24701-28-05-00-070-04-02

/ 4.9
1001 reviews | Need a Specific Revision?
Bently Nevada 24701-28-05-00-070-04-02 is a stainless-steel probe housing with an approved 3300 XL 8 mm probe, 0.5 m cable, 7.0 in penetration, one plug, and a 3/4-14 NPT mount.
In Stock
Ships by Tuesday, November 3
Fast Shipping Available
Get a quick price for 24701-28-05-00-070-04-02
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 24701-28-05-00-070-04-02

  • Manufacturer:
    Bently Nevada
  • Part Number:
    24701-28-05-00-070-04-02
  • Product Family:
    21000, 24701, and 164818 Proximity Probe Housing A
  • Product Type:
    stainless-steel proximity probe housing assembly
  • Stock:
    1
  • Probe:
    3300 XL 8 mm with approval option
  • Probe cable length:
    0.5 m (20 in)
  • Standoff adapter:
    None
  • Probe penetration:
    7.0 in (178 mm)
  • Fittings:
    One 3/4-14 NPT plug only
  • Mounting thread:
    3/4-14 NPT
  • Body material:
    303 stainless steel
  • Sleeve material:
    304 stainless steel
  • Adjustment range:
    ±0.5 in (13 mm)
  • Probe operating/storage temperature:
    -51°C to +177°C
  • Weight:
    3.968 lbs (1.8 kg)
  • Tariff Code:
    9031809090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Housing Probe Reach Probe & Cable Mounting

Features:

  • Approved 3300 XL 8 mm probe
  • 7.0 in direct-mounted probe penetration
  • 303/304 stainless-steel housing structure
Bently Nevada 24701-28-05-00-070-04-02 protects and positions an externally mounted proximity probe through a rigid stainless-steel body and sleeve.

The 0.5 m probe cable and 7.0 in penetration of 24701-28-05-00-070-04-02 set the signal lead and mechanical reach while the threaded sleeve provides final gap adjustment.

A single plug and 3/4-14 NPT mounting thread complete the direct-mounted arrangement of 24701-28-05-00-070-04-02.

The Bently Nevada 24701-28-05-00-070-04-02 stainless-steel proximity probe housing assembly may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 24701-28-05-00-070-04-02 stainless-steel proximity probe housing assembly Manuals,Datasheets,LinkImportant Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Body, Sleeve, and Probe Access

  • Body: The 303 stainless-steel body protects the external probe assembly.
  • Sleeve: The 304 stainless-steel sleeve provides the threaded path toward the target.
  • Probe access: The design retains external access for final mechanical gap adjustment.
  • Function separation: The housing provides mechanical protection while the probe performs the measurement.

Penetration and Final Adjustment

  • Standoff: Option 00 supplies no standoff adapter.
  • Penetration: The 070 code sets a 7.0 in (178 mm) probe penetration.
  • Adjustment: The sleeve permits ±0.5 in (13 mm) mechanical adjustment.
  • Gap setting: Final probe gap is set after the sleeve is secured to the machine case.

Probe and Lead Arrangement

  • Probe: An approved 3300 XL 8 mm probe is included in the configured assembly.
  • Cable length: The probe carries a 0.5 m (20 in) integral cable.
  • Connection path: The probe lead exits the housing toward the matching extension cable and Proximitor sensor.
  • Identification: The complete suffix must be preserved because probe identity alone does not define the housing geometry.

Thread and Closure Details

  • Mounting thread: The outer sleeve mounts through a 3/4-14 NPT interface.
  • Plug: One 3/4-14 NPT plug closes the specified fitting arrangement.
  • Support: Longer penetration assemblies require suitable external mechanical support where specified.
  • Sealing: The threaded entry and closure require proper sealing for the installed environment.
Description
Bently Nevada 24701-28-05-00-070-04-02 is a stainless-steel proximity probe housing assembly that externally mounts and protects an approved 3300 XL 8 mm probe. Its body and sleeve establish a rigid path from the machine-case thread to the monitored target while keeping the probe accessible for adjustment.

The order code of 24701-28-05-00-070-04-02 supplies a 0.5 m probe cable, no standoff adapter, and a 7.0 in penetration dimension. Because the sleeve position sets the probe reach, the installed gap is adjusted within the stated ±0.5 in mechanical range rather than by changing the penetration suffix.

A single 3/4-14 NPT plug closes the fitting arrangement on 24701-28-05-00-070-04-02, while the outer sleeve uses a 3/4-14 NPT mounting thread. The 303 stainless-steel body and 304 stainless-steel sleeve separate enclosure protection from the probe's own measurement function.
Alternative Names
247012805000700402 24701 28 05 00 070 04 02 24701-28 05-00 070-04 02 Bently Nevada 24701-28-05-00-070-04-02 24701-28-05-00-070-04-02 Probe Housing 247O1-28-O5-OO-O7O-O4-O2 2470I-28-05-00-070-04-02 24701 28-05 00-070 04-02
Technical notes
Direct sleeve mounting allows Bently Nevada 24701-28-05-00-070-04-02 to position an approved 8 mm probe through 7.0 in penetration without a standoff.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What prevents 24701-28-05-00-070-04-02 from being replaced by another 24701 housing with the same probe?
The 24701-28-05-00-070-04-02 suffix also fixes no standoff, 7.0 in penetration, a single plug, and a 3/4-14 NPT mount, so probe identity alone is insufficient.
Where is the probe reach set on 24701-28-05-00-070-04-02?
The 070 suffix establishes 7.0 in penetration for 24701-28-05-00-070-04-02, and the threaded sleeve provides the limited final gap adjustment.
Does 24701-28-05-00-070-04-02 include a standoff adapter?
No. Option 00 on 24701-28-05-00-070-04-02 means the 3/4-14 NPT outer sleeve mounts without a standoff adapter.
Which material boundary matters when 24701-28-05-00-070-04-02 is installed outdoors?
The 24701-28-05-00-070-04-02 uses a 303 stainless-steel body and 304 stainless-steel sleeve; the conduit entry still requires the specified plug and proper sealing.
Is the 1.8 kg figure for 24701-28-05-00-070-04-02 a packed shipping weight?
No. The 1.8 kg value for 24701-28-05-00-070-04-02 is the manufacturer's typical housing mass without fittings, not a packaged shipping weight.
