330101-00-24-10-02-CN

/ 4.9
1001 reviews | Need a Specific Revision?
The 330101-00-24-10-02-CN is a Bently Nevada 3300 XL 8 mm proximity probe with 3/8-24 UNF thread, 2.4 in case length, 1.0 m total length, standard cable, and ClickLoc connector.
Get a quick price for 330101-00-24-10-02-CN
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330101-00-24-10-02-CN

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330101-00-24-10-02-CN
  • Product Family:
    3300 XL 8 mm Probe
  • Product Type:
    Proximity Probe
  • Thread Type:
    3/8-24 UNF
  • Armor:
    None (use 330102 for armored)
  • Unthreaded Length:
    0.0 inches (0 mm)
  • Overall Case Length:
    2.4 inches (61 mm)
  • Total Length (probe + cable):
    1.0 meter (3.3 feet)
  • Connector Type:
    Miniature coaxial ClickLok
  • Cable Type:
    Standard cable
  • Agency Approval:
    Approvals country specific
  • Sensitivity:
    7.87 V/mm (200 mV/mil)
  • Linear Range:
    approx. 2 mm (80 mils)
  • Operating Temperature (standard):
    Up to 177°C (350°F)
  • Weight:
    0.05 kg
  • Estimated shipping dimensions:
    1.5x1.3x118cm
  • Tariff Code:
    8479899990
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Certifications Compatibility

Features:

  • No bench calibration or component matching required; any 3300 XL probe works with any 3300 XL extension cable and Proximitor sensor.
  • TipLoc™ tip‑to‑body bond; CableLoc™ 330 N pull strength; gold‑plated ClickLoc™ connectors resist vibration loosening; API 670 compliant.
  • Certified for use in the Chinese market with local agency approvals; suitable for power plants, refineries, and other industrial facilities in China.
The 330101-00-24-10-02-CN is part of Bently Nevada’s 3300 XL system, which is designed for complete component interchangeability. In older transducer systems, each probe, extension cable, and Proximitor sensor had to be individually calibrated and matched to achieve specified accuracy. This made field replacements time‑consuming and required specialized test equipment. The 3300 XL system eliminates this requirement. Any 3300 XL 8 mm probe works with any 3300 XL extension cable and any 3300 XL Proximitor sensor – no bench calibration or component matching is needed. This feature significantly reduces maintenance downtime: a technician can replace a failed probe in minutes without waiting for a calibrated spare or performing on‑site adjustments.

The 330101-00-24-10-02-CN incorporates several patented mechanical improvements over previous probe designs. TipLoc™ is a molding method that creates a more robust bond between the probe tip (where the coil is located) and the probe body. This prevents the tip from loosening or rotating during installation or under vibration. CableLoc™ secures the cable attachment point where the probe cable joins the probe tip. This design provides 330 N (75 lbf) pull strength, meaning even if someone accidentally pulls on the cable during installation or maintenance, the connection will not separate.

The 330101-00-24-10-02-CN carries the CN suffix, indicating country‑specific approvals for the Chinese market. Industrial facilities in China – including power plants, oil refineries, chemical plants, and steel mills – often require local certifications such as CCC (China Compulsory Certificate) or other agency approvals for electrical equipment installed in hazardous or safety‑related areas. Using components with the correct local approval is mandatory for regulatory compliance and insurance purposes.

The 330101-00-24-10-02-CN Bently Nevada Proximity Probe may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL)by the manufacturer (OEM).

Bently Nevada 330101-00-24-10-02-CN Proximity Probe Manuals, Datasheets,Drivers,Link Important Notice:Other accessories,manuals,cables,calibration data,software,etc.are not included with this equipment unless listed in the above stock item description.All prices are shown in USD.
Bently Nevada 330101-00-24-10-02-CN Proximity Probe Specs

General

  • Manufacturer GE /Bently Nevada
  • Model 330101-00-24-10-02-CN
  • Condition New Original ready stock
  • Product Family 330101-00-24-10-01-CN,330101-00-24-10-11-CN,330101-00-24-10-02-00
Important Notice:Other accessories,manuals,cables,calibration data,software,etc.are not included with this equipment unless listed in the above stock item description.All prices are shown in USD.
  • Mechanical Condition Monitoring: Measuring radial vibration and axial displacement of large rotating equipment (such as steam turbines, compressors, pumps, and motors).
  • Speed ​​and Rotation Monitoring: As a keyphasor sensor, it provides a reference signal per revolution for calculating rotational speed and performing phase analysis.
  • Industrial Applications: Widely used in heavy industrial environments such as oil, natural gas, petrochemicals, power generation, and large-scale manufacturing.
  • NEPSI Certification: Possesses the explosion-proof mark of the National Explosion-Proof Electrical Products Quality Supervision and Inspection Center of China (NEPSI), applicable to hazardous areas within China.
  • International Explosion-Proof Standards: Typically complies with international hazardous area certification standards such as ATEX, IECEx, and CSA (Class I Div 2 / Zone 2).
  • Industry Standards: Its performance fully complies with API 670 (American Petroleum Institute) standards, meeting top-tier industry requirements in terms of mechanical configuration, linear range, and temperature stability.
  • System Compatibility: Fully compatible with the 3300 XL Proximitor Sensor and the 3500 Series Mechanical Protection Monitoring System.
  • Seamless Replacement: Supports seamless interchangeability between the probe, extension cable, and proximitor without significant deviation in output signals (such as gap voltage or vibration values).
  • Backward Compatibility: Remains compatible with some components from older non-XL series (such as the 3300 series), facilitating gradual upgrades to older systems.
Description
The 330101-00-24-10-02-CN is a 3300 XL 8 mm proximity probe with 3/8-24 UNF thread and no armor. When using the 330101-00-24-10-02-CN, engineers benefit from Bently Nevada’s patented TipLoc™ molding, which provides a robust bond between the probe tip and body. The CableLoc™ design provides 330 N (75 lbf) pull strength at the cable attachment point. The gold‑plated ClickLoc™ connectors require only finger‑tight torque and will not loosen due to vibration.

The 330101-00-24-10-02-CN has a standard operating temperature range up to 177°C (350°F) for the probe lead and extension cable. The standard system (5‑meter total length) fully complies with API 670 Standard for mechanical configuration, linear range, accuracy, and temperature stability. The “CN” suffix indicates country‑specific approvals for China (likely CCC or equivalent). This probe is not armored – use 330102 for armored version.

For legacy Bently Nevada system expansions or repairs, the 330101-00-24-10-02-CN provides a direct replacement for 3300 series 8 mm probes. It is compatible with 3300 XL Proximitor sensors (330180) and extension cables (330130).
Alternative Names
330101-00-24-10-01-CN 330101-00-24-10-11-CN 330101-00-24-10-02-RU 330101-00-24-10-02-00
Technical notes
The 330101-00-24-10-02-CN has a total length of 1.0 meter (probe cable only). It is designed for use with a 1.0 meter extension cable and a 1.0 meter Proximitor sensor (330180-1x) or with a 5.0 meter Proximitor and no extension cable. Always match the total system length to the Proximitor sensor length.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Is 330101-00-24-10-02-CN compatible with existing 3300 systems?
Yes. The 330101-00-24-10-02-CN is fully backward compatible with non‑XL 3300 series 5 mm and 8 mm components. It works with existing Proximitor sensors and extension cables without bench calibration, reducing downtime during replacement.
What is the sensitivity of 330101-00-24-10-02-CN?
The probe provides 200 mV/mil (7.87 V/mm) sensitivity with a linear range of approximately 2 mm (80 mils). This output is directly proportional to the distance between the probe tip and the shaft, enabling precise radial vibration and thrust position monitoring.
How does 330101-00-24-10-02-CN prevent mechanical failure?
The probe uses patented TipLoc™ molding for a robust tip‑to‑body bond and CableLoc™ design providing 330 N (75 lbf) pull strength at the cable attachment. The ClickLoc™ connector locks securely with finger‑tight torque and resists vibration loosening.
Does 330101-00-24-10-02-CN include connector protection?
The “02” connector option is a standard ClickLoc™ connector without a factory‑installed protector. For increased environmental protection (especially when routing through conduit), order the “01” option which includes a connector protector, or order protectors separately.
