330901-00-09-70-02-05

/ 4.9
1001 reviews | Need a Specific Revision?
The Model 330901-00-09-70-02-05 is a 3300 NSv proximity probe featuring 1/4-28 UNF mounting threads without armor, designed for process compressor applications requiring enhanced chemical resistance and extended 7.0 meter cable length.
Get a quick price for 330901-00-09-70-02-05
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330901-00-09-70-02-05

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330901-00-09-70-02-05
  • Product Family:
    NSV Probe
  • Mounting Thread:
    1/4-28 UNF
  • Unthreaded Length:
    0.0 in
  • Overall Case Length:
    0.9 in
  • Total Length:
    7.0 meters (23.0 feet)
  • Connector Type:
    Miniature coaxial ClickLoc
  • Cable Type:
    Standard cable
  • Chemical Resistance:
    Increased vs. 3300 RAM
  • Agency Approvals:
    Multiple Approvals
  • Pain Point Solved:
    The 330901-00-09-70-02-05 provides 7.0 meter cable length eliminating extension cable connection points that can fail in corrosive environments. Ultra-compact 0.9 in case fits tight spaces while increased chemical resistance prevents probe degradation from aggressive process media.
  • Weight:
    0.05 kg
  • Estimated shipping dimensions:
    1.2x1x117cm
  • Tariff Code:
    9031900090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manual Specifications

Features:

  • 3300 NSv proximity probe with 1/4-28 UNF threads and ultra-compact 0.9-inch case for tight installations
  • Extended 7.0-meter integral cable eliminating extension cable connection points
  • Increased chemical resistance with multiple hazardous area approvals for process compressor applications
The 330901-00-09-70-02-05 provides essential sensing functions critical to the entire monitoring path, serving as the primary interface between process compressors and the monitoring system, directly affecting the proper, normal operation of the overall protection system. One 330901-00-09-70-02-05 probe is required per measurement point, installed flush in the compressor casing with the 1/4-28 UNF mounting threads.

For applications requiring enhanced chemical resistance in aggressive process environments, the 330901-00-09-70-02-05 offers increased resistance compared to previous 3300 RAM probes, allowing reliable operation with corrosive media exposure. In addition to standard signal transmission, the superior side-view characteristics of the 330901-00-09-70-02-05 provide better performance than 3000-series 190 probes when gapped at the same distance from the target.

The 330901-00-09-70-02-05's rugged construction ensures reliable operation in demanding process compressor environments. Using enhanced materials for chemical resistance and precision manufacturing, the probe delivers consistent performance over extended periods. The multiple hazardous area approvals carried by the 330901-00-09-70-02-05 certify its suitability for installation in potentially explosive atmospheres.

The 330901-00-09-70-02-05 Bently Nevada 3300 NSv Proximity Probes may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 330901-00-09-70-02-05 3300 NSv Proximity Probes Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330901-00-09-70-02-05 3300 NSv Proximity Probes Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330901-00-09-70-02-05
  • Condition New Original ready stock
  • Product Family 330901-00-09-70-01-05,330901-00-09-70-12-05,330901-00-09-70-02-00
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Description
The Model 330901-00-09-70-02-05 is a specialized 3300 NSv proximity probe featuring 1/4-28 UNF mounting threads with extended 7.0 meter cable length for remote monitoring applications. This ultra-compact configuration includes 0.9 in overall case length with zero unthreaded flush-mount design. The 330901-00-09-70-02-05 carries multiple agency approvals for hazardous area installations worldwide.

Chemical resistance is a significant advantage of the 330901-00-09-70-02-05 compared to previous probe generations. This NSv probe offers increased chemical resistance relative to the earlier 3300 RAM probe for process compressor applications. The 330901-00-09-70-02-05 maintains side-view characteristics superior to 3000-series 190 probes when gapped at the same distance from the target.

The 7.0 meter cable length of the 330901-00-09-70-02-05 eliminates need for extension cables in remote installations, reducing connection points and potential failure sources. Gold-plated brass ClickLoc connectors enable tool-free installation with secure vibration-resistant locking. The 330901-00-09-70-02-05 delivers reliable signal transmission for critical machinery monitoring over extended distances.

System compatibility is a key feature of the 330901-00-09-70-02-05, which is interchangeable with Bently Nevada's previous 3300 RAM probe systems. This backward compatibility allows seamless integration into existing monitoring installations. The 330901-00-09-70-02-05 combines enhanced chemical resistance with extended cable reach for demanding process applications.
Alternative Names
330901-00-09-70-01-05 330901-00-09-70-11-05 330901-00-09-70-12-05 330901-00-09-70-02-00
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the difference between the 330901-00-09-70-02-05 with 7.0 meter cable and a standard 1.0 meter NSv probe with separate extension cable?
The 330901-00-09-70-02-05 features an integral 7.0 meter cable eliminating the need for a separate extension cable and the connection point between probe and extension. This reduces potential failure sources by 50% and simplifies installation in remote monitoring applications. Both offer identical chemical resistance and side-view characteristics, but the 330901-00-09-70-02-05 provides superior reliability where connection points are vulnerable to corrosion or mechanical stress.
How to identify a reliable supplier for the 330901-00-09-70-02-05?
A reliable supplier should provide documented traceability of multiple agency approvals, verify the 7.0 meter cable length and 0.9 in ultra-compact case specifications, and demonstrate knowledge of NSv chemical resistance benefits for process compressors. They must explain the advantage of integral extended cable over separate extension cables. Look for suppliers who can provide actual test documentation for the 7.0 meter signal integrity. Avoid suppliers who cannot explain why the ultra-compact 0.9 in case is beneficial for tight installations or lack understanding of hazardous area requirements.
What certifications are required when exporting the 330901-00-09-70-02-05 to the United States?
The 330901-00-09-70-02-05 carries multiple agency approvals including CSA which is accepted in the US through CSA/US mutual recognition. Export documentation must include country of origin, product value declaration, and HTS classification. The hazardous area approvals satisfy NEC requirements for Class I locations when properly installed. No additional FCC or UL certifications are required for this passive sensor device. Importers should verify that the 7.0 meter cable length meets any specific installation requirements for their application.
Why do standard proximity probes fail in remote monitoring applications while the 330901-00-09-70-02-05 survives?
Standard probes fail from corrosion at extension cable connection points, signal degradation across multiple connectors, and mechanical stress on junction points. The 330901-00-09-70-02-05 survives with integral 7.0 meter cable eliminating vulnerable connection points, increased chemical resistance protecting against process media, and ultra-compact 0.9 in case allowing installation in tight spaces without stress. The gold-plated brass ClickLoc connectors on the single remaining connection resist corrosion where standard connectors fail, while multiple agency approvals ensure materials withstand environmental conditions that cause standard probe degradation.
