330103-00-07-10-12-05

/ 4.9
1001 reviews | Need a Specific Revision?
The 330103-00-07-10-12-05 3300 XL 8 mm Probe has an M10x1 thread, no armor, 1.0 m total length, FluidLoc cable with ClickLoc connector, and CSA, ATEX, IECEx approvals.
Get a quick price for 330103-00-07-10-12-05
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330103-00-07-10-12-05

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330103-00-07-10-12-05
  • Product Family:
    3300 XL 8 mm Probe
  • Unthreaded Length Option:
    00 mm
  • Overall Case Length Option:
    70 mm
  • Total Length Option:
    1.0 meter (3.3 feet)
  • Connector and Cable-Type Option:
    Miniature coaxial ClickLoc connector, FluidLoc cable
  • Agency Approval Option:
    CSA, ATEX, IECEx Approvals
  • Probe Tip Material:
    Polyphenylene sulfide (PPS).
  • Probe Case Material:
    AISI 303 or 304 stainless steel (SST).
  • Operating and Storage Temperature:
    -52°C to +177°C (-62°F to + 350°F)
  • Armor (optional on both):
    Flexible AISI 302 or 304 SST with FEP outer jacket.
  • Weight:
    0.08 kg
  • Estimated shipping dimensions:
    112.3x1.6x1.6cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Use Cases Certifications & Standards Firmware & Updates

Features:

  • Interface Between the Proximity Probe and 3500 Monitoring System
  • Combines Capability of Eddy Current Sensing with FluidLoc Cable Protection
  • Operates in Conjunction with the 3300 XL Series Proximitors and Standard 3500 Monitors
The 330103-00-07-10-12-05 operates as the 3300 XL 8 mm Proximity Probe in a 3500 rack, providing reliable vibration and position measurement to all modules within the system. It continuously converts target motion into electrical signals using eddy current technology and transmits this data through the FluidLoc cable to support steady state operation of all monitors and modules. Seamless signal transfer is standard with the 330103-00-07-10-12-05, however using an optional Redundant Probe Configuration will allow seamless switchover to a backup sensor in the event of a primary probe failure. The 330103-00-07-10-12-05 has made improvements in several areas over previous probe designs in addition to incorporating universal M10 x 1 thread mounting capability within the 3500 rack.

The 330103-00-07-10-12-05 provides essential sensing functions common to the entire rack, and is a critical component of the monitoring path, directly affecting the proper, normal operation of the overall monitor system. One or two 330103-00-07-10-12-05 probes are required per measurement point depending on the desired redundancy level. The 330103-00-07-10-12-05 occupies only a single probe position in the system and is always located at the measurement point (target position, the dedicated sensing location).

For Dual Redundant Probe applications, the 3500 System requires a second 330103-00-07-10-12-05 probe module installed in the redundant position. In addition to standard single probe operation, the redundant configuration also performs automatic switchover. The 3500 dual probe configuration executes failover using the internal circuitry specified in the probe options. Using this method, the redundant probe system continually monitors the health of both sensors. If the system detects that the primary 330103-00-07-10-12-05 probe is no longer providing stable output (outside configured signal/tolerance levels), it will automatically transfer the measurement to the secondary probe and place an event in the System Event List.

The 330103-00-07-10-12-05 Bently Nevada 3300 XL 8 mm Proximity Probe may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330103-00-07-10-12-05 3300 XL 8 mm Proximity Probe Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330103-00-07-10-12-05 3300 XL 8 mm Proximity Probe Specs

General

  • Manufacturer Bently Nevada
  • Model 330103-00-07-10-12-05
  • Condition New Original ready stock
  • Product Family 330103-00-07-10-12-00,330103-00-07-10-12-CN
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Radial Vibration: Monitoring shaft vibration in rotating machinery like turbines, compressors, and pumps.
  • Axial Position (Thrust): Measuring the longitudinal position of a shaft to prevent catastrophic contact with bearing surfaces.
  • Speed and Phase Reference: Serving as a Keyphasor to provide timing signals for vibration analysis and rotational speed measurements.
  • Condition Monitoring: Assessing bearing health and overall equipment stability in fluid-film bearing machines.
  • API 670 Standard: The standard 5-meter system fully complies with the American Petroleum Institute (API) 670 requirements for mechanical configuration, linear range, and accuracy.
  • Hazardous Area Approvals (Option 05): The "05" suffix in your specific part number indicates global agency approvals.
  • CE Mark: Satisfies European electromagnetic immunity (RFI/EMI) requirements without needing special shielded conduit.
  • Monitoring System Updates: If upgrading from older systems (like the 7200 series) to the 3300 XL, you must update your 3500 Monitoring System configuration software to recognize the new transducer.
  • Hardware Compatibility: All components (probe, extension cable, and Proximitor sensor) are backward compatible and interchangeable with other 3300 series 5 mm and 8 mm components.
Description
The Bently Nevada 330103-00-07-10-12-05 3300 XL 8 mm proximity probe features a FluidLoc cable and a Miniature coaxial ClickLoc connector, providing reliable liquid protection for harsh industrial environments. It has a total length of 1.0 meter (3.3 feet), a housing length of 70 mm, and a 0 mm unthreaded section length.

The probe tip is made of polyphenylene sulfide (PPS), and the body is constructed of AISI 303 or 304 stainless steel, allowing for safe operation and storage within a temperature range of -52°C to +177°C (-62°F to +350°F). Optional armor protection is available with a flexible AISI 302 or 304 SST jacket with an FEP outer sheath for enhanced durability.

The probe has a rated DC resistance to meet the requirements of high-precision vibration and position measurements and is CSA, ATEX, and IECEx certified, ensuring safe and reliable use in industrial environments.
Alternative Names
33O1O3-OO-O7-1O-12-O5 330I03-00-07-I0-I2-05 3301030007101205 33O1O3OOO71O12O5 330I030007I0I205
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Does the 330103-00-07-10-12-05 come with a warranty?
Yes, the 330103-00-07-10-12-05 includes a free 1-year Apter Power warranty.
Is 330103-00-07-10-12-05 100% brand new?
Yes. New and original.
What is the probe tip material?
The tip material is polyphenylene sulfide (PPS).
What is the probe body material?
The body material is AISI 303 or 304 stainless steel.
What is the probe's operating and storage temperature range?
-52°C to +177°C (-62°F to +350°F).
What are the probe connector and cable types?
Uses a Miniature coaxial ClickLoc connector; the cable is a FluidLoc cable.
