Features:
- The 330901-00-70-10-02-05 features a 1/4-28 UNF thread configuration without armor.
- This model includes an overall case length of 7.0 inches for extended reach applications.
- The 330901-00-70-10-02-05 offers increased chemical resistance for process compressor environments.
The 330901-00-70-10-02-05 is mechanically and electrically compatible and interchangeable with Bently Nevada's previous 3300 RAM proximity probe designs. This NSv probe features increased chemical resistance compared to the 3300 RAM probe, allowing its use in many process compressor applications where exposure to aggressive media is common. The 330901-00-70-10-02-05 enables seamless upgrades from legacy 3300 RAM installations while providing enhanced durability in chemically challenging environments.
The side-view characteristics of the 330901-00-70-10-02-05 are superior to those of the 3000-series 190 probe when gapping at the same distance from the probe target. This improved performance enables more accurate measurements in confined spaces and applications where probe orientation presents challenges. With multiple agency approvals, the 330901-00-70-10-02-05 simplifies global deployment in hazardous and non-hazardous locations.
The 330901-00-70-10-02-05 represents a complete solution for applications requiring 1/4-28 UNF mounting threads and enhanced chemical resistance with extended 7.0-inch case length. This NSv probe delivers reliable vibration and position monitoring while the increased chemical resistance and superior side-view characteristics ensure long-term performance in demanding process environments. The 330901-00-70-10-02-05 maintains compatibility with legacy systems while providing significant performance improvements.
The 330901-00-70-10-02-05 Bently Nevada 3300 NSv Proximity Probes may still be available for purchase and support from Apter Power beyond
End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330901-00-70-10-02-05 3300 NSv Proximity Probes Manuals,
Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not
included with this equipment unless listed in the above stock item description. All prices are
shown in USD.
Bently Nevada 330901-00-70-10-02-05 3300 NSv Proximity Probes Specs
General
- Manufacturer GE / Bently Nevada
- Model 330901-00-70-10-02-05
- Condition New Original ready stock
- Product Family 330901-00-70-10-01-05,330901-00-70-10-11-05,330901-00-70-10-02-00
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
- Key Monitoring: Used for measuring radial vibration and axial displacement.
- Main Industries: Widely used in steam turbines, compressors, and pumps in power generation, oil and gas, chemical, and general manufacturing industries.
- Small Shaft Diameter Applications: Particularly suitable for machines with small shaft diameters (typically less than 13 mm or 0.5 inches), its narrow lateral field of view reduces lateral metal interference.
- Continuous Protection: As part of a mechanical condition monitoring system, it provides real-time data to enable automatic equipment shutdown and protection against catastrophic damage.
- Diagnostic Functions: By analyzing the dynamic voltage signals output by the probe, engineers can diagnose faults such as imbalance, misalignment, bearing wear, or rotor friction.
- Circuit Protection: This probe is typically used in conjunction with the 3300 XL NSv Proximitor sensor and features electrostatic discharge (ESD) protection.
- Recommended Torque: The recommended installation torque is 5.1 N·m (45 in·lb).
- Gap Setting: An initial gap setting of 1.0 mm (40 mils) is recommended to ensure the sensor is within its optimal linear range (1.5 mm).
- Protection Measures: Connector protectors are recommended for field installations to enhance environmental protection.
