330130-075-10-05

/ 4.9
1001 reviews | Need a Specific Revision?
The Bently Nevada 330130-075-10-05 Extension Cable is a high-performance component designed for use within the 3300 XL 8 mm proximity transducer system.
Get a quick price for 330130-075-10-05
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330130-075-10-05

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330130-075-10-05
  • Product Family:
    3300 XL Extension Cable
  • Capacitance:
    69.9 pF/m (21.3 pF/ft) typical
  • Output Resistance:
    50 Ω
  • Power Requirement:
    −17.5 Vdc to −26 Vdc
  • Maximum Current Consumption:
    12 mA
  • Cable Length Option:
    7.5 meters
  • Connector Protector and Cable Option:
    FluidLoc cable
  • Agency Approval Option:
    CSA, ATEX, IECEx Approvals
  • Probe Tip Material:
    Polyphenylene sulfide
  • Probe Case Material:
    AISI 303 or 304 stainless steel(SST)
  • Weight:
    0.25 kg
  • Estimated shipping dimensions:
    20x20x2.5cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Product Applications Diagnostics Installation

Features:

  • High-Reliability Extension Cable For Accurate Signal Transmission Between Proximity Probe And Sensor.
  • 7.5 Meter Cable With FluidLoc Connector For Enhanced Environmental Protection.
  • Designed For Seamless Integration With 3300 XL System And Long-Term Industrial Operation.
The 330130‑075‑10‑05 Extension Cable provides a secure and precise connection between Bently Nevada 3300 XL proximity probes and Proximitor sensors. Its robust design ensures minimal signal loss and accurate transmission of vibration and displacement data in critical machinery monitoring applications.

With a 7.5 meter length and integrated FluidLoc connector, this cable offers enhanced protection against fluid ingress, mechanical stress, and electrical interference. Its construction ensures reliable operation in harsh industrial environments, including turbines, compressors, and generators.

Fully compatible with the 3300 XL monitoring system, the cable supports predictive maintenance strategies by maintaining accurate sensor signals over long distances. Its durable build and precision engineering contribute to reduced downtime and extended equipment life.

The 330130-075-10-05 Bently Nevada 3300 XL Standard Extension Cable may still be available for purchase and support from authorized distributors beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330130-075-10-05 3300 XL Standard Extension Cable Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330130-075-10-05 3300 XL Standard Extension Cable

General

  • Manufacturer GE / Bently Nevada
  • Model 330130-075-10-05
  • Condition New Original ready stock
  • Product Family 330130-075-10-00,330130-075-10-CN,330130-075-10-BR
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Vibration Monitoring: Tracking radial vibration on rotating shafts to identify mechanical issues like unbalance or misalignment.
  • Axial Position Measurement: Monitoring the thrust position of a shaft to prevent internal machine contact and failure.
  • Keyphasor & Speed Sensing: Providing essential timing and speed data for phase reference in rotating machinery.
  • FluidLoc Seal: Since this is a -10 (FluidLoc) cable, inspect the jacket for swelling or softening. While designed to prevent internal wicking, external chemical exposure can still degrade the outer insulation.
  • Connector Condition: Check the gold-plated ClickLoc connectors for corrosion, moisture, or bent pins. Ensure the connector protector is intact and free of debris.
  • Armor/Jacket Integrity: Look for kinks, sharp bends, or frayed shielding. A breach in the shield often leads to "noise" in the vibration signal.
  • Total Length: This 7.5-meter cable must be paired with a 1.5-meter probe to create a standard 9.0-meter system.
  • Proximitor Pairing: Connect only to a 9.0m 3300 XL Proximitor Sensor. Using it with a 5.0m sensor or a different probe length will cause significant calibration errors.
  • Finger-Tight Only: Join the probe and extension cable connectors by hand. You will feel/hear a "click" when locked. Never use pliers, as crushing the dielectric changes the electrical impedance.
Description
This model features a 7.5 meter cable length and incorporates advanced FluidLoc and CableLoc technologies, which enhance connection stability and prevent fluid ingress in harsh industrial environments. Its robust construction and shielding design help maintain signal integrity while minimizing electrical interference.

Engineered to meet stringent industrial standards, the extension cable supports precise measurement of shaft position and vibration when used as part of a complete transducer system. It is widely applied in turbines, compressors, and other rotating equipment, contributing to reliable condition monitoring and reduced maintenance downtime.

The system provides an output voltage that is directlyproportional to the distance between the probe tip and theobserved conductive surface and can measure both static(position) and dynamic (vibration) values. The system’sprimary applications are vibration and positionmeasurements on fluid-film bearing machines, as well asKeyphasor reference and speed measurements.

Each 3300 XL 8 mm Transducer System component isbackward compatible and interchangeable4 with other nonXL 3300 series 5 mm and 8 mm transducer systemcomponents5. This compatibility includes the 3300 5 mmprobe, for applications in which an 8 mm probe is too largefor the available mounting space.
Alternative Names
330130-075-10-00 330130-075-10-BR 330130-075-10-CN 330130-075-10-RU
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What Is The Cable Length Of The 330130-075-10-05 Extension Cable?
The cable has a total length of 7.5 meters (24.6 feet), suitable for standard industrial installations.
What Type Of Connector Protection Does This Cable Use?
It features a FluidLoc sealing design, which helps prevent fluid ingress and improves reliability in harsh environments.
What Are The Typical Electrical Characteristics Of This Cable?
The cable provides approximately 69.9 pF/m capacitance and 50 Ω resistance, ensuring stable signal transmission.
