The Bently Nevada 330101-00-08-10-01-00 is a 3300 XL 8 mm proximity probe for use in the 3300 XL proximity sensor system, measuring static position and dynamic vibration.
Get a quick price for 330101-00-08-10-01-00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330101-00-08-10-01-00

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330101-00-08-10-01-00
  • Product Family:
    3300 XL 8 mm Probe
  • Product Type:
    3300 XL 8 mm Proximity Probe
  • Minimum unthreaded length:
    0.0 in.
  • Overall Case Length Option:
    0.8 in.
  • Total Length Option:
    1.0 meter (3.3 feet)
  • Connector and Cable-Type Option:
    Miniature coaxial ClickLoc connector with connector protector, standard cable
  • Agency Approval Option:
    Not required
  • Nominal Probe DC Resistance:
    7.59 ± 0.50 Ω
  • Maximum Altitude:
    2000 meters
  • Operating and Storage Temperature:
    -52°C to +177°C (-62°F to + 350°F)
  • Weight:
    0.06 kg
  • Estimated shipping dimensions:
    1.6x1.4x112cm
  • Tariff Code:
    9025199090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Configuration Use Cases Performance

Features:

  • Provides precise eddy current-based vibration and position measurement for rotating machinery monitoring
  • Supports high mechanical durability with TipLoc bonding and CableLoc cable retention up to 330 N pull strength
  • Ensures system flexibility with full interchangeability across 3300 XL probe, cable, and sensor components
The Bently Nevada 330101-00-08-10-01-00 is widely applied in industrial rotating equipment monitoring systems where continuous vibration and shaft position tracking are required. It delivers consistent signal response that reflects real-time changes in machine conditions. In turbine, compressor, and pump applications, the Bently Nevada 330101-00-08-10-01-00 helps support early fault detection and operational stability. Its compatibility with the 3300 XL system ensures smooth integration in both new and existing installations. Engineers often rely on the Bently Nevada 330101-00-08-10-01-00 for long-term monitoring strategies.

In industrial environments with high temperature variation and mechanical stress, the Bently Nevada 330101-00-08-10-01-00 maintains stable performance across a wide operating range. The probe construction is designed to resist mechanical loosening and cable strain during continuous operation. The Bently Nevada 330101-00-08-10-01-00 also supports flexible installation through its compact probe design and ClickLoc connector system. These features make it suitable for confined or vibration-intensive mounting locations. It plays an important role in maintaining measurement reliability in critical machinery systems.

From a system perspective, the Bently Nevada 330101-00-08-10-01-00 contributes to standardized monitoring architecture under API 670 guidelines. It works seamlessly with extension cables and Proximitor sensors to ensure accurate signal conversion and transmission. The Bently Nevada 330101-00-08-10-01-00 enables consistent interchangeability, reducing maintenance complexity and downtime. Its robust design supports long service life in continuous industrial operation. This makes the Bently Nevada 330101-00-08-10-01-00 a dependable component in predictive maintenance and asset protection programs.

The 330101-00-08-10-01-00 Bently Nevada 3300 XL 8 mm Proximity Probe may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330101-00-08-10-01-00 3300 XL 8 mm Proximity Probe Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330101-00-08-10-01-00 3300 XL 8 mm Proximity Probe Specs

General

  • Manufacturer Bently Nevada
  • Model 330101-00-08-10-01-00
  • Condition New Original ready stock
  • Product Family 330101-00-08-10-02-00,330101-00-08-10-12-00,330101-00-08-30-01-00
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Threadless Length: 00 indicates 0 inches, meaning the entire probe housing is threaded.
  • Total Housing Length: 08 indicates the housing length is 0.8 inches.
  • Total Cable Length: 10 indicates the included cable length is 1.0 meter (3.3 feet).
  • Connectors and Cable: 01 indicates the inclusion of a ClickLoc mini coaxial connector with connector protection sleeve and a standard cable.
  • Institutional Certification Code: 00 indicates no specific country/region explosion-proof safety certification is required.
  • Fluid Thin-Film Bearing Monitoring: Widely installed on heavy-duty industrial rotating machinery using sliding bearings.
  • Radial Vibration Measurement: Used to continuously capture the dynamic radial runout and shaft centerline trajectory of high-speed rotating shafts.
  • Axial Position Monitoring: Real-time measurement of axial movement of rotors in turbines, compressors, etc., to prevent bearing wear.
  • Keyphasor and Speed ​​Measurement: As a keyphasor sensor, it provides speed and phase reference signals by identifying keyways on the shaft.
  • Linear Measurement Range: Capable of linear measurement of static and dynamic displacement up to 2.0 mm (80 mils).
  • Standard Sensitivity: Average Scale Factor (ASF) meets industry standards at 7.87 V/mm (200 mV/mil).
  • Rated Operating Temperature: The probe head and cable can operate stably in harsh environments from -35°C to +200°C.
  • Mechanical Tensile Strength: The maximum rated tensile strength between the probe housing and the lead wires is 330 N (75 lbf).
  • Material and Sealing: The housing is made of AISI 304 stainless steel, and the probe tip is made of high-strength polyphenylene sulfide (PPS) insulation.
Description
The Bently Nevada 330101-00-08-10-01-00 3300 XL 8 mm proximity probe is part of a complete eddy current measurement system designed for precise monitoring of machine shaft behavior. It works together with an extension cable and Proximitor sensor to form a fully integrated transducer system. The 330101-00-08-10-01-00 provides stable output performance that reflects changes in distance between the probe tip and conductive target surfaces. It is widely used in machinery condition monitoring environments where both vibration and position data are critical. This model 330101-00-08-10-01-00 ensures compatibility within the 3300 XL ecosystem without requiring individual calibration matching.

Built with a 3/8-24 UNF threaded design and no armor configuration, the 330101-00-08-10-01-00 features a total system length option of 1.0 meter (3.3 feet) and a miniature coaxial ClickLoc connector with connector protector. The probe operates with a nominal DC resistance of 7.59 ± 0.50 Ω, ensuring consistent electrical performance. The 330101-00-08-10-01-00 also supports an operating and storage temperature range from -52°C to +177°C, making it suitable for harsh industrial environments. With a maximum altitude rating of 2000 meters, the 330101-00-08-10-01-00 can be deployed in various installation conditions.

The mechanical design of the 330101-00-08-10-01-00 incorporates patented TipLoc and CableLoc technologies, improving the bonding strength between probe components and increasing cable retention strength up to 330 N (75 lbf). These enhancements improve durability in high-vibration machinery environments. In addition, optional FluidLoc cable construction prevents oil or fluid migration through the cable interior, helping maintain machine sealing integrity. The 330101-00-08-10-01-00 also maintains backward compatibility with legacy 3300 series systems, allowing flexible integration in existing monitoring setups.

Overall, the 330101-00-08-10-01-00 is engineered to support accurate measurement performance in fluid-film bearing machines, where precise vibration and position data are essential for predictive maintenance strategies. It contributes to system-level interchangeability, allowing probes, extension cables, and Proximitor sensors to be swapped without recalibration. The 330101-00-08-10-01-00 also aligns with API 670 mechanical and performance requirements in standard configurations. Its robust construction and measurement stability make it suitable for continuous industrial monitoring applications.
Alternative Names
3301010008100100 3301O1-OO-O8-1O-O1-OO 330I0I-00-08-I0-0I-00 330101-00-08-10-01-05 330101-00-08-10-01-CN 330101-00-08-10-01-BR 330101-00-08-10-01-RU 330101-00-08-10-11-00
Technical notes
The Bently Nevada 330101-00-08-10-01-00 is a premium 3300 XL 8 mm proximity probe configured with a 0.8-inch case length and 1.0-meter cable, engineered to deliver precise critical machinery diagnostics across a 2.0 mm (80 mils) linear range.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How does Bently Nevada 330101-00-08-10-01-00 integrate with other components in the system?
The Bently Nevada 330101-00-08-10-01-00 operates together with a 3300 XL extension cable and Proximitor sensor as a complete transducer system.
Why is Bently Nevada 330101-00-08-10-01-00 suitable for harsh environments?
The Bently Nevada 330101-00-08-10-01-00 supports -52°C to +177°C temperature range and 2000 meters altitude rating, ensuring reliable operation under extreme conditions.
How does Bently Nevada 330101-00-08-10-01-00 maintain mechanical reliability?
The Bently Nevada 330101-00-08-10-01-00 uses TipLoc molding and CableLoc design to strengthen probe bonding and improve cable pull strength.
What applications commonly use Bently Nevada 330101-00-08-10-01-00?
The Bently Nevada 330101-00-08-10-01-00 is used in fluid-film bearing machines for vibration, position, Keyphasor, and speed measurement.
