ABB RF615 3BHT100010R1 is a ten-slot base backplane for Advant Controller 100-series hardware, providing the mechanical slot structure and internal distribution paths for installed modules.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for RF615 3BHT100010R1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for RF615 3BHT100010R1

  • Manufacturer:
    ABB
  • Part Number:
    RF615 3BHT100010R1
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    RF615 Ten-Slot Base Backplane
  • Stock:
    1
  • ABB Product ID:
    3BHT100010R1
  • Type designation:
    RF615
  • Rack capacity:
    10 slots
  • Documented controller family:
    Advant Controller 100 series
  • Supplied assembly:
    Base backplane only
  • Weight:
    3 kg
  • Estimated shipping dimensions:
    47.07x24.57x8.46cm
  • Tariff Code:
    8538909900
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Slot Backplane Power Distribution Chassis Inspection Product Applications

Features:

  • Ten-slot rack base: Provides the documented module positions for the assembled controller chassis.
  • Shared interconnection: Carries internal distribution paths used by multiple plug-in modules.
  • Advant hardware: Supports the established Controller 100-series rack environment.
Backplane condition affects the chassis as a shared system rather than a single channel.

Power distribution, slot sequence, and connector alignment should be documented before the rack is disturbed.

The official ABB scope is the base backplane only unless additional items are stated separately.

Apter Power supports ABB RF615 3BHT100010R1 base-backplane quotations, official documents, and Advant rack review.
ABB RF615 3BHT100010R1 RF615 Ten-Slot Base Backplane Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Ten positions: Keep module order aligned with the rack drawing and controller configuration.
  • Connectors: Inspect every slot for bent pins, contamination, wear, or heat damage.
  • Insertion: Support modules evenly and avoid forcing misaligned card edges.
  • Unused slots: Protect open positions from debris and accidental contact.
  • Chassis feed: Verify the documented supply reaches the backplane under load.
  • Common paths: Review shared voltages and returns when several slots fail together.
  • Grounding: Retain protective-earth and chassis-bonding arrangements.
  • Thermal check: Look for abnormal temperature rise at connectors and distribution points.
  • Mounting: Check flatness, fasteners, support rails, and enclosure clearance.
  • Contamination: Remove dust or residue only with approved ESD-safe methods.
  • Module sequence: Photograph the complete populated rack before any card is removed.
  • Startup: Observe controller boot and slot diagnostics after the rack is assembled.
  • Advant controller racks: Provides the ten-slot base for documented Controller 100 hardware.
  • Control-system service: Maintains an established rack architecture during planned hardware work.
  • Shared-fault diagnosis: Offers a defined inspection point when several installed modules show related symptoms.
Description
Forming the base of an Advant Controller 100-series rack, RF615 3BHT100010R1 is officially catalogued by ABB as a ten-slot backplane. It provides the module positions and internal interconnection structure used by the assembled control chassis.

A backplane fault around RF615 3BHT100010R1 can affect several modules at once, so diagnosis should include chassis supply, slot connectors, distribution paths, mounting alignment, and contamination. Individual modules should be tested separately before the shared base is assigned as the fault source.

Apter Power can support RF615 3BHT100010R1 quotations, ABB documentation, rack inspection guidance, and Advant hardware planning. The page describes the base backplane only; modules, power units, connectors, and accessories are included only when stated in the quotation.
Alternative Names
RF615 3BHT100010R1 RF615 3BHT100010R1 RF 615 RF-615 ABB RF615 ABB 3BHT100010R1 3BHT 100010 R1
Technical notes
For RF615 3BHT100010R1, verify the ten-slot chassis layout, mounting alignment, supply distribution, grounding, backplane connectors, module sequence, and controller documentation together. If several modules show related faults, inspect shared power and backplane paths before condemning individual cards. Use controlled ESD handling and prove every installed slot after service.
