        330105-XX-XX-10-02-05 MOD:157310-11
        330105-XX-XX-10-02-05 MOD:157310-11
        330105-XX-XX-10-02-05 MOD:157310-11
        330105-XX-XX-10-02-05 MOD:157310-11
        330105-XX-XX-10-02-05 MOD:157310-11
        330105-XX-XX-10-02-05 MOD:157310-11
        Ask our team:
        • Phone: +86 181 0690 9650
        • E-Mail sales1@apterpower.com

        • Lifecycle status

          Active / Available from OEM
          Apter Power delivers genuine Bently Nevada MOD 157310-11 reverse-mount sensors, ensuring reliable shaft displacement tracking tailored to your specific application.

        330105-XX-XX-10-02-05 MOD:157310-11

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        The Bently Nevada 330105-XX-XX-10-02-05 MOD:157310-11 Reverse Mount Probe is a custom-engineered eddy current proximity probe belonging to the industry-standard 3300 XL 8 mm series.
        In Stock
        Ships by Thursday, October 29
        Fast Shipping Available
        Get a quick price for 330105-XX-XX-10-02-05 MOD:157310-11
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 330105-XX-XX-10-02-05 MOD:157310-11

        • Manufacturer:
          Bently Nevada
        • Part Number:
          330105-XX-XX-10-02-05 MOD:157310-11
        • Product Family:
          3300 XL 8 mm Probe
        • Product Type:
          Reverse Mount Probe
        • Stock:
          1
        • Probe Diameter:
          8 mm
        • Operating Principle:
          Eddy Current
        • Measured Target:
          Conductive metal surface
        • Operating Voltage:
          -17.5 Vdc to -26 Vdc
        • Maximum Current:
          12 mA
        • Output Resistance:
          50 Ω
        • Power Supply Sensitivity:
          < 2 mV per volt
        • Power Supply Voltage:
          -24 Vdc
        • Weight:
          0.3 kg
        • Estimated shipping dimensions:
          20.4×22.2×3.7cm
        • Tariff Code:
          8537101190
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Specifications Use Cases Performance & Efficiency Firmware & Updates

        Features:

        • Eddy-Current Proximity Sensing with 8 mm Probe Tip and 3/8-24 UNF Threaded Case
        • Patented TipLoc and CableLoc Design for Enhanced Mechanical Bond and 330 N Pull Strength
        • Full API 670 Compliance with Complete Interchangeability Across 3300 XL System Components
        The Bently Nevada 330105-XX-XX-10-02-05 MOD: 157310-11 operates as a 3300 XL 8 mm Reverse Mount Probe within the eddy current proximity transducer system, providing accurate non-contact measurement of shaft vibration and displacement in rotating machinery. It continuously detects changes in the distance between the probe tip and the target surface, converting this into a precise electrical signal for monitoring systems. The 330105-XX-XX-10-02-05 MOD: 157310-11 incorporates a patented TipLoc molding method that delivers a more robust bond between the probe tip and the probe body compared to previous designs.

        The 330105-XX-XX-10-02-05 MOD: 157310-11 provides essential sensing functionality for machinery protection and condition monitoring, and is a critical component of the measurement path, directly affecting the accuracy and reliability of the overall monitoring system. One probe is required per measurement channel, with the 330105-XX-XX-10-02-05 MOD: 157310-11 installed using its 3/8-24 UNF threaded case and secured with a locknut at the specified mounting location.

        For complete system operation, the 330105-XX-XX-10-02-05 MOD: 157310-11 requires pairing with a matched 3300 XL Proximitor Sensor and extension cable to form a calibrated 5-meter, 7-meter, or 9-meter system. The probe delivers a nominal system sensitivity of 7.87 V/mm (200 mV/mil) when properly matched with compatible 3300 XL components.

        The 330105-XX-XX-10-02-05 MOD：157310-11 Bently Nevada Reverse Mount Probe may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
        Bently Nevada 330105-XX-XX-10-02-05 MOD：157310-11 Reverse Mount Probe Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        Bently Nevada 330105-XX-XX-10-02-05 MOD：157310-11 Reverse Mount Probe Specs

        General

        • Manufacturer Bently Nevada
        • Model 330105-XX-XX-10-02-05 MOD：157310-11
        • Condition New Original ready stock
        • Product Family 330105-XX-XX-10-02-05 MOD：157310-09,330105-02-12-15-12-CN
        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        • Fluid-Film Bearing Monitoring: Tracks the relative movement of the rotating shaft inside heavy machinery fluid bearings.
        • Radial Vibration Detection: Monitors high-frequency shaft dynamic vibration to detect issues like imbalance, misalignment, or rotor instability.
        • Axial Position Tracking: Measures micro-movements of the shaft along its axis to safeguard against rotor-to-stator collision.
        • Speed and Phase Referencing (Keyphasor): Detects a single notch or projection on a rotating shaft to provide critical timing signals for phase-angle evaluation and RPM tracking.
        • Confined Spaces: Used across industrial steam turbines, gas compressors, multi-stage pumps, and large industrial electric motors.
        • Linear Measurement Range: Offers a nominal linear tracking range of 2.0 mm (80 mils).
        • System Sensitivity: Delivers a standard scale factor output of 7.87 V/mm (200 mV/mil) when integrated with a matching 3300 XL Proximitor sensor.
        • Frequency Response: Functions reliably from 0 Hz (static DC displacement) up to 10 kHz (dynamic target observation).
        • Mechanical Integrity: Features a patented TipLoc molding process for a reinforced bond between the polyphenylene sulfide (PPS) probe tip and the stainless steel body, offering a CableLoc tensile pull-strength of up to 330 N (75 lbf).
        • Thermal Resilience: Designed to withstand harsh process temperatures ranging from -52°C to +177°C (-62°F to +350°F) under standard conditions.
        • Interchangeability: Fully meets API 670 standards, which allows the probe to be hot-swapped or extended without the need for manual bench calibration.
        • Transducer Configuration: Linearity adjustments and target material calibrations are processed directly inside the 3300 XL Proximitor Sensor hardware, which requires zero code upgrades.
        • Monitoring System Firmware: To update data acquisition parameters, alert limits, or scaling algorithms, updates must be pushed directly to connected monitoring modules, such as the Bently Nevada 3500 Monitoring System using 3500 Rack Configuration Software.
        Description
        The Bently Nevada 330105-XX-XX-10-02-05 MOD:157310-11 Reverse Mount Probe is a precision-engineered proximity probe designed for industrial vibration monitoring and machinery protection systems. The 330105-XX-XX-10-02-05 MOD:157310-11 features a reverse mount configuration that enables installation from the interior side of machine housings, making the 330105-XX-XX-10-02-05 MOD:157310-11 particularly suitable for applications where external mounting space is restricted or inaccessible. This reverse mount probe, designated as 330105-XX-XX-10-02-05 MOD:157310-11, is manufactured to meet the rigorous demands of continuous condition monitoring in rotating equipment environments.

        This 330105-XX-XX-10-02-05 MOD:157310-11 Reverse Mount Probe is specifically designed to address the challenge of monitoring shaft vibration and position in machinery with limited external access or confined installation clearances. The 330105-XX-XX-10-02-05 MOD:157310-11 solves the problem of implementing reliable proximity sensing in turbines, compressors, and pumps where conventional forward-mount probes cannot be physically accommodated. By utilizing the reverse mount design of the 330105-XX-XX-10-02-05 MOD:157310-11, maintenance teams can achieve accurate displacement measurement without requiring extensive machine disassembly or structural modifications.

        The 330105-XX-XX-10-02-05 MOD:157310-11 finds application across multiple industrial sectors, including power generation, oil and gas processing, petrochemical refining, and heavy manufacturing. In power plants, the 330105-XX-XX-10-02-05 MOD:157310-11 is deployed for monitoring steam and gas turbine rotor dynamics. The 330105-XX-XX-10-02-05 MOD:157310-11 is also widely used in centrifugal compressor stations and large motor-pump assemblies where continuous vibration surveillance is critical for operational safety. Additionally, the 330105-XX-XX-10-02-05 MOD:157310-11 serves essential roles in paper mills, steel rolling mills, and marine propulsion systems requiring robust proximity measurement solutions.
        Alternative Names
        33O1O5-XX-XX-1O-O2-O5 MOD:15731O-11 330I05-XX-XX-I0-02-05 MOD:I57310-II 330105 XX XX 10 02 05 330105-XX-XX-10-02-00 330105-XX-XX-10-02-CN 330105-XX-XX-10-02-BR 330105-XX-XX-10-02-RU 330105-02-12-05-02-00
        Technical notes
        The Bently Nevada 330105-XX-XX-10-02-05 MOD:157310-11 is precisely customized with the factory-specified modification code MOD: 157310-11, so it offers the same electrical performance as the standard 3300 XL probe while having a unique physical layout, which is crucial for dedicated industrial machinery interfaces.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        What measurements can the 330105-XX-XX-10-02-05 MOD:157310-11 perform?
        The probe is designed to monitor dynamic shaft vibration and static axial shaft position in fluid-film bearing machines, providing accurate displacement data for machinery protection and condition monitoring systems.
        How is the 330105-XX-XX-10-02-05 MOD:157310-11 : 157310-11 installed?
        The probe is threaded into a compatible reverse-mount probe housing or mounting sleeve from the exterior of the machine casing. This installation method provides convenient access while maintaining accurate probe positioning.
        What components are required for a complete monitoring system?
        The probe is used with a compatible Bently Nevada 3300 XL extension cable and a 3300 XL Proximitor® Sensor. Together, these components form a complete proximity transducer system that delivers signals to machinery protection and condition monitoring platforms.
