PR6423/004-010 CON021

/ 4.9
1001 reviews | Need a Specific Revision?
Emerson PR6423/004-010 CON021 is a 65 mm M10×1 probe with adapter plug, 5 m LEMO lead and CON021 converter.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for PR6423/004-010 CON021
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for PR6423/004-010 CON021

  • Manufacturer:
    Emerson
  • Part Number:
    PR6423/004-010 CON021
  • Product Family:
    Epro
  • Product Type:
    8 mm Eddy Current Sensor with Panel Converter
  • Stock:
    1
  • Probe thread and body:
    M10×1; 65 mm
  • Cable construction:
    Unarmored
  • Adapter plug:
    With
  • Probe lead:
    5 m; LEMO
  • Converter:
    CON021
  • Linear range:
    2 mm
  • Initial air gap:
    0.5 mm nominal
  • Weight:
    0.24 kg
  • Estimated shipping dimensions:
    16x16x4cm
  • Tariff Code:
    9031809090
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Deep Bracket Adapter Seal Gap & Travel Product Applications

Features:

  • Deeper reach: 65 mm M10×1 body suits extended mounting geometry.
  • Adapter configuration: includes the documented adapter plug.
  • Compact lead: 5 m LEMO cable connects to CON021.
The 004 body code identifies the 65 mm threaded case used where the bracket sits farther from the target.

The 010 suffix selects an adapter plug, 5 m cable and LEMO termination.

Mechanical clearance and electrical gap are checked independently before the machine is released.

Apter Power supports Emerson PR6423/004-010 CON021 8 mm Eddy Current Sensor with Panel Converter quotations, technical documentation, procurement support and system-matching guidance.
Emerson PR6423/004-010 CON021 8 mm Eddy Current Sensor with Panel Converter Manuals,Datasheets,Link Important Notice: Apter Power provides these resources for exact-model documentation, quotation and engineering review.
  • Longer body: the 65 mm M10×1 version serves a deeper mounting point, but its extra reach must still leave a controllable adjustment around the working gap.
  • Machine envelope: the case, locknut and cable exit need room at the housing before the tip can be set safely against the shaft.
  • Free sensing sector: Emerson specifies 45° clearance around the PR6423 head; nearby metal may distort the upper measuring range.
  • Angular alignment: axial tilt below 2° helps keep the distance reading tied to shaft movement rather than bracket angle.
  • Defined junction: this 010 configuration includes an adapter within a 5 m total lead, so the cable arrangement is part of the exact chain identity.
  • Sleeved joint: Emerson requires a shrink sleeve across the mated adapter, including inside a metal protection tube, to isolate and protect that connection.
  • Panel end: the final LEMO plug locks into the CON021 front socket, whereas open-wire terminations use CON041 screw terminals.
  • Route planning: a 5 m run must reach the mounting box without an improvised extension that would alter the converter calibration basis.
  • Initial position: the PR6423 specification starts from a nominal 0.5 mm air gap; the paired CON021 output is the practical installation reference.
  • Useful travel: the standard 2 mm linear window must include expected shaft motion, not only a stationary cold reading.
  • Voltage centre: the selected converter range sets the centre output, allowing movement on either side of the rest position.
  • Separate causes: a stable gap voltage with poor running vibration can point to target runout or mounting behaviour rather than a different static setting.
  • Deep housing mounts: reaches a shaft through a longer threaded bracket.
  • Turbine position channels: supports axial displacement measurement.
  • Compressor vibration: provides radial shaft-motion data.
  • Local panel conversion: links a 5 m LEMO lead to CON021.
Description
PR6423/004-010 CON021 provides a 65 mm M10×1 unarmored probe body for deeper mounting positions, combined with an adapter plug, 5 m cable and LEMO termination.

CON021 receives the LEMO-connected probe signal and provides the conditioned output used by the machinery-monitoring channel. The longer body of PR6423/004-010 CON021 changes the mechanical reach without changing the standard 2 mm sensing range.

PR6423/004-010 CON021 service planning should compare bracket depth, adapter arrangement and the available 5 m route. After installation, establish the cold gap and confirm output linearity without forcing the probe or cable into the machine envelope.
Alternative Names
PR6423004010CON021 PR6423 004 010 CON021 PR6423-004-010 CON021 PR6423/004-010-CON021 PR6423/004/010 CON021 Emerson PR6423/004-010 CON021 Epro PR6423/004-010 CON021 PR6423/004-010 CON 021
Technical notes
PR6423/004-010 CON021 combines the 65 mm body with an adapter plug and 5 m LEMO lead. Confirm that the longer case clears the machine housing and that the cable reaches the panel without tension. Gap adjustment belongs to the complete matched chain; use the conditioned output and approved target to position the sensor rather than the body length alone.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
When is the 65 mm body of PR6423/004-010 CON021 useful?
It supports mounting points that require greater reach, provided the bracket and machine envelope maintain safe adjustment and shaft clearance.
What does the 010 suffix specify for PR6423/004-010 CON021?
It selects an adapter plug, 5 m cable and LEMO cable end for the CON021 interface.
Why should cable tension be checked on PR6423/004-010 CON021?
Tension at the probe or LEMO connector can disturb mounting stability and create intermittent signal behavior.
How should PR6423/004-010 CON021 be gapped after installation?
Use the complete matched chain and conditioned output with the approved target, then confirm mechanical clearance through the expected shaft movement.
Can PR6423/004-010 CON021 replace a shorter-body PR6423 configuration?
Only after the mounting drawing proves the 65 mm case and adjustment range fit the machine without interference.
What diagnostic evidence supports release of PR6423/004-010 CON021?
Keep the static gap output, dynamic baseline, connector check, bracket depth and matched converter record.
