          Original Bently Nevada 330901-11-43-10-02-05 NSv probe. Contact Apter Power for price, availability and lead time.

        330901-11-43-10-02-05

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        Bently Nevada 330901-11-43-10-02-05 3300 XL NSv unarmored proximity probe, 1/4-28 UNF, 1.1 in unthreaded length, 4.3 in case, 1.0 m standard cable, ClickLoc connector and multiple approvals.
        Ships by Friday, October 30
        Fast Shipping Available
        Get a quick price for 330901-11-43-10-02-05
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 330901-11-43-10-02-05

        • Manufacturer:
          Bently Nevada
        • Part Number:
          330901-11-43-10-02-05
        • Product Family:
          Proximity Probe
        • Product Type:
          NSV Probe
        • Product Family:
          3300 XL NSv Proximity Transducer System
        • Probe Configuration:
          Standard mount, unarmored
        • Mounting Thread:
          1/4-28 UNF-2A
        • Length Configuration:
          1.1 in unthreaded; 4.3 in case; 1.0 m total
        • Connector / Cable:
          Miniature coaxial ClickLoc / standard 75 ohm FEP cable
        • Agency Approval:
          Multiple approvals (option 05)
        • Linear Range:
          1.5 mm (60 mils), approximately 0.25 to 1.75 mm
        • Scale Factor:
          7.87 V/mm (200 mV/mil), +12.5%/-20%
        • Recommended Gap:
          1.0 mm (40 mils)
        • Frequency Response:
          0 to 10 kHz, +0/-3 dB typical
        • Probe Temperature:
          -52 to +177 C (-62 to +351 F)
        • Weight:
          0.05 kg
        • Country of origin:
          United States
        • Place of shipment:
          Ships within 3 working days after order confirmation.
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Ordering Code Measurement Applications Setup Environmental & Approvals

        Product overview:

        • Standard-mount 3300 XL NSv proximity probe for restricted clearances and small targets
        • 1/4-28 UNF-2A threaded body with an unarmored probe cable
        • 1.1 in unthreaded length, 4.3 in overall case length and 1.0 m total probe length
        The 330901-11-43-10-02-05 is the sensing element in a complete 3300 XL NSv proximity transducer system. Use a matching extension cable and Proximitor Sensor for the selected total electrical length.

        Option 05 identifies the multiple-approval configuration; verify the delivered nameplate and project certificate requirements before hazardous-area installation.
        Bently Nevada 330901-11-43-10-02-05 Manuals and Datasheets Important Notice: Extension cables, Proximitor Sensors, mounting hardware, calibration data and other accessories are not included unless listed in the stock item description.

        Exact ordering-code interpretation:

        • 330901 - 3300 XL NSv probe, 1/4-28 UNF-2A thread, without armor
        • 11 - 1.1 in unthreaded length
        • 43 - 4.3 in overall case length
        • 10 - 1.0 m total probe length
        • 02 - miniature coaxial ClickLoc connector with standard cable
        • 05 - multiple approvals

        Typical measurement applications:

        • Radial shaft vibration and radial position on fluid-film bearing machines
        • Axial or thrust position measurement
        • Tachometer, zero-speed and Keyphasor phase-reference measurements
        • Small shafts, small flat targets and installations with restricted side or rear view
        The 3300 XL NSv probe is suited to locations where conventional 5 mm or 8 mm probes cannot meet counterbore or viewing-clearance requirements. System performance depends on the matched extension cable, Proximitor Sensor and target material.

        Installation and compatibility checks:

        • Set the initial probe gap near 1.0 mm (40 mils) for the nominal linear range
        • Use a matching 3300 XL NSv extension cable and Proximitor Sensor
        • Make the probe and extension cable lengths equal the selected 5 m or 7 m system length
        • Maintain recommended probe-tip separation to limit cross-talk in X-Y or axial installations
        • Confirm calibration when the target material differs from AISI 4140 steel
        Replacement check: match the thread, case length, cable and connector option, total system length and approval suffix before installation.

        Environmental and approval guidance:

        • Probe operating temperature: -52°C to +177°C
        • Option 05 identifies the multiple-approval configuration
        • Probe tip material: polyphenylene sulfide (PPS)
        • Probe case: AISI 304 stainless steel; cable: 75 ohm FEP-insulated coaxial cable
        Hazardous-area suitability depends on the delivered nameplate, certificate, entity parameters, temperature classification, installation drawing and local jurisdiction. Verify the complete transducer system before installation.
        View as PDF
        Description
        The Bently Nevada 330901-11-43-10-02-05 is a standard-mount 3300 XL NSv proximity probe for measurements where counterbore, side-view or rear-view restrictions limit conventional probes.

        This unarmored configuration has a 1/4-28 UNF thread, 1.1 in unthreaded length, 4.3 in case length, 1.0 m standard FEP-insulated coaxial cable, a miniature ClickLoc connector and multiple approvals. Typical uses include radial vibration, radial position, axial position, tachometer, zero speed and Keyphasor measurements.
        Alternative Names
        Bently Nevada 330901-11-43-10-02-05 Bently Nevada 3300 XL NSv Probe 330901-11-43-10-02-05 330901 11 43 10 02 05 Proximity Probe 3309011143100205 NSv Probe Bently Nevada 330901 1/4-28 UNF Probe Bently Nevada 330901 1 m ClickLoc Probe 3300 XL NSv Unarmored Proximity Probe 330901 Multiple Approval Probe
        Technical notes
        The Bently Nevada 330901-11-43-10-02-05 is a 1/4-28 UNF, unarmored 3300 XL NSv probe with a 1.0 m standard cable and ClickLoc connector. Match it with a 3300 NSv extension cable and 3300 XL NSv Proximitor Sensor so the probe and extension cable equal the selected 5 m or 7 m system length.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        What is the configuration of 330901-11-43-10-02-05?
        It is a standard-mount 3300 XL NSv probe with a 1/4-28 UNF thread, no armor, a 1.0 m cable and multiple approvals.
        What do the 11 and 43 length codes mean?
        Code 11 specifies a 1.1 in unthreaded length; code 43 specifies a 4.3 in overall case length.
        What is the total probe length?
        Total length option 10 specifies 1.0 m (39 in).
        Which connector and cable option is supplied?
        Option 02 provides a miniature coaxial ClickLoc connector with standard FEP-insulated cable and no connector protector.
        Does this 330901 probe include armor?
        No. Base model 330901 is the unarmored 1/4-28 UNF probe configuration.
        What measurements is this NSv probe intended for?
        It supports radial vibration and position, axial position, tachometer, zero-speed and Keyphasor measurements, especially where installation space or target size is limited.
        What are the nominal range, scale factor and gap?
        The system has a 1.5 mm (60 mil) linear range, 7.87 V/mm (200 mV/mil) scale factor and 1.0 mm (40 mil) recommended gap.
        Which extension cable and Proximitor Sensor should be used?
        Use a matching 3300 NSv extension cable and 3300 XL NSv Proximitor Sensor; probe plus extension cable must equal the Proximitor Sensor 5 m or 7 m system length.
