330130-045-02-00

/ 4.9
1001 reviews | Need a Specific Revision?
Bently Nevada 330130-045-02-00 is a 3300 XL standard extension cable with a connector protector, featuring a 4.5-meter (14.8 feet) cable length, precise resistance parameters, and compatibility with multiple 3300 XL and non-XL transducer system components, supporting stable signal transmission for eddy current proximity measurements.
Get a quick price for 330130-045-02-00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330130-045-02-00

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330130-045-02-00
  • Product Family:
    3300 XL Extension Cable
  • Cable Length Option:
    4.5 meters (14.8 feet)
  • Connector Protector and Cable Option:
    Standard cable with connector protector
  • Agency Approval Option:
    Not required
  • Nominal Extension Cable DC Resistance:
    0.99 ± 0.15 Ω
  • Resistance (RJACKET ) from Outer Conductor to Outer Conductor:
    0.30 ± 0.06 Ω
  • Weight:
    0.16 kg
  • Estimated shipping dimensions:
    22.8x2.2x22.5cm
  • Tariff Code:
    8486403900
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Certifications Compatibility

Features:

  • 4.5-meter (14.8 feet) length provides extended reach between probe and Proximitor sensor, eliminating the need for custom cable lengths in many installations.
  • Gold-plated brass ClickLoc connectors lock securely with finger-tight torque, preventing loosening in high-vibration environments without requiring special tools.
  • Standard cable construction with connector protector offers reliable signal transmission and environmental sealing for general-purpose industrial applications.
The 330130-045-02-00 is designed to provide the critical link between 3300 XL 8 mm proximity probes and Proximitor sensors in configurations where the sensor must be located at a distance from the measurement point. Its 4.5-meter (14.8 feet) length offers a practical solution for installations where a standard 1.0-meter probe cable is insufficient but a full 8.0-meter extension is unnecessary.

The 330130-045-02-00 features gold-plated brass ClickLoc connectors that lock securely with simple finger-tight torque, eliminating the need for special installation tools while ensuring connections remain stable in high-vibration applications. This locking mechanism is particularly valuable on rotating machinery such as turbines, compressors, and generators, where standard connectors can loosen over time, leading to signal degradation or intermittent faults.

The 330130-045-02-00 includes a connector protector that provides a built-in barrier against moisture, dust, and light washdown exposure at the critical connection point. This feature is essential for installations in humid environments or where cables must be routed through conduit, as it prevents contaminants from compromising the electrical connection.

The 330130-045-02-00 Bently Nevada 3300 XL Standard Extension Cable may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 330130-045-02-00 3300 XL Standard Extension Cable Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330130-045-02-00 3300 XL Standard Extension Cable Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330130-045-02-00
  • Condition New Original ready stock
  • Product Family 330130-045-01-00,330130-045-11-00,330130-045-02-05
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Key Equipment Protection: Primarily used for monitoring machines equipped with fluid-film bearings, such as large steam turbines, generators, centrifugal compressors, and large pumps.
  • Measurement Tasks: Supports radial vibration, axial displacement, eccentricity, and speed measurement (including overspeed protection).
  • Institutional Certification: The code 00 at the end indicates "Not required," typically used for non-hazardous areas.
  • API Standard: Designed to comply with API 670 specifications.
  • General Industrial Certifications: Although this model does not come with optional explosion-proof certification, this product series generally complies with CE, UL, and ISO 9001 quality system standards.
  • Backward Compatibility: Electrically and physically interchangeable with non-XL series 3300 series 5 mm and 8 mm sensor components.
  • System Integration: Specifically designed for seamless integration with the 3300 XL 8 mm probe and 3300 XL Proximitor sensor.
  • Third-Party Interoperability: Offers some compatibility with third-party components conforming to the same standards, such as the Metrix MX2031 extension cable.
Description
The Bently Nevada 330130-045-02-00 is a 3300 XL standard extension cable designed to ensure reliable and precise connectivity within the 3300 XL 8 mm eddy current proximity transducer system. It features a fixed cable length of 4.5 meters (14.8 feet) and a standard cable configuration with connector protector, providing effective protection for the connector from external environmental damage while extending the cable’s service life. The cable’s nominal DC resistance is 0.99 ± 0.15 Ω and the resistance from outer conductor to outer conductor (RJACKET) is 0.30 ± 0.06 Ω, delivering highly accurate and stable signal transmission to guarantee the measurement precision of the system.

As a core component of the 3300 XL 8 mm transducer system, the 330130-045-02-00 fully supports industry-leading performance. When combined with the standard 5-meter 3300 XL system, it complies with API 670 standards, meeting stringent requirements for mechanical configuration, linear range, accuracy, and temperature stability. Its precise resistance characteristics and stable transmission enable seamless cooperation with probes and Proximitor sensors, providing solid support for the efficient operation of the entire system.

The 330130-045-02-00 also excels in compatibility and interchangeability, significantly reducing user installation and maintenance costs. All components in the 3300 XL 8 mm proximity transducer system—including probes, extension cables, and Proximitor sensors paired with 330130-045-02-00—are fully interchangeable, eliminating the need for individual component matching or bench calibration. This simplifies installation and commissioning while ensuring consistent performance across the system.

Furthermore, the 3300 XL 8 mm series components are backward compatible with non-XL 3300 series 5 mm and 8 mm components, including the 3300 5 mm probe. In scenarios where the 8 mm probe cannot be accommodated due to limited space, the 5 mm probe can be used with the 330130-045-02-00, maintaining stable compatibility and signal transmission. This ensures the cable’s adaptability to diverse installation environments and multi-scenario industrial applications.
Alternative Names
330130-045-02-05 330130-045-02-CN 330130-045-02-BR 330130-045-02-RU 330130-045-01-00 330130-045-12-00 3301300450200
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the cable length of Bently Nevada 330130-045-02-00?
The cable length option is 4.5 meters (14.8 feet).
What type of cable configuration does it use?
It is a standard cable with connector protector.
Is Bently Nevada 330130-045-02-00 currently in stock?
Yes, it is generally in stock. Real-time inventory can be checked, supporting quick response to urgent procurement needs.
What is the nominal extension cable DC resistance?
The nominal DC resistance is 0.99 ± 0.15 Ω.
