330730-080-10-05

/ 4.9
1001 reviews | Need a Specific Revision?
The 330730-080-10-05 is an 8.0-meter FluidLoc extension cable with multiple approvals, for 3300 XL 11 mm systems, preventing oil leakage and providing environmental protection.
Get a quick price for 330730-080-10-05
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330730-080-10-05

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330730-080-10-05
  • Product Family:
    3300 XL 11mm Proximity Transducer System
  • Product Type:
    3300 XL 11 mm Extension Cable
  • Cable Length:
    8.0 meters (26.2 feet)
  • Cable Type:
    FluidLoc (fluid-blocking)
  • Agency Approvals:
    Multiple Approvals (CSA, ATEX, IECEx)
  • Sealing Options:
    Connector protectors (recommended); silicone tape (provided)
  • Silicone Tape Limitation:
    Not for turbine oil exposure
  • Key Benefit:
    Solves fluid leakage in lubricated machinery—FluidLoc blocks oil migration, multiple approvals enable global use, 8.0m length provides flexible sensor placement.
  • Weight:
    0.34 kg
  • Estimated shipping dimensions:
    20.4x22.2x3.7cm
  • Tariff Code:
    8544492100
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Communication Safety and Compliance

Features:

  • FluidLoc cable technology prevents oil migration through the cable interior, eliminating field sealing.
  • 8.0-meter length provides flexible placement of the Proximitor sensor away from the measurement point.
  • Multiple hazardous area approvals (CSA, ATEX, IECEx) enable global deployment without region-specific variants.
Oil wicking through cables is a common failure. The 330730-080-10-05 blocks it with an internal barrier. No tape, no compounds—just factory-engineered protection for lubricated machinery. When oil migrates through standard cable interiors, it doesn't just make a mess—it can compromise signal integrity, attract contaminants, and create safety hazards on the plant floor. The 330730-080-10-05's FluidLoc technology creates an impermeable barrier within the cable itself, stopping oil at the source.

At 8.0 meters, this cable reaches remote cabinets and junction boxes. Place the Proximitor sensor where it's convenient, not where the probe forces it. The 330730-080-10-05 simplifies system layout. In large machinery installations, the probe may be mounted in a difficult-to-access location deep within the machine casing, but the Proximitor sensor doesn't have to suffer the same fate. With 8.0 meters of cable, you can route to a nearby junction box, a convenient cabinet, or a central monitoring panel.

CSA for North America, ATEX for Europe, IECEx for international sites. The 330730-080-10-05 moves with your equipment. No region-specific variants, no compliance delays. When your machinery ships worldwide or your facility sources components from multiple regions, stocking different cables for different approval jurisdictions is a logistical nightmare. The 330730-080-10-05 eliminates that problem. One cable, multiple approvals. Install it in a Texas refinery, a German chemical plant, or an offshore platform in the North Sea—the certifications travel with the cable.

The 330730-080-10-05 Bently Nevada 3300 XL 11 mm Extension Cable may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 330730-080-10-05 3300 XL 11 mm Extension Cable Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330730-080-10-05 3300 XL 11 mm Extension Cable Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330730-080-10-05
  • Condition New Original ready stock
  • Product Family 330730-040-10-05,330730-080-00-05,330730-080-01-05
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Large Rotating Machinery Monitoring: Widely used in large fluid power bearing machines such as steam turbines, large generators, and axial flow compressors.
  • Wide Range Displacement Measurement: Due to the wider measurement range provided by the 11mm probe, this cable is commonly used to monitor axial (thrust) displacement or radial vibration of large diameter shafts.
  • Key Phase Reference: Provides the system with speed and phase signals (keyphasor) to aid in diagnosing mechanical faults.
  • Connectivity Technology: Utilizes ClickLoc gold-plated connectors, requiring only manual rotation for locking, no special tools needed, and the gold plating effectively prevents contact corrosion.
  • System Integration: This 8-meter cable must be combined with a 1-meter probe to form a 9-meter total length system, connected to the corresponding 3300 XL 11mm Proximitor sensor to ensure signal sensitivity is accurately maintained at 3.94 V/mm (100 mV/mil).
  • Hazardous Area Certification (Ex): Code 05 indicates that the cable meets Intrinsic Safety and Non-Incendive standards and can be installed in hazardous locations in Zone 0/1 or Class I Div 1.
  • Insulation Sheath: Made of FEP fluoropolymer, providing excellent flame retardancy and chemical resistance.
  • Temperature Range: Operates stably in extreme temperatures from -51°C to +177°C.
  • API 670 Compliance: As part of the 3300 XL series, it fully complies with the American Petroleum Institute's API 670 specifications for mechanical protection systems, ensuring linearity and interoperability of measurements.
Description
The 330730-080-10-05 is an 8.0-meter extension cable designed for the 3300 XL 11 mm Proximity Transducer System. It features FluidLoc cable technology that blocks oil and other liquids from migrating through the cable interior. Multiple agency approvals allow global deployment in hazardous areas without region-specific variants.

FluidLoc technology creates an internal barrier within the 330730-080-10-05, preventing leakage at the machine penetration point. This is essential in lubricated machinery such as turbines, compressors, and gearboxes. The cable also supports connector protectors for additional sealing in humid or moist environments.

The 330730-080-10-05 works with 3300 XL 11 mm probes, which come standard with a locknut featuring pre-drilled safety wire holes. For field installations where cables must run through restrictive conduit, connector protectors can be ordered separately.

This extension cable solves the pain point of fluid leakage in high-temperature, lubricated machinery. The 330730-080-10-05’s FluidLoc construction eliminates the need for field-applied sealing compounds, while its 8.0-meter length provides flexible placement of the Proximitor sensor. Multiple approvals simplify global procurement.
Alternative Names
330730-040-10-05 330730-080-00-05 330730-080-01-05 330730-080-10-00
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the length of the 330730-080-10-05?
8.0 meters (26.2 feet)—sufficient to place the Proximitor sensor in a remote control cabinet.
How does FluidLoc technology prevent leakage?
An internal barrier built into the cable stops oil from traveling through the cable interior—no field sealing required.
Can I use silicone tape instead of connector protectors?
Yes, silicone tape is provided. However, it is not recommended for applications where the connection will be exposed to turbine oil.
What approvals does this cable carry?
Multiple approvals including CSA, ATEX, and IECEx for global hazardous area deployment.
