330854-040-24-CN

/ 4.9
1001 reviews | Need a Specific Revision?
Bently Nevada 330854-040-24-CN is a 3300 XL 25 mm Extension Cable with 4.0 m (13.1 ft) high temperature fluidloc cable, without armor, and country-specific china approval option; verify current markings in the approvals quick reference guide.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 330854-040-24-CN
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330854-040-24-CN

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330854-040-24-CN
  • Product Type:
    3300 XL 25 mm Extension Cable
  • Stock:
    1
  • Component Type:
    3300 XL 25 mm Extension Cable
  • Cable Length:
    4.0 m (13.1 ft)
  • Cable Type:
    High Temperature FluidLoc cable
  • Armor:
    Without armor
  • Agency Approval:
    Country-specific China approval option; verify current markings in the Approvals Quick Reference Guide
  • Cable Material:
    75 ohm PFA-insulated FluidLoc cable
  • Operating Temperature:
    -35 to +200 C (-31 to +392 F)
  • Minimum Bend Radius:
    25.4 mm (1.0 in)
  • Weight:
    0.16 kg
  • Estimated shipping dimensions:
    22.5x1.2x24cm
  • Tariff Code:
    9031809090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Ordering Code System Matching Installation

Product overview:

  • •Function: Connects the 25 mm probe to its matched Proximitor Sensor
  • •Cable configuration: 4.0 m (13.1 ft), high temperature fluidloc cable
  • •Approval option: Country-specific China approval option; verify current markings in the Approvals Quick Reference Guide

Bently Nevada 330854-040-24-CN is configured with 4.0 m (13.1 ft) high temperature fluidloc cable, without armor, and country-specific china approval option; verify current markings in the approvals quick reference guide.

Combine this 4.0 m cable with a 1.0 m probe and 5 m Proximitor Sensor. Protect both ClickLoc connections and verify system matching before commissioning.

Availability is subject to Apter Power's current inventory and sourcing confirmation.

Bently Nevada 330854-040-24-CN Specs

General

Manufacturer Bently Nevada
Model 330854-040-24-CN
Condition New and factory sealed
Product Family 3300 XL 25mm Proximity Transducer System

Ordering code breakdown

  • •Base model: 330854 3300 XL 25 mm extension cable
  • •Cable length: 4.0 m (13.1 ft)
  • •Armor and cable: High Temperature FluidLoc cable
  • •Approval code CN: Country-specific China approval option; verify current markings in the Approvals Quick Reference Guide

System matching guidance

  • •5 m system: Combine this 4.0 m cable with a 1.0 m probe and 5 m Proximitor Sensor
  • •Electrical length: Probe and extension cable lengths must equal the Proximitor Sensor length
  • •Linear range: 12.7 mm (500 mils)
  • •Scale factor: 0.787 V/mm (20 mV/mil)
  • •Reference target: AISI 4140 steel

Installation checks

  • •Temperature: -35 to +200 C (-31 to +392 F)
  • •Cable protection: Without armor
  • •Reference target: AISI 4140 steel; recommended minimum target diameter 61 mm (2.4 in)
  • •Connector: Make ClickLoc connections finger tight and keep connector protectors clean
  • •Cable routing: Maintain a 25.4 mm (1.0 in) minimum bend radius and avoid unsupported loads
  • •Commissioning: Verify target material, bracket stiffness, viewing clearance, gap, and electrical matching
Description

The Bently Nevada 330854-040-24-CN is a 3300 XL 25 mm Extension Cable configured with 4.0 m (13.1 ft) high temperature fluidloc cable, without armor, and country-specific china approval option; verify current markings in the approvals quick reference guide.

The cable is part of the 3300 XL 25mm Proximity Transducer System, which provides a 12.7 mm (500 mils) linear range and a nominal scale factor of 0.787 V/mm (20 mV/mil).

Combine this 4.0 m cable with a 1.0 m probe and 5 m Proximitor Sensor. Protect both ClickLoc connections and verify system matching before commissioning.

Alternative Names
330854-040-24-CN Bently Nevada 330854-040-24-CN Baker Hughes Bently Nevada 330854-040-24-CN 330854-040-24-CN 3300 XL 25 mm Extension Cable 330854-040-24-CN 3300 XL 25mm Proximity Transducer System 330854-040-24-CN datasheet 330854-040-24-CN quotation 33085404024CN
Technical notes
330854-040-24-CN is a 4.0 m (13.1 ft) high temperature fluidloc cable. Combine this 4.0 m cable with a 1.0 m probe and 5 m Proximitor Sensor.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the Bently Nevada 330854-040-24-CN?
It is a 3300 XL 25 mm Extension Cable for the 3300 XL 25mm Proximity Transducer System.
What is the configuration of 330854-040-24-CN?
4.0 m (13.1 ft) high temperature fluidloc cable, without armor, and country-specific china approval option; verify current markings in the approvals quick reference guide.
What approval option is specified for 330854-040-24-CN?
Code CN indicates country-specific china approval option; verify current markings in the approvals quick reference guide.
What measurement system uses 330854-040-24-CN?
It belongs to the 3300 XL 25mm Proximity Transducer System, with a 12.7 mm (500 mils) system linear range.
What scale factor applies to 330854-040-24-CN?
The official system nominal scale factor is 0.787 V/mm (20 mV/mil).
How should 330854-040-24-CN be matched?
Combine this 4.0 m cable with a 1.0 m probe and 5 m Proximitor Sensor.
What is the lifecycle status of 330854-040-24-CN?
Active / Available from OEM.
Can Apter Power support 330854-040-24-CN?
Apter Power can provide quotations, technical documents, sourcing support, and system matching guidance.
