330232-05-05-12-05

/ 4.9
1001 reviews | Need a Specific Revision?
The Bently Nevada 330232-05-05-12-05 Button Probe is a right-angle proximity probe designed for tight-space applications, featuring a rugged 90° PPS and stainless steel tip assembly for reliable vibration and thrust position monitoring. It provides seamless compatibility with 3300 XL 8 mm Proximitor sensors, ensuring easy integration into existing systems.
Get a quick price for 330232-05-05-12-05
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330232-05-05-12-05

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330232-05-05-12-05
  • Product Family:
    3300 XL 8 mm Probe
  • Probe Type:
    Right-angle / button-style proximity probe
  • Tip Assembly:
    90° molded polyphenylene sulfide (PPS) and stainless steel
  • Tip Height:
    8.4 mm (0.33 in)
  • Linear Range:
    80 mil (≈2.03 mm)
  • Scale Factor:
    200 mV/mil
  • Compatibility:
    Compatible with Bently Nevada 3300 XL 8 mm Proximitor sensors and extension cables
  • Operating Temperature:
    -51°C to +177°C (-60°F to +350°F)
  • Cable Type:
    FluidLoc® coaxial cable (prevents oil wicking)
  • Construction:
    Robust molded PPS + stainless steel; more rugged than all-fiberglass tips
  • Mounting Options:
    Standard button probe package; compatible with custom probe cases or brackets
  • Weight:
    0.04 kg
  • Estimated shipping dimensions:
    1.6x1.6x76cm
  • Tariff Code:
    6602000090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Protection Upgrade Application Scenarios

Features:

  • Flexible Right-Angle Tip Design – Standard 90° tip assembly allows installation in tight spaces without custom engineering.
  • Robust PPS and Stainless Steel Construction – Engineered for durability, outperforming all-fiberglass probes.
  • Wide Range and System Compatibility – 80 mil linear range, 200 mV/mil scale factor, compatible with 3300 XL 8 mm Proximitor sensors. Introductory Paragraphs
The Bently Nevada 330232-05-05-12-05 Button Probe combines high-performance sensing with a compact design suitable for demanding industrial applications. Its 90° molded PPS and stainless steel tip provides exceptional durability while maintaining a minimal tip height of 8.4 mm, allowing it to fit into existing button probe installations or customized brackets.

Designed for integration with Bently Nevada 3300 XL systems, the 330232-05-05-12-05 Button Probe supports both radial vibration and thrust position measurements. Its 80 mil linear range and 200 mV/mil scale factor make it a versatile solution for a variety of machinery monitoring needs, simplifying maintenance and spare parts management across facilities.

With FluidLoc® coaxial cables and an extended operating temperature range of -51°C to +177°C, this probe ensures reliable performance in harsh environments. The standardized design shortens lead times and reduces the complexity of installation, making the 330232-05-05-12-05 Button Probe a preferred choice for both legacy upgrades and new equipment setups.

The 330232-05-05-12-05 Bently Nevada Button Probe may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330232-05-05-12-05 Button Probe Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330232-05-05-12-05 Button Probe Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330232-05-05-12-05
  • Condition New Original ready stock
  • Product Family 330232-05-08-12-00,330232-06-05-12-CN,330102-00-13-10-01-00
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Connector Protection: Button probe connectors are extremely fragile. Connector protectors (transparent sleeves) or heat shrink tubing must be used to prevent oil and moisture from entering the connector and causing signal drift.
  • Physical Clearance: When installed inside bearing housings, ensure the cable routing is not rubbed against the rotor or rotating parts. Wear and tear on the cable sheath can lead to shielding failure and data errors.
  • Cable Securing: Use stainless steel cable clamps to secure the cable and prevent metal fatigue or breakage at the cable root due to vibration during operation.
  • Environmental Sealing: If installed in an oil mist chamber, ensure the cable sealing glands are intact to prevent lubricating oil from flowing along the cable to the external instrument box.
  • Series Migration: This probe is from the 3300 XL series and can directly replace the older 7200 or 3300 5mm/8mm button probes, providing better linearity and wider temperature stability.
  • Material Upgrade: If the environment has extremely strong chemical corrosion, it is recommended to upgrade to the 330231 (All-PPS) model, whose all-plastic construction offers better corrosion resistance.
  • Armor Upgrade: If the field cabling lacks protective conduit, consider replacing it with an extension cable with SST armor to enhance resistance to mechanical damage and rodent bites.
  • System Integration: It is recommended to use it with the 3300 XL Proximitor and connect it to the 3500 system or Orbit 60 for a higher level of waveform analysis and self-diagnostic capabilities.
  • Confined Space Installation: Specifically designed for areas where standard 3/8-24 or M10 probes cannot be installed vertically due to height limitations (e.g., inside compact radial bearings).
  • 90-Degree Mounting: Suitable for situations where the probe mounting hole is perpendicular to the rotor axis and there is insufficient external space to accommodate a long probe body.
  • Small Machine Radial Vibration: Commonly used inside the housings of small motors, pumps, or centrifuges to directly monitor the radial vibration of the rotor journal.
  • Thrust/Axial Position Assisted Monitoring: Utilizing the flatness of a button probe to measure axial displacement in certain customized thrust bearing blocks.
Description
The Bently Nevada 330232-05-05-12-05 Button Probe delivers a compact and robust solution for machinery monitoring where space constraints limit conventional probe placement. Its 90° molded polyphenylene sulfide (PPS) and stainless steel tip assembly provides enhanced durability over all-fiberglass designs, allowing installation in challenging industrial environments without compromising performance.

This probe supports an 80 mil linear range and a 200 mV/mil scale factor, making it suitable for both radial vibration and thrust position measurements. With a tip height of just 8.4 mm (0.33 in), it fits into standard button probe packages while also accommodating custom probe cases or brackets. Its compatibility with Bently Nevada 3300 XL 8 mm Proximitor sensors and extension cables simplifies spare parts management and system maintenance.

Operating across a wide temperature range of -51°C to +177°C (-60°F to +350°F), the 330232-05-05-12-05 Button Probe can withstand extreme conditions encountered in turbines, compressors, and other rotating equipment. The integrated FluidLoc® coaxial cable prevents oil wicking, protecting both the sensor and surrounding equipment from contamination.

The new 90° tip assembly offers faster manufacturing and delivery times compared to previous custom-engineered right-angle probes. Its flexible design allows it to replace older button probes, integrate into existing installations, or adapt to specialized mounting configurations. Bently Nevada continues to supply the all-PPS button probe (part number 330231) for customers preferring legacy designs, while the 330232-05-05-12-05 Button Probe represents the most advanced, versatile option for tight-space monitoring.

Industrial users benefit from its improved robustness, extended range, and standardized configurations, making the 330232-05-05-12-05 Button Probe an ideal choice for both new installations and upgrades of legacy 3300 XL systems.
Alternative Names
330232-05-10-12-00 330232-05-08-12-05 330232-05-12-12-05 330232-06-05-12-05 330104-00-05-10-02-05 330102-00-13-10-01-00
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Why is the 90° tip assembly important?
The 90° tip allows installation in tight spaces without requiring custom engineering, improving delivery times and flexibility.
What temperature ranges can the 330232-05-05-12-05 Button Probe handle?
It operates reliably from -51°C to +177°C (-60°F to +350°F), suitable for extreme industrial environments.
How does this probe compare to older button probes?
The 330232-05-05-12-05 Button Probe offers a more rugged tip, standardized 90° design, and shorter lead times, while maintaining compatibility with 3300 XL sensors.
Can it be used with custom mounting brackets?
Yes, its flexible design allows integration into both standard button probe packages and custom probe cases or brackets.
