350500-00-00-00-11-00

/ 4.9
1001 reviews | Need a Specific Revision?
The Bently Nevada 350500-00-00-00-11-00 is a high-precision dynamic pressure charge amplifier designed to convert piezoelectric sensor signals into low-impedance voltage outputs for combustion instability monitoring in gas turbine engines.
Get a quick price for 350500-00-00-00-11-00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 350500-00-00-00-11-00

  • Manufacturer:
    Bently Nevada
  • Part Number:
    350500-00-00-00-11-00
  • Product Family:
    3500 System
  • Input Sensitivity Option:
    00=16 pC/psi (232 pC/bar)
  • Low Pass Frequency Option (See Figures 1 and 2):
    00=High
  • Output Sensitivity Option:
    00=100 mV/psi (1.45 V/bar)
  • Mounting Option:
    11=Din Mount, MIL Connector
  • Approvals:
    00=No Approvals
  • Operating Temperature:
    -20°C to +70°C (-4°F to +158°F)
  • Storage Temperature:
    -40°C to +85°C (-40°F to +185°F)
  • Operating and Storage Humidity:
    0% to 95% relative noncondensing
  • Sensitivity:
    100 mV/psi ( 1.45 V/bar); ±2% @ 150 Hz
  • Dynamic Range:
    ±50 psi pk
  • Common Mode Rejection:
    -40 dB or better in the passband
  • Weight:
    0.24 kg
  • Estimated shipping dimensions:
    8.8x3.6x7cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
Description
The Bently Nevada 350500-00-00-00-11-00 Dynamic Pressure Charge Amplifier (DPCA) is a key component in dynamic pressure sensing systems, specifically engineered to monitor pressure pulsations caused by combustion instability in gas turbine engines. It works in conjunction with high-temperature piezoelectric pressure sensors, low-noise interconnect cables, and monitoring devices to provide accurate and reliable pressure measurements in harsh industrial environments.

This amplifier converts the sensor charge signal into a low-impedance voltage output, making it compatible with Bently Nevada monitoring devices such as the 3500/64 Dynamic Pressure Monitor. The DPCA features an input sensitivity of 16 pC/psi (232 pC/bar), an output sensitivity of 100 mV/psi (1.45 V/bar) ±2% @ 150 Hz, a dynamic range of ±50 psi pk, and common-mode rejection of -40 dB or better. Its high low-pass frequency option ensures precise signal fidelity.

Designed for flexibility and robustness, the 350500-00-00-00-11-00 comes with DIN mounting and MIL connector, supports operating temperatures from -20°C to +70°C and storage temperatures from -40°C to +85°C, and operates reliably under 0% to 95% non-condensing relative humidity. The interconnect cable is low-noise and environmentally robust, allowing accurate signal transmission from the sensor to the amplifier even in challenging conditions.

With its versatile design, the 350500 DPCA can be used with multiple sensors for combustion instability monitoring. It provides a safe, standardized electrical interface to Bently Nevada monitors, using -24 Vdc power, common, and signal, and is compatible with appropriate safety barriers to ensure operational safety. This makes the DPCA ideal for continuous high-fidelity monitoring of gas turbine combustion dynamics.
Alternative Names
35O5OO-OO-OO-OO-11-OO 350500-00-00-00-II-00 3505000000001100 35O5OOOOOOOO11OO 350500000000II00 350500 00 00 00 11 00
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the 350500-00-00-00-11-00 input sensitivity?
16 pC/psi (232 pC/bar).
How is the DPCA mounted?
DIN mount with MIL connector.
Does the Bently Nevada 350500-00-00-00-11-00 product come with a warranty?
Yes, all products are covered by a one-year warranty provided by Apter Power.
What is the 350500-00-00-00-11-00 operating temperature range?
-20°C to +70°C (-4°F to +158°F).
