        Bently Nevada 3300/03 3300 system monitor module, showing electronic board layout and connector section
        Bently Nevada 3300/03 3300 system module, machinery monitoring hardware with casing and circuit board details
        Bently Nevada 3300/03 3300 system monitor module, industrial control rack component with front panel details
        Bently Nevada 3300/03 3300 system monitor module, showing electronic board layout and connector section
        Bently Nevada 3300/03 3300 system module, machinery monitoring hardware with casing and circuit board details
        Ask our team:
        • Phone: +86 181 0690 9650
        • E-Mail sales1@apterpower.com

        3300/03

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        The Bently Nevada 3300/03 System Monitor provides precise transducer signal management, alarm handling, and real-time data communication for 3300 monitor racks, supporting advanced machinery protection and automation integration.
        Get a quick price for 3300/03
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 3300/03

        • Manufacturer:
          Bently Nevada
        • Part Number:
          3300/03
        • Product Family:
          3300 System
        • Inputs Power Consumption:
          2 watts; 4.6 watts with interface options.
        • Keyphasor Signal:
          Accepts up to four proximity probe Keyphasor signals.
        • Input impedance:
          10 k Ω.
        • RS422 Communications Impedance:
          4 k Ω.
        • RS422 Communications Distance:
          1200 metres (4000 feet) maximum.
        • Frequency Range:
          60 to 30,000 cpm (rpm).
        • Duty Cycle:
          1% minimum.
        • Amplitude:
          0.5 V peak-to-peak minimum.
        • Accuracy:
          12-bit dynamic data is maintained with no losses. While DDI can support up to 24-bits of resolution on static data, the actual resolution is a function of the monitor type for each channel.
        • Operating Temperature:
          0°C to +65°C (+32°F to +150°F).
        • Storage Temperature:
          -40°C to +85°C (-40°F to +185°F).
        • Relative Humidity:
          To 95%, noncondensing.
        • Weight:
          0.94 kg
        • Estimated shipping dimensions:
          5x31.8x20.3cm
        • Tariff Code:
          6115291000
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen, Fujian, China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Specifications Performance Application Scenarios Connectivity

        Features:

        • Centralized System Monitor Provides Alarm Management, Keyphasor Signal Processing, And Data Communication For 3300 Rack Systems
        • Supports Up To Four Proximity Probe Keyphasor Signals With 12-Bit Dynamic Data Accuracy And Optional 24-Bit Static Resolution
        • Includes RS422 Communication Ports, SDI And DDI Interfaces, And Operates Reliably In Harsh Industrial Environments
        The Bently Nevada 3300/03 System Monitor is engineered to manage and coordinate critical monitoring functions within a 3300 rack system. It consolidates essential tasks such as alarm setpoint adjustment, Keyphasor® signal power and distribution, and alarm acknowledgement, ensuring continuous machinery protection across multiple channels. By handling these key operations, the Bently Nevada 3300/03 System Monitor reduces the complexity of rack-level monitoring and provides reliable performance in demanding industrial applications.

        Designed for high compatibility, the Bently Nevada 3300/03 accepts up to four proximity probe Keyphasor signals, featuring 10 kΩ input impedance and supporting RS422 communication distances up to 1200 metres (4000 feet). It maintains 12-bit dynamic data accuracy, with optional support for 24-bit static resolution, depending on monitor channel configuration. The monitor operates across a frequency range of 60 to 30,000 cpm, with a minimum duty cycle of 1% and amplitude of 0.5 V peak-to-peak, enabling precise measurement and event detection.

        Connectivity is a major advantage of the Bently Nevada 3300/03 System Monitor. It provides STATIC and DYNAMIC data ports for external communication processors, and optional Serial Data Interface (SDI) and Dynamic Data Interface (DDI) for direct connection to process computers, DCS, PLCs, and Bently Nevada machinery management software. Built for industrial reliability, the module supports operating temperatures from 0°C to +65°C, storage from -40°C to +85°C, and up to 95% noncondensing humidity, making the Bently Nevada 3300/03 System Monitor a robust solution for continuous machine monitoring and protection.

        The 3300/03 Bently Nevada System Monitor may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

        Bently Nevada 3300/03 System Monitor Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        Bently Nevada 3300/03 System Monitor Specs

        General

        • Manufacturer GE / Bently Nevada
        • Model 3300/03
        • Condition New Original ready stock
        • Product Family 3300/03-04-01,3300/03-04-00,3300/03-03-01
        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        • High-Precision Signal Processing: At 25°C, the typical dynamic signal accuracy is ±0.3% (full scale), and the typical phase accuracy is ±0.2°.
        • System-Level Protection: Provides power-up inhibition, disabling alarms for the first 2 seconds after power-on or voltage instability, effectively preventing false triggering.
        • Status Monitoring Efficiency: The front panel features 7 internal voltage indicator lights (e.g., +VRH, -VT) and a green SUPPLIES OK LED, facilitating quick diagnosis of the frame's power status by maintenance personnel.
        • Alarm Management: Supports a "Trip Multiply" function, temporarily increasing alarm thresholds by a preset ratio under special operating conditions such as machine startup, avoiding unnecessary downtime.
        • Rotating Machinery Protection: Provides isolated power, terminal connections, and signal conditioning for up to 4 proximity probe keyphasors, supporting speed monitoring from 60 to 30,000 rpm.
        • Industrial Integrated Monitoring: Suitable for asset status management in fields such as power (steam turbines, generators) and petrochemicals (compressors), enabling vibration and displacement monitoring in conjunction with the 3300 XL series sensors.
        • Legacy System Upgrade: As the core of the SDI/DDI system, it allows older 3300 frames to be connected to modern System 1 machine management software via a serial interface.
        • Serial Data Interface (SDI/DDI): RS232: Up to 19.2 kbaud baud, maximum transmission distance 30 meters, suitable for short-distance connection to the main controller; RS422: Up to 38.4 kbaud baud (DDI mode), maximum transmission distance up to 1200 meters, supports daisy-chaining of multiple frames.
        • External Control Interface: Backplane terminals provide dry contact connections for "Rack Inhibit," "Alarm Reset," and "Multiplier Trigger."
        • Signal output: The front panel provides 4 coaxial cable interfaces (BNC) to output buffered phase signals, which are convenient for portable instruments in the field (such as vibration analyzers) to directly acquire the original waveform.
        View as PDF
        Description
        The Bently Nevada 3300/03 System Monitor is designed to centralize and manage key monitoring functions in a 3300 rack system, ensuring reliable machinery protection and data distribution. This module addresses critical monitoring challenges, including alarm management, Keyphasor® signal conditioning, and communication of transducer data to external control and automation systems. With support for up to four Keyphasor signals, the Bently Nevada 3300/03 System Monitor ensures accurate phase reference and event detection for vibration and machinery analysis.

        Power-efficient and versatile, the Bently Nevada 3300/03 consumes only 2 watts, or 4.6 watts when interface options are included, allowing integration without adding significant energy load. The module features 10 kΩ input impedance for Keyphasor signals and 4 kΩ RS422 communications impedance, supporting signal transmission distances up to 1200 metres (4000 feet). The monitor accommodates frequency ranges from 60 to 30,000 cpm (rpm), a 1% minimum duty cycle, and a 0.5 V peak-to-peak minimum amplitude, maintaining 12-bit dynamic data resolution across all channels with the ability to support up to 24-bit static resolution, depending on channel type.

        Connectivity is a core strength of the Bently Nevada 3300/03 System Monitor. It provides STATIC and DYNAMIC data ports for integration with external communication processors, as well as optional Serial Data Interface (SDI) and Dynamic Data Interface (DDI) for direct connection to process computers, DCS, PLCs, and compatible Bently Nevada machinery management software. This flexibility can eliminate the need for an additional communications processor depending on the data requirements.

        Built to withstand demanding industrial conditions, the Bently Nevada 3300/03 operates reliably between 0°C and +65°C, with storage capability from -40°C to +85°C, and tolerates up to 95% relative humidity, noncondensing. By combining precise signal management, versatile data communication, and rugged industrial design, the Bently Nevada 3300/03 System Monitor delivers reliable performance, making it a superior choice over competing monitor modules for continuous machinery protection.
        Alternative Names
        3300/03-01-00 3300/03-01-01 3300/03-01-02 3300/03-02-00 3300/03-02-01
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        Does Bently Nevada 3300/03 System Monitor include a warranty?
        The Bently Nevada 3300/03 comes with a 1-year Apter Power warranty covering defects and operational performance.
        What is the input power consumption of the 3300/03 System Monitor?
        It consumes 2 watts, increasing to 4.6 watts if interface options are installed.
        How many Keyphasor signals can the monitor accept?
        The Bently Nevada 3300/03 can accept up to four proximity probe Keyphasor signals simultaneously.
        How accurate is the data resolution?
        Dynamic data maintains 12-bit resolution with no loss, and static data can support up to 24-bit resolution, depending on monitor channel type.
