81724-00-08-10-02

/ 4.9
1001 reviews | Need a Specific Revision?
81724-00-08-10-02 is an unarmored Bently Nevada 7200 14 mm metric probe with an 80 mm case, a 1.0 m integral lead and a miniature male coaxial connector.
In Stock
Ships by Saturday, October 31
Fast Shipping Available
Get a quick price for 81724-00-08-10-02
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 81724-00-08-10-02

  • Manufacturer:
    Bently Nevada
  • Part Number:
    81724-00-08-10-02
  • Product Family:
    7200 Proximity Transducer Systems
  • Product Type:
    14 mm Metric Standard-Mount Probe
  • Stock:
    1
  • Mounting thread:
    M16 × 1.5
  • Unthreaded length:
    0 mm (-00)
  • Overall case length:
    80 mm (-08)
  • Integral lead length:
    1.0 m, +0.2 m / -0 m (-10)
  • Connector:
    Miniature male coaxial (-02)
  • Armor:
    None
  • Mounting hardware:
    24 mm jam nut; 12 mm wrench flats
  • Weight:
    0.14 kg
  • Estimated shipping dimensions:
    2.8x2.3x121cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Mounting Fit Lead & Connector System Response Product Applications

Features:

  • Metric mounting: The 81724 probe uses an M16 × 1.5 thread with a 24 mm jam nut.
  • Defined case geometry: The -00-08 segments specify 0 mm unthreaded length and an 80 mm overall case.
  • Installed lead and connector: The -10-02 segments provide a 1.0 m lead and miniature male coaxial connector.
81724-00-08-10-02 is a 14 mm standard-mount probe in the 7200 proximity transducer system, not a complete transducer chain by itself.

Its 80 mm case, 0 mm unthreaded section and metric mounting hardware support a direct fit comparison at the existing measurement point.

The 1.0 m integral lead and miniature male connector must be considered alongside the required extension cable and Proximitor system length.

Apter Power can support an 81724-00-08-10-02 Bently Nevada 14 mm Metric Standard-Mount Probe enquiry with a scoped quotation and 7200 system documentation.
Bently Nevada 81724-00-08-10-02 14 mm Metric Standard-Mount Probe Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Metric thread: The 81724 base probe uses an M16 × 1.5 mounting thread.
  • Case selection: The -00-08 segments specify 0 mm unthreaded length and an 80 mm overall case.
  • Installation hardware: The listed metric part uses a 24 mm jam nut and 12 mm wrench flats.
  • Probe type: 81724 is the unarmored 14 mm standard-mount probe in the 7200 family.
  • Integral lead: The -10 option provides a 1.0 m lead with a +0.2 m / -0 m tolerance.
  • Connector end: The -02 option specifies a miniature male coaxial connector.
  • System length: A probe with less than a five-metre integral lead uses an extension cable to reach the selected system length.
  • Sensor pairing: The probe and lead are selected with the appropriate 7200 Proximitor, not as an independent powered sensor.
  • Measurement principle: The complete 7200 14 mm assembly measures static and dynamic target displacement without contact.
  • Calibrated range: Bently Nevada lists a 4.06 mm linear range for the complete 14 mm system under its stated test conditions.
  • Recommended gap: The 14 mm system has a published 2.54 mm recommended gap setting.
  • System output: The Proximitor converts the probe response to a gap-to-voltage signal for the monitor.
  • Radial vibration: A complete 7200 transducer system can monitor shaft motion at a bearing location.
  • Axial thrust: The configured system can track rotor thrust position.
  • Eccentricity: The documented application includes shaft-bow observation during turbine startup.
  • Rod drop: A suitable installation can measure rider-band wear on reciprocating compressors.
Description
81724-00-08-10-02 is the metric 14 mm standard-mount probe in Bently Nevada's 7200 proximity transducer system. The 81724 base part has an M16 × 1.5 mounting thread, a 24 mm jam nut and 12 mm wrench flats.

The 81724-00-08-10-02 ordering segments specify 0 mm unthreaded length, an 80 mm overall case, a 1.0 m integral lead and a miniature male coaxial connector. These dimensions and connector details support an accurate match to the installed probe position.

Within a complete 7200 measurement chain, 81724-00-08-10-02 observes target displacement without contact. The probe, any required extension cable and Proximitor sensor are selected together for the intended combined system length.
Alternative Names
Bently Nevada 81724-00-08-10-02 BN 81724-00-08-10-02 81724 00 08 10 02 8172400081002 81724-00-08-10-02 14 mm probe 7200 81724-00-08-10-02 Bently Nevada 81724 00 08 10 02 BN 81724 00 08 10 02
Technical notes
The 81724-00-08-10-02 ordering code defines a one-metre integral lead and miniature male coax termination in a 14 mm 7200 probe. Mechanical fit alone does not establish the correct total electrical system length with the extension cable and Proximitor. Apter Power can help align the installed signal chain when preparing a replacement quote.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can 81724-00-08-10-02 replace an 8 mm 7200 probe?
This is a 14 mm probe in the 7200 family, so an 8 mm installation should use its documented probe and sensor arrangement rather than assume a direct replacement.
Will 81724-00-08-10-02 fit my existing metric mounting point?
The order matrix specifies an M16 × 1.5 thread and 80 mm overall case for this configuration. Compare those features with the installed opening and available clearance before ordering.
Does an 81724-00-08-10-02 quote include the extension cable and Proximitor?
The model identifies the probe with its integral lead; the extension cable and Proximitor are separate parts unless the quotation explicitly includes them.
Can 81724-00-08-10-02 connect to my installed signal lead?
The -02 termination is miniature male coax. The mating connector and total probe-to-sensor electrical length must suit the installed 7200 chain; Apter Power can help compare both before quotation.
