          Apter Power guarantees premium quality Bently Nevada vibration monitoring hardware, offering a highly reliable source for critical machinery protection replacement parts.

        330102-10-40-10-02-00

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        The Bently Nevada 330102-10-40-10-02-00 is a premium 3300 XL 8mm eddy-current proximity probe engineered with stainless steel armor for heavy-duty machinery vibration and position monitoring.
        In Stock
        Ships by Thursday, October 29
        Fast Shipping Available
        Get a quick price for 330102-10-40-10-02-00
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 330102-10-40-10-02-00

        • Manufacturer:
          Bently Nevada
        • Part Number:
          330102-10-40-10-02-00
        • Stock:
          1
        • Probe Tip Diameter:
          8 mm (0.31 in)
        • Thread Type & Size:
          3/8-24 UNF (United National Fine Thread)
        • Unthreaded Length:
          1.0 in.
        • Overall Case Length:
          4.0 in.
        • Total Length:
          1.0 meter (3.3 feet)
        • Connector and Cable-Type:
          Miniature coaxial ClickLoc connector, standard cable
        • Agency Approval:
          Not required
        • Linear Range:
          2.0 mm (80 mils) starting at approx. 0.25 mm (10 mils) gap
        • Scale Factor / Sensitivity:
          7.87 V/mm (200 mV/mil) when paired with 3300 XL Proximitor
        • Target Material Calibration:
          AISI 4140 Electric Furnace Melt Steel
        • Operating Temperature Range:
          -52°C to +177°C (-62°F to +350°F)
        • Probe Tip Material:
          Polyphenylene Sulfide (PPS)
        • Weight:
          0.15 kg
        • Estimated shipping dimensions:
          1.6x1.3x112cm
        • Tariff Code:
          8537101190
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen, Fujian, China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Specifications Applications Safety & Compliance Performance & Efficiency

        Features:

        • Rugged Stainless Steel Armor Protection for Ultimate Durability
        • Advanced ClickLoc Connection with Intelligent Contamination Lockout
        • Excellent Thermal and Chemical Stability under Extreme Operations
        The coaxial cable of the Bently Nevada 330102-10-40-10-02-00 is fully encased in a flexible, high-tensile stainless steel armor conduit. This heavy-duty shielding acts as an impenetrable barrier against physical shearing, tearing, and mechanical crushing, making it perfectly suited to endure the punishing environments of high-vibration machinery housings and tight routing channels without compromising signal delivery.

        The Bently Nevada 330102-10-40-10-02-00 features a specialized miniature coaxial ClickLoc connector. This tool-less, user-friendly connection mechanism physically clicks to confirm a 100% secure link while establishing a tight seal that locks out ambient moisture, oil ingress, and airborne dust particles, drastically reducing maintenance overhead and eliminating common signal losses caused by environmental exposure.

        Engineered with a high-performance PPS (Polyphenylene Sulfide) plastic tip and a premium-grade corrosion-resistant stainless steel case, the Bently Nevada 330102-10-40-10-02-00 guarantees an ultra-low thermal drift across an expansive temperature spectrum ranging from -52°C to +177°C. This exceptional material stability allows the probe to provide unwavering, linear measurement data even when subjected to harsh industrial chemical fluids or severe thermal cycling.

        The 330102-10-40-10-02-00 Bently Nevada 3300 XL 8mm Proximity Probe may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
        Bently Nevada 330102-10-40-10-02-00 3300 XL 8mm Proximity Probe Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        Bently Nevada 330102-10-40-10-02-00 3300 XL 8mm Proximity Probe

        General

        • Manufacturer GE / Bently Nevada
        • Model 330102-10-40-10-02-00
        • Condition New Original ready stock
        • Product Family 330102-60-96-10-02-05,330102-00-13-10-02-00,330102-00-80-10-02-00
        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        • Critical Turbo-Machinery Protection: Capable of capturing high-frequency micro-vibrations, making it indispensable for monitoring high-speed steam and gas turbines in power generation plants.
        • Centrifugal Compressor Radial Tracking: Strategically installed in pairs (X-Y configuration) on fluid-film bearings to trace the precise dynamic orbit of compressor shafts under heavy thermodynamic loads.
        • Thrust Bearing Axial Position Monitoring: Deployed facing the shaft thrust collar to measure minute axial displacements, preventing catastrophic internal rotor-to-stator rubbing inside massive industrial pumps.
        • Hydro-Turbine Air Gap and Runout Analysis: Provides reliable shaft runout and absolute displacement tracking in slow-speed hydroelectric generator shafts subjected to immense hydraulic forces.
        • API 670 Machinery Protection Compliance: Engineered to strictly adhere to the American Petroleum Institute’s API 670 standard, ensuring standardized electronic performance and maximum reliability for oil and gas refinery assets.
        • Strict Mechanical Ingress Containment: The PPS tip and stainless steel case interface are hermetically sealed, functioning as a robust primary containment barrier against high-pressure oil leaks from bearing housings.
        • High Insulation Safety Resistance: Delivers superior electrical isolation between the inner probe circuitry and the machine ground, preventing dangerous ground-loop noise from corrupting critical plant emergency shutdown systems (ESD).
        • Structural Mechanical Resilience: Built utilizing high-tensile AISI 303/304 stainless steel, preventing thread stripping or structural shearing under extreme physical stresses or pipe-strain anomalies.
        • Sub-Micron Precision and Minimal Thermal Drift: Offers excellent measurement repeatability with minimal drift, ensuring the system does not trigger false machinery trips during cold-start or high-temperature operations.
        • Optimized 1.0-Meter Signal Path: Eliminates the need for intermediary cable junctions close to the machine, reducing impedance mismatches and ensuring crisp, noise-free signal transmission to the control room.
        • Wide-Band Frequency Response: Operates flawlessly from DC (0 Hz) up to 10 kHz, allowing maintenance teams to capture both slow operational position shifts and high-frequency rotor blade pass frequencies.
        • Efficient ClickLoc Interlocking Mechanism: Significantly slashes plant downtime during routine maintenance or sensor swaps due to the tool-less, click-locking connection that ensures zero signal loss.
        Description
        The Bently Nevada 330102-10-40-10-02-00 is a cornerstone component of the world-renowned 3300 XL series, specifically designed to withstand the harshest industrial environments. Featuring a 3/8-24 UNF threaded case with a 4.0-inch overall length and a 1.0-inch unthreaded portion, this probe allows for precise physical gap calibration during installation. The integrated flexible stainless steel armor provides robust mechanical protection for the coaxial cable against sharp edges, abrasive debris, and physical impacts common on plant floors.

        Operating on the eddy-current principle, the Bently Nevada 330102-10-40-10-02-00 provides continuous, non-contact measurements of static (position) and dynamic (vibration) parameters. It is factory-calibrated to a standard AISI 4140 steel target, ensuring an exceptionally linear 80 mil (2.0 mm) measurement range. The probe tip is molded from high-performance Polyphenylene Sulfide (PPS) plastic, hermetically sealing the internal coil against moisture, oil, and chemical ingress.

        With a total electrical length of 1.0 meter, the Bently Nevada 330102-10-40-10-02-00 is designed for direct integration or localized termination without requiring an intermediate extension cable, significantly reducing signal attenuation. Equipped with a miniature coaxial ClickLoc connector, it guarantees a secure, vibration-resistant connection to the proximity transducer system, maintaining pristine signal integrity under extreme operational stress.
        Alternative Names
        330102 10 40 10 02 00 33O1O2-1O-4O-1O-O2-OO 330I02-I0-40-I0-02-00 33OIO2-IO-4O-IO-O2-OO 330102-10-40-10-02-05 330102-10-40-10-02-CN 330102-10-40-10-02-BR 330102-10-40-10-02-RU
        Technical notes
        The Bently Nevada 330102-10-40-10-02-00 requires strict adherence to proper gap voltage positioning (typically -10 VDC at the linear midpoint) using a digital voltmeter during installation to ensure measurement accuracy. For optimal performance, the Bently Nevada 330102-10-40-10-02-00 must be paired exclusively with a matching 3300 XL 5-meter or 9-meter Proximitor Sensor system configured for a 1-meter probe length.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        Can the Bently Nevada 330102-10-40-10-02-00 be connected directly to a 9-meter 3300 XL Proximitor Sensor?
        Yes, but only if the Proximitor Sensor is explicitly configured for a 1-meter probe. Because the Bently Nevada 330102-10-40-10-02-00 has an integrated total length of 1.0 meter, you must use an 8.0-meter extension cable to complete the 9.0-meter system loop required by the Proximitor to maintain the standard 200 mV/mil scale factor.
        What is the significance of the 1.0-inch unthreaded length on the Bently Nevada 330102-10-40-10-02-00 case?
        The 1.0-inch unthreaded length on the Bently Nevada 330102-10-40-10-02-00 allows the probe to pass through thick mounting brackets or outer casings smoothly without thread binding. It leaves 3.0 inches of active thread on the 4.0-inch case for precise locking nut adjustment and gap voltage tuning.
        How do I diagnose a faulty connection or wire break within the Bently Nevada 330102-10-40-10-02-00?
        You can measure the DC resistance of the Bently Nevada 330102-10-40-10-02-00 using a multimeter across the center conductor and outer shield of the ClickLoc connector. A healthy 1-meter probe typically registers a very low center-to-shield resistance (typically between 4.0 to 8.0 ohms); an infinite reading (open circuit) indicates a broken internal wire.
        How does target material composition alter the calibration of the Bently Nevada 330102-10-40-10-02-00?
        The Bently Nevada 330102-10-40-10-02-00 is factory-tuned to AISI 4140 steel. If the probe is targeting a different metal (e.g., stainless steel, Inconel, or chromed shafts), the eddy-current properties change, resulting in a altered Scale Factor and a non-linear output, which requires custom recalibration via the Proximitor or monitoring system.
        What is the correct mechanical installation sequence for mounting the Bently Nevada 330102-10-40-10-02-00?
        First, thread the Bently Nevada 330102-10-40-10-02-00 into the machine housing bracket until the tip gently touches the shaft. Next, back the probe out approximately 1.27 mm (50 mils) to establish the midpoint gap. Finally, power the system and monitor the Proximitor's DC output voltage, fine-tuning the probe depth until it reads -10.0 VDC before locking the nuts.
