    Apter Power supplies the active 3500/33 option 03 and option 01 hardware referenced by 3500/33-SIL2-03-01. The SIL2 qualifier remains subject to complete functional-safety certificate verification.

3500/33-SIL2-03-01

/ 4.9
1001 reviews | Need a Specific Revision?
3500/33-SIL2-03-01 is a supplied reference for a low-current relay configuration requiring SIL certificate review.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for 3500/33-SIL2-03-01
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 3500/33-SIL2-03-01

  • Manufacturer:
    Bently Nevada
  • Part Number:
    3500/33-SIL2-03-01
  • Product Family:
    3500 System
  • Product Type:
    3500/33 Low Current 16-Channel Relay Module
  • Stock:
    1
  • Current order template:
    3500/33-AA-BB
  • Safety qualifier:
    SIL2 certificate verification required
  • Output module:
    03, low current 16-channel relay output
  • Approval option:
    01, cNRTLus Class I Division 2
  • Contact finish:
    Gold-plated low-current contacts
  • Relay type:
    16 independently programmed SPDT outputs
  • Rack space:
    One full-height front slot plus rear I/O
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Ordering Code System Matching Installation

Product overview:

  • Low-current 16-channel relay output with gold-plated contacts
  • Independently programmable Alarm Drive Logic for every output
  • Supplied SIL2 qualifier requires complete certificate verification

The 3500/33 relay module translates configured rack alarm logic into 16 isolated SPDT output channels.

For safety service, validate the exact certified configuration and apply the restricted contact ratings and proof-test instructions.

Verified resources for Bently Nevada 3500/33-SIL2-03-01:

Additional technical data:

  • Typical power consumption: 5.8 watts
  • Minimum low-current load: 1 mA at 1 Vdc
  • Maximum low-current rating: 100 mA at 48 Vdc
  • Relay operation selection: four groups of four channels, normally energized or de-energized
  • Main module dimensions: 241 x 24.4 x 242 mm

Ordering structure:

  • The official template contains only AA output and BB approval fields
  • AA 03 selects low-current relay outputs
  • BB 01 selects cNRTLus Class I Division 2
  • The inserted SIL2 text must be checked against the safety certificate and rack configuration

Compatibility checklist:

  • Use the matching 16-channel low-current rear I/O module
  • Confirm supported rack configuration software
  • Validate the certified safety loop and restricted voltage
  • Map every relay channel to the intended alarm logic and field load

Installation checks:

  • Verify contact voltage and current before wiring
  • Select normally energized or de-energized operation in groups of four
  • Load the approved Alarm Drive Logic configuration
  • Perform the required channel and safety proof tests before service
Description

3500/33-SIL2-03-01 is a supplied reference associated with the Bently Nevada 3500/33 16-Channel Relay Module. Current ordering literature identifies option 03 as a low-current output module with gold-plated contacts and option 01 as cNRTLus Class I, Division 2 approval.

The standard ordering template is 3500/33-AA-BB, so SIL2 is not a normal order-code field. Confirm the functional-safety certificate, restricted contact ratings, relay/I/O combination, rack configuration and proof-test requirements before quotation or use in a safety function.

Alternative Names
3500/33-SIL2-03-01 3500 33 SIL2 03 01 3500-33-SIL2-03-01 3500/33 SIL 2 03 01 Bently Nevada 3500/33-SIL2-03-01 Bentley Nevada 3500/33-SIL2-03-01 3500 System 3500/33-SIL2-03-01 3500/33-SIL2-03-01 Relay Module
Technical notes
3500/33-SIL2-03-01 must not be treated as proof of SIL2 capability by part number alone. Functional-safety use depends on the certified system configuration and restricted relay-contact voltage.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Is 3500/33-SIL2-03-01 the standard ordering format?
No. The current product template is 3500/33-AA-BB; SIL2 is a supplied configuration qualifier that requires certificate verification.
What does option 03 identify?
It selects the low-current 16-channel relay output module with gold-plated contacts.
What does approval option 01 mean?
It identifies cNRTLus Class I, Division 2 hazardous-area approval.
Does the reference alone establish SIL2 compliance?
No. The complete certified rack, monitor, relay and proof-test configuration must match the applicable functional-safety certificate.
How are the relay outputs programmed?
Each SPDT output has configurable Alarm Drive Logic using AND or OR combinations of rack alarm and measured-variable states.
What contact limits apply in safety service?
Use the restricted ratings required by the functional-safety and hazardous-area documentation; higher voltages are not permitted in those configurations.
Where is the relay technical document?
The Manuals tab provides an Apter-hosted 3500/33 document with contact ratings and ordering information.
What must accompany a quotation request?
Provide the safety-certificate reference, rack revision, relay/I/O pair, contact load, proof-test interval, quantity and destination.
