330102-00-12-90-02-05

/ 4.9
1001 reviews | Need a Specific Revision?
The 330102-00-12-90-02-05 is a 3300 XL 8 mm proximity probe featuring a 3/8-24 UNF thread with armor protection. This model includes a 9.0 meter (29.5 feet) total length with an overall case length of 1.2 inches and unthreaded length of 0.0 inches.
Get a quick price for 330102-00-12-90-02-05
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330102-00-12-90-02-05

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330102-00-12-90-02-05
  • Product Family:
    3300 XL 8 mm Probe
  • Product Type:
    3300 XL 8 mm Proximity Probe
  • Thread Type:
    3/8-24 UNF (with armor)
  • Total Length:
    9.0 meters (29.5 feet)
  • Unthreaded Length:
    0.0 inches
  • Overall Case Length:
    1.2 inches
  • Connector Type:
    Miniature coaxial ClickLoc™
  • Connector Material:
    Gold-plated brass
  • Cable Type:
    Standard cable
  • Agency Approvals:
    CSA, ATEX, IECEx
  • Key Benefit:
    Model 330102-00-12-90-02-05 carries CSA, ATEX, and IECEx approvals for global hazardous area deployment.
  • Weight:
    0.15 kg
  • Estimated shipping dimensions:
    1.5x1.3x116cm
  • Tariff Code:
    8479899990
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Connections Safety and Compliance

Features:

  • 9.0-meter (29.5 feet) extended cable length enables remote monitoring installations with the Proximitor sensor located far from the measurement point.
  • CSA, ATEX, and IECEx approvals provide global hazardous area deployment without region-specific variants, simplifying procurement and compliance.
  • Armor protection with compact 1.2-inch case length delivers mechanical durability for long cable runs while fitting in space-constrained mounting ports.
The 330102-00-12-90-02-05 is designed for installations where the Proximitor sensor must be located at a significant distance from the measurement point. Its 9.0-meter integral cable eliminates the need for a separate extension cable, reducing the number of connections and potential failure points in the monitoring path.

The 330102-00-12-90-02-05 carries CSA, ATEX, and IECEx approvals, making it suitable for deployment in explosive environments across North America, Europe, and international markets. This multi-agency certification is particularly valuable for remote monitoring applications where the cable may pass through or terminate in hazardous areas.

The 330102-00-12-90-02-05 combines extended cable length with armor protection to ensure reliable operation in demanding industrial environments. The armored construction shields the 9.0-meter cable against crushing, abrasion, and impact damage during routing through conduit, cable trays, or open trenches—common requirements when connecting remote sensors to control cabinets.

The 330102-00-12-90-02-05 Bently Nevada 3300 XL 8 mm Proximity Probes may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 330102-00-12-90-02-05 3300 XL 8 mm Proximity Probes Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330102-00-12-90-02-05 3300 XL 8 mm Proximity Probes Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330102-00-12-90-02-05
  • Condition New Original ready stock
  • Product Family 330102-00-12-90-01-05,330102-00-12-90-11-05,330102-00-12-90-02-00
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Radial Vibration Monitoring: Measures the dynamic vibration of the shaft in fluid thin-film bearings (sliding bearings) to assess alignment and balance.
  • Axial Displacement Monitoring: Monitors wear on thrust bearings to prevent rotor-stator collisions.
  • Phase and Speed ​​Reference (Keyphasor): Provides accurate speed pulses for eccentricity measurement and vector analysis.
  • Typical Equipment: Steam turbines, centrifugal compressors, large motors, and power plant auxiliary equipment (such as feedwater pumps and fans).
  • Physical Connection: Utilizes ClickLoc mini coaxial connectors. This design features an anti-loosening locking mechanism to ensure stable signal transmission under machine vibration conditions and allows for manual installation and removal without special tools.
  • Signal Transmission: The probe connects to the 3300 XL preamplifier via an extension cable, converting gap variations into a linear voltage signal (standard 200 mV/mil or 7.87 V/mm).
  • System Integration: The preamplifier output is typically connected to a Bently Nevada 3500 monitoring system or a Distributed Control System (DCS). Although the probe itself does not have digital communication capabilities, it can communicate digitally via Modbus, Ethernet, or PROFIBUS when integrated with the 3500 system.
  • Explosion-proof Certification: Certified by CSA, ATEX, IECEx, and other standards, suitable for flammable and explosive environments including Zone 0, Zone 1, and Zone 2 (Zone 0/1/2).
  • Electrical Safety: Designed to meet intrinsic safety standards, and when used with a suitable Zener Barrier, it prevents energy leakage from igniting sparks.
  • Sealing: The probe tip is encapsulated in PPS plastic, providing oil, water, and high-pressure resistance (withstanding the oil pressure inside the bearing).
Description
The 330102-00-12-90-02-05 features a 3/8-24 UNF thread configuration with armor protection, providing enhanced durability for demanding industrial installations requiring standard UNF mounting threads. This model includes a 9.0 meter (29.5 feet) total length with an overall case length of 1.2 inches and unthreaded length of 0.0 inches.

The 330102-00-12-90-02-05 carries CSA, ATEX, and IECEx approvals for global deployment in hazardous areas, simplifying compliance requirements for international installations. This model can be configured with an optional FluidLoc cable option, which prevents oil and other liquids from leaking out of the machine through the cable's interior, addressing critical safety concerns in lubricated machinery.

This 8 mm probe provides a thicker encapsulation of the probe coil in molded PPS plastic, resulting in a more rugged probe design. The larger diameter of the probe body also provides a stronger, more robust case for optimal robustness against physical abuse.

With its combination of hazardous area approvals, extended cable length, and 8 mm durability, the 330102-00-12-90-02-05 is well-suited for remote monitoring of critical machinery in explosive environments.
Alternative Names
330102-00-12-90-01-05 330102-00-12-90-11-05 330102-00-12-90-12-05 330102-00-12-90-02-00
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What installation advantage does the 9.0-meter cable length provide?
The extended 9.0-meter cable allows the Proximitor sensor to be located in a control cabinet or protected area remote from the machine, eliminating the need for a separate extension cable and reducing connection points.
What hazardous area approvals does this probe carry?
The 330102-00-12-90-02-05 carries CSA, ATEX, and IECEx approvals, enabling global deployment in explosive environments without requiring region-specific variants.
How does the armor protection benefit this long cable?
The armored construction protects the extended 9.0-meter cable against crushing and abrasion during routing through conduit or cable trays, ensuring signal integrity over long distances.
What is the overall case length of this probe?
The probe features a compact 1.2-inch overall case length, allowing installation in space-constrained mounting ports where longer cases would not fit.
