against the long-reach housing drawing.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Our machine needs 14.4 in of probe penetration. Is 21000-16-10-15-144-03-02 the corresponding ordered depth?
Yes. The 144 D option specifies 14.4 in penetration. Its separate 15 C option provides a 1.5 in standoff, so the complete geometry needs room for both.
Does the long sleeve on 21000-16-10-15-144-03-02 need added support near the probe?
The specified C-plus-D length is 15.9 in, above Bently Nevada’s 12 in threshold. The manufacturer calls for sleeve support near the probe to prevent resonance.
We need a separate sleeve matching 21000-16-10-15-144-03-02. What 44382 option follows the published method?
For the documented 3300 XL 8 mm arrangement, the manufacturer’s sleeve formula is 015 + 144 + 045, giving 204 as the 44382 sleeve-length option.
Is the 1.0 m cable option on 21000-16-10-15-144-03-02 the same dimension as its probe penetration?
They are different parts of the order code: 10 selects a 1.0 m probe lead, while 144 selects 14.4 in mechanical penetration. Both need to fit the route and case drawing.
Our existing machine port is 3/4-14 NPT. Does 21000-16-10-15-144-03-02 use that thread at the mounting point?
Yes. The final 02 option specifies 3/4-14 NPT mounting. The reducer in the 03 fitting kit belongs to the cable side, not the machine mounting thread.
Can 21000-16-10-15-144-03-02 be called a CA-rated explosion-proof housing if its cable seal is installed?
The cable seal alone does not establish the CA rating. Bently Nevada identifies only the specified CA housing versions as CSA-rated explosion-proof housings.
