330901-00-10-02-00-02

/ 4.9
1001 reviews | Need a Specific Revision?
The 330901-00-10-02-00-02 is a 3300 NSv Proximity Probe featuring a 1/4-28 UNF thread without armor. This model includes an overall case length of 1.0 inch and unthreaded length of 0.0 inches.
Get a quick price for 330901-00-10-02-00-02
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330901-00-10-02-00-02

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330901-00-10-02-00-02
  • Product Family:
    NSV Probe
  • Product Type:
    3300 NSv Proximity Probe
  • Thread Type:
    1/4-28 UNF (without armor)
  • Unthreaded Length:
    0.0 inches
  • Overall Case Length:
    1.0 inch
  • Connector Type:
    Miniature coaxial ClickLoc™
  • Connector Material:
    Gold-plated brass
  • Agency Approval:
    Not specified (varies by configuration)
  • Key Benefit:
    Model 330901-00-10-02-00-02 addresses measurement accuracy challenges in confined spaces with superior side-view characteristics versus 3000-series 190 probes.
  • Weight:
    0.05 kg
  • Estimated shipping dimensions:
    1.2x1x117cm
  • Tariff Code:
    8525891900
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Firmware and Updates Configuration and Programming

Features:

  • The 330901-00-10-02-00-02 features a 1/4-28 UNF thread configuration without armor for standard UNF mounting applications.
  • This model includes a compact 1.0-inch overall case length for space-constrained installations.
  • The 330901-00-10-02-00-02 offers increased chemical resistance for process compressor applications.
The 330901-00-10-02-00-02 is mechanically and electrically compatible and interchangeable with Bently Nevada's previous 3300 RAM proximity probe designs. This NSv probe features increased chemical resistance compared to the 3300 RAM probe, allowing its use in many process compressor applications where exposure to aggressive media is common. The 330901-00-10-02-00-02 enables seamless upgrades from legacy 3300 RAM installations while providing enhanced durability in chemically challenging environments.

The side-view characteristics of the 330901-00-10-02-00-02 are superior to those of the 3000-series 190 probe when gapping at the same distance from the probe target. This improved performance enables more accurate measurements in confined spaces and applications where probe orientation presents challenges. The 330901-00-10-02-00-02 features reliable ClickLoc connector technology with gold-plated brass contacts for secure field connections.

The 330901-00-10-02-00-02 represents a complete solution for applications requiring 1/4-28 UNF mounting threads with enhanced chemical resistance in a compact 1.0-inch package. This NSv probe delivers reliable vibration and position monitoring while the increased chemical resistance and superior side-view characteristics ensure long-term performance in demanding process environments. The 330901-00-10-02-00-02 maintains compatibility with legacy systems while providing significant performance improvements in a smaller form factor.

The 330901-00-10-02-00-02 Bently Nevada 3300 NSv Proximity Probes may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 330901-00-10-02-00-02 3300 NSv Proximity Probes Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330901-00-10-02-00-02 3300 NSv Proximity Probes Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330901-00-10-02-00-02
  • Condition New Original ready stock
  • Product Family 330901-00-10-02-01-02,330901-00-10-02-02-02,330901-00-10-02-00-05
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Space-Confined Monitoring: Due to the small magnetic field area of ​​the NSv probe, it is suitable for narrow locations where a standard 8mm probe cannot be installed.
  • Small Shaft Diameter Measurement: Primarily used for shafts with diameters less than 9.5 mm (0.375 inches) to measure radial vibration and axial displacement.
  • Centrifugal Air Compressors: Monitoring high-speed rotor stability.
  • No firmware updates available: This device uses pure analog circuitry (hard-wired logic) to convert gap changes sensed by the probe into voltage signals (standard 7.87 V/mm or 200 mV/mil). Therefore, it does not have rewritable firmware and does not require software updates.
  • Hardware iteration: If system performance improvements or functional changes are needed, the entire preamplifier hardware typically needs to be replaced, rather than through a software upgrade.
  • Maintenance recommendations: Although there are no firmware updates, regular calibration checks are necessary to ensure the analog output profile remains within the manufacturer's specifications (linearity typically between 0.25mm and 1.25mm).
  • Monitoring Framework Setup: When connecting to the Bently Nevada 3500 framework, the correct sensor type (3300 NSv) must be selected in the 3500 Rack Configuration software, and the corresponding scale factor must be set.
  • Physical Alignment: The configuration process mainly involves adjusting the probe mounting gap during installation. Typically, the preamplifier output voltage is adjusted to the linear midpoint (approximately -7.0 to -9.0 VDC) to obtain the optimal dynamic measurement range.
  • Programming Requirements: This hardware is not programmable. All logical controls, alarm limits (Alert/Danger), and data trend analysis are performed in back-end monitors (such as 3500/42M) or automation systems (DCS/PLC).
Description
The 330901-00-10-02-00-02 features a 1/4-28 UNF thread configuration without armor, providing installation flexibility for applications requiring standard UNF mounting threads in a compact 1.0-inch case length. This model includes an overall case length of 1.0 inch with unthreaded length of 0.0 inches, offering a compact form factor for installations with limited space.

The 330901-00-10-02-00-02 is mechanically and electrically compatible and interchangeable with Bently Nevada's previous 3300 RAM proximity probe designs. This NSv probe features increased chemical resistance compared to the 3300 RAM probe, allowing its use in many process compressor applications where exposure to aggressive media is common.

The side-view characteristics of the 330901-00-10-02-00-02 are superior to those of the 3000-series 190 probe when gapping at the same distance from the probe target. This improved performance enables more accurate measurements in confined spaces and applications where probe orientation presents challenges.

With a compact 1.0-inch overall case length, the 330901-00-10-02-00-02 represents a complete solution for applications requiring 1/4-28 UNF mounting threads in space-constrained installations. This NSv probe delivers reliable vibration and position monitoring while the increased chemical resistance and superior side-view characteristics ensure long-term performance in demanding process environments.
Alternative Names
330901-00-10-02-01-02 330901-00-10-02-02-02 330901-00-10-02-11-02 330901-00-10-02-12-02
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What installation advantage does the 1.0-inch overall case length provide for the 330901-00-10-02-00-02?
The compact 1.0-inch case length allows installation in extremely tight spaces where standard longer probes cannot be accommodated, making it ideal for densely packed machinery configurations.
How does the 330901-00-10-02-00-02 improve upon previous 3300 RAM probe designs?
This NSv probe offers increased chemical resistance for process compressor applications and superior side-view characteristics, while maintaining complete mechanical and electrical interchangeability with RAM probes for seamless upgrades.
What makes the side-view characteristics of the 330901-00-10-02-00-02 superior to 3000-series probes?
Improved side-view response allows accurate gapping at the same distance as 190-series probes, enabling reliable measurements in confined spaces where optimal probe orientation cannot be achieved.
Can the 330901-00-10-02-00-02 be used to replace existing 3300 RAM probes in process compressors?
Yes, the 330901-00-10-02-00-02 is mechanically and electrically interchangeable with 3300 RAM probes, and its increased chemical resistance makes it particularly suitable for process compressor applications where chemical exposure is a concern.
