          Apter Power provides Bently Nevada 330910-00-10-10-01-05 quotations, technical resources and system-matching assistance.

        330910-00-10-10-01-05

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        Bently Nevada 330910-00-10-10-01-05 is an armored M10×1 3300 NSv proximity probe for non-contact vibration, position and phase-reference measurements in machinery with restricted installation space.
        In Stock
        Ships by Thursday, October 29
        Fast Shipping Available
        Get a quick price for 330910-00-10-10-01-05
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 330910-00-10-10-01-05

        • Manufacturer:
          Bently Nevada
        • Part Number:
          330910-00-10-10-01-05
        • Product Family:
          NSV Probe
        • Product Type:
          3300 NSv Proximity Probe
        • Stock:
          1
        • Thread Type:
          M10×1
        • Armor:
          Yes
        • Unthreaded Length:
          0 mm
        • Overall Case Length:
          100 mm
        • Total Probe Length:
          1.0 m (39 in)
        • Connector:
          Miniature coaxial ClickLoc
        • Connector Protection:
          Connector protector included
        • Cable Type:
          Standard cable
        • Probe Cable:
          75 Ω coaxial, FEP insulated
        • Probe Tip Material:
          Polyphenylene sulfide (PPS)
        • Probe Case Material:
          AISI 304 stainless steel
        • Connector Material:
          Gold-plated brass
        • Agency Approval Option:
          Multiple Approvals
        • Minimum Bend Radius:
          25.4 mm (1.0 in)
        • Recommended M10×1 Case Torque:
          11.3 N·m (100 in·lb)
        • Maximum M10×1 Thread Engagement:
          15 mm
        • Operating Temperature:
          -52°C to +177°C (-62°F to +351°F)
        • Storage Temperature:
          -52°C to +177°C (-62°F to +351°F)
        • Tariff Code:
          8414909090
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen, Fujian, China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Installation Construction Environment Applications

        Features:

        • Armored M10×1 standard-mount probe configuration for restricted installation spaces.
        • One-metre probe assembly with a 100 mm stainless-steel case.
        • Protected ClickLoc connection provides a secure probe-to-cable interface.
        330910-00-10-10-01-05 belongs to the narrow side-view probe range developed for installations where standard proximity probes have insufficient surrounding clearance.

        The selected ordering configuration combines zero unthreaded length with a 100 mm metric probe body, allowing the threaded section to extend along the configured case.

        Armor protects the probe lead mechanically, while the protected coaxial connection maintains the electrical interface with the corresponding NSv extension cable.

        The Bently Nevada 330910-00-10-10-01-05 3300 NSv Proximity Probe is supported by Apter Power for sourcing and system-matching requirements.
        Bently Nevada 330910-00-10-10-01-05 3300 NSv Proximity Probe Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        • Mounting Thread: The probe uses an M10×1 metric standard-mount case.
        • Thread Engagement: Maximum permitted engagement for the M10×1 case is 15 mm.
        • Case Torque: Recommended tightening torque is 11.3 N·m (100 in·lb).
        • Cable Routing: Minimum allowable bend radius is 25.4 mm (1.0 in).
        • Probe Tip: Polyphenylene sulfide provides the probe-tip construction material.
        • Probe Case: The case is manufactured from AISI 304 stainless steel.
        • Probe Cable: A 75 Ω coaxial cable uses FEP insulation along the probe lead.
        • Connection: Electrical connection is made through gold-plated brass ClickLoc hardware.
        • Operating Temperature: Probe operating range is -52°C to +177°C (-62°F to +351°F).
        • Storage Temperature: The specified storage range is also -52°C to +177°C.
        • Pressure Seal: A Viton O-ring seals differential pressure between the probe tip and case.
        • Low Temperature: Sustained exposure below -34°C may shorten pressure-seal service life.
        • Radial Measurement: Supports radial vibration and radial position measurement on suitable machinery.
        • Axial Position: The NSv system can measure axial or thrust position on appropriate targets.
        • Speed Measurement: Compatible system configurations support tachometer and zero-speed measurements.
        • Phase Reference: The probe can form part of a system used to obtain Keyphasor phase-reference signals.
        Description
        Bently Nevada 330910-00-10-10-01-05 is an armored metric 3300 NSv proximity probe configured with an M10×1 mounting thread. The probe has no unthreaded section, a 100 mm overall case length and a 1.0 metre total probe length. Its compact NSv geometry is intended for machinery installations where available counterbore, side-view or rear-view clearance limits the use of larger proximity probes.

        The 330910-00-10-10-01-05 uses a 75 Ω coaxial FEP-insulated probe cable and a miniature coaxial ClickLoc connection. This configuration includes a connector protector on the standard cable connection, while the armored construction provides additional mechanical protection around the probe lead.

        Mechanical construction of the 330910-00-10-10-01-05 combines a polyphenylene sulfide probe tip with an AISI 304 stainless-steel probe case and gold-plated brass connector components. The CableLoc design secures the probe lead to the probe body, while the TipLoc construction provides the mechanical bond between the sensing tip and probe body.

        Within a complete 3300 XL NSv transducer system, the 330910-00-10-10-01-05 supports non-contact measurements including radial vibration, radial position, axial position, tachometer, zero-speed and phase-reference applications. The probe configuration carries the multiple-approvals ordering option and is intended for use with the appropriate NSv extension cable and Proximitor Sensor.
        Alternative Names
        33O7O4-OOO-O78-1O-O1-O5 330704-000-078-I0-0I-05 330704000078100105 330704 000 078 10 01 05 330704-000-078-10-01-00 3300 NSv 330910-00-10-10-01-05 Bently 330910 M10x1 Proximity Probe BN 330910-00-10-10-01-05
        Technical notes
        Bently Nevada 330910-00-10-10-01-05 combines an armored M10×1 probe body, 100 mm case length and 1.0 m total cable length with a protected ClickLoc connector. It belongs to the 3300 XL NSv proximity transducer platform for restricted-clearance machinery measurements.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        How should Bently Nevada 330910-00-10-10-01-05 be matched with an NSv extension cable?
        The probe and extension-cable lengths must be selected so their combined length matches the total system length of the associated 3300 XL NSv Proximitor Sensor. Bently Nevada 330910-00-10-10-01-05 has a total probe length of 1.0 metre.
        Does Bently Nevada 330910-00-10-10-01-05 include stainless-steel armor?
        Yes. The 330910 base configuration identifies an M10×1 3300 NSv probe with armor, so Bently Nevada 330910-00-10-10-01-05 is the armored metric probe configuration.
        What mounting arrangement is required for Bently Nevada 330910-00-10-10-01-05?
        Bently Nevada 330910-00-10-10-01-05 uses an M10×1 standard-mount thread. Maximum thread engagement for an M10×1 probe case is 15 mm, and the recommended installation torque is 11.3 N·m.
        Can Bently Nevada 330910-00-10-10-01-05 be used for radial and axial measurements?
        Yes. When incorporated into the correct 3300 XL NSv transducer system, Bently Nevada 330910-00-10-10-01-05 can support radial vibration, radial position and axial position measurement arrangements.
        What connector configuration comes with Bently Nevada 330910-00-10-10-01-05?
        The 01 connector option specifies a miniature coaxial ClickLoc connector with a connector protector and standard cable for Bently Nevada 330910-00-10-10-01-05.
        Is Bently Nevada 330910-00-10-10-01-05 appropriate for installations with limited probe clearance?
        The 3300 XL NSv platform is specifically designed for restricted counterbore, side-view and rear-view installations. This makes Bently Nevada 330910-00-10-10-01-05 suitable where the larger standard proximity-system geometry cannot be accommodated.
        Can Bently Nevada 330910-00-10-10-01-05 directly replace components from another proximity system?
        System matching must be checked before replacement. Bently Nevada identifies NSv probes and extension cables as mechanically and electrically interchangeable with earlier 3300 RAM components, while upgrades from 3000-series or 7000-series 190 systems require replacement of the probe, extension cable and Proximitor Sensor with NSv components.
