330709-000-120-10-02-00

/ 4.9
1001 reviews | Need a Specific Revision?
The Bently Nevada 330709-000-120-10-02-00 3300 XL 11 mm Probe delivers accurate non-contact vibration and displacement measurement with M16 x 1.5 threading and robust AISI 304 stainless steel construction.
Get a quick price for 330709-000-120-10-02-00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330709-000-120-10-02-00

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330709-000-120-10-02-00
  • Product Family:
    3300 XL 11mm Proximity Transducer System
  • Minimum unthreaded length:
    0 mm
  • Overall Case Length Option:
    120 mm
  • Total Length Option:
    1.0 meter (3.3 feet)
  • Connector and Cable-Type Option:
    Miniature coaxial ClickLoc connector, standard cable
  • Agency Approval Option:
    Not required
  • Probe dc Resistance:
    5.9 ± 0.5 ohms
  • Probe Tip Material:
    Polyphenylene sulfide (PPS).
  • Probe Case Material:
    AISI 304 stainless steel (SST).
  • Probe Cable Specification:
    75 Ω triaxial, fluoroethylene propylene
  • Weight:
    0.2 kg
  • Estimated shipping dimensions:
    2.6x2.3x119cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
Description
The Bently Nevada 330709-000-120-10-02-00 3300 XL 11 mm Probe is a precision proximity transducer designed for industrial condition monitoring systems. With a minimum unthreaded length of 0 mm, an overall case length of 120 mm, and a total length of 1.0 meter (3.3 feet), it provides flexible installation options in turbines, compressors, and other critical rotating machinery. Its M16 x 1.5 thread ensures secure mounting in standard applications.

This 3300 XL 11 mm probe features a miniature coaxial ClickLoc connector with standard cable, enabling reliable electrical connections. The probe dc resistance is 5.9 ± 0.5 ohms, while the probe tip material is Polyphenylene sulfide (PPS) and the probe case is made from AISI 304 stainless steel, delivering robust performance under industrial conditions. The 75 Ω triaxial FEP-insulated cable ensures consistent signal transmission for high-precision monitoring.

The 330709-000-120-10-02-00 is part of the Bently Nevada 3300 XL 11 mm Proximitor Sensor System, which replaces older 7200-series 11 mm and 14 mm transducer systems. When upgrading, all components, including probes, extension cables, and sensors, must be replaced with 3300 XL 11 mm components. For use with 3500 Monitoring Systems, an updated configuration software version listing 3300 XL 11 mm as compatible is required, while existing 3300 Monitoring Systems may need modification.

Designed for demanding industrial environments, this 3300 XL 11 mm probe operates reliably across -52°C to +177°C (-62°F to +351°F), providing accurate non-contact measurements of axial position, rod displacement, and phase reference (Keyphasor) signals. Its robust construction and proven design ensure long-term reliability in critical monitoring applications.
Alternative Names
33O7O9-OOO-12O-1O-O2-OO 33070g-000-120-10-02-00 330709-000-I20-I0-02-00 330709-000-1Z0-10-0Z-00 330709000120100200 330709 000 120 10 02 00
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the minimum unthreaded length of the 330709-000-120-10-02-00 probe?
The minimum unthreaded length is 0 mm.
What is the overall case length?
The overall case length is 120 mm.
Where is the 330709-000-120-10-02-00 manufactured?
This 3300 XL 11 mm probe is manufactured by Bently Nevada in the United States.
What is the total length of the 330709-000-120-10-02-00 probe?
The total length is 1.0 meter (3.3 feet).
What is the 330709-000-120-10-02-00 probe dc resistance?
The dc resistance is 5.9 ± 0.5 ohms.
