Technical specifications for 330881-BR-04-145-06-02

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330881-BR-04-145-06-02
  • Product Family:
    PROXPAC XL Proximity Transducer Assembly
  • RetainingNut:
    29.5 N·m (260 in·lb)
  • Operating Temperature:
    -52°C to +100°C(-62°F to +212°F)
  • ProxpacStorageTemperature:
    -52°C to +105°C(-62°F to +221°F)
  • RecommendedGap Setting:
    1.27 mm (50 mils)
  • Outputresistance:
    50 Ω
  • Minimum TargetSize:
    15.2 mm (0.6 in) diameter(flat target)
  • ProximitorSensor Input:
    3300 XL 8 mm Proximity Probewith a 1-metre cable lengthinstalled in the probe sleeve.
  • Weight:
    1.5 kg
  • Estimated shipping dimensions:
    37x9x8cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications


Features:

  • Interface Between the 330881-BR-04-145-06-02 PROXPAC XL Assembly and 3300 XL / 3500 Monitoring Systems
  • Combines Capability of Shaft Displacement and Vibration Measurement with Extended 145 mm Probe Reach
  • Operates in Conjunction with Standard 3300 XL and 3500 Series Monitors for Critical Machinery Protection
The Bently Nevada 330881-BR-04-145-06-02 functions as a fully integrated PROXPAC XL 8 mm proximity transducer assembly, providing accurate shaft displacement and vibration measurements for critical rotating machinery. It continuously converts mechanical shaft motion into high-resolution electrical signals via the 145 mm probe and integrated Proximitor sensor, delivering reliable outputs to 3300 XL and 3500 Series monitoring systems for real-time condition monitoring.

The Bently Nevada 330881-BR-04-145-06-02 provides essential shaft displacement and vibration measurement functions for critical machinery and is a key component of the monitoring path, directly affecting the accurate operation of the overall condition monitoring system. One or more 330881-BR-04-145-06-02 assemblies are installed per machine depending on the number of measurement points and redundancy requirements. The assembly is compact, factory-calibrated, and designed for straightforward integration with 3300 XL and 3500 Series monitoring systems, ensuring reliable, long-term performance.

For dual-redundant monitoring applications, the Bently Nevada 330881-BR-04-145-06-02 can be deployed as a secondary transducer assembly to provide backup measurement capability. In addition to standard single-probe operation, the redundant configuration allows automatic switchover if the primary assembly fails or its output signal falls outside specified shaft displacement or vibration tolerances.

The 330881-BR-04-145-06-02 Bently Nevada PROXPAC XL 8 mm proximity transducer may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 330881-BR-04-145-06-02 PROXPAC XL 8 mm Proximity Transducer Assembly Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
 Bently Nevada 330881-BR-04-145-06-02 PROXPAC XL 8 mm Proximity Transducer Assembly Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330881-BR-04-145-06-02
  • Condition New Original ready stock
  • Product Family 330881-BR-05-145-06-02,330881-BR-06-145-06-02,330881-BR-07-145-06-02
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Description
Alternative Names
330881-BR-05-145-06-02 330881-BR-06-145-06-02 330881-BR-07-145-06-02
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What type of measurements does the 330881-BR-04-145-06-02 provide?
The 330881-BR-04-145-06-02 provides non-contact shaft displacement and vibration measurements using an 8 mm PROXPAC XL probe with an integrated Proximitor® sensor.
What is the probe penetration length and typical application?
This assembly features a 145 mm probe penetration length, suitable for deep or extended reach into bearing housings and complex machinery requiring precise monitoring.
Which monitoring systems is the 330881-BR-04-145-06-02 compatible with?
It is compatible with Bently Nevada 3300 XL and 3500 Series monitoring systems, delivering reliable condition monitoring and machinery protection in industrial environments.
