PR6424-010-140

/ 4.9
1001 reviews | Need a Specific Revision?
Emerson PR6424-010-140 is a 16 mm armored eddy current sensor with M18×1.5 mounting, 52.5 mm total sensor length, a continuous 10 m lead and LEMO cable end.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for PR6424-010-140
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for PR6424-010-140

  • Manufacturer:
    Emerson
  • Part Number:
    PR6424-010-140
  • Product Family:
    Epro
  • Product Type:
    16 mm Armored Eddy Current Sensor
  • Stock:
    1
  • Case thread:
    M18×1.5
  • Cable armor:
    Yes
  • Sleeve length:
    40 mm
  • Total sensor length:
    52.5 mm
  • Total cable length:
    10 m
  • Linear measuring range:
    4 mm
  • Initial air gap:
    Approximately 2.7 mm at the center position
  • Sensitivity:
    4 V/mm
  • Reference target:
    42CrMo4 / AISI 4140 steel
  • Minimum shaft diameter:
    80 mm
  • Operating temperature:
    -35 to +150°C in the exact-family specifications sheet
  • Protection class:
    IP66
  • Armored cable bend radius:
    35 mm
  • Tariff Code:
    9031809090
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Range Selection Mechanical Fit Cable Integrity Application
  • Use the larger PR6424 range only with sufficient target diameter and free metal clearance
  • Protect the continuous armored 10 m cable because it has no intermediate adapter
  • Set cold gap with the expected thermal and axial movement included

Emerson PR6424-010-140 is a 16 mm armored eddy current sensor for larger non-contact shaft displacement and vibration measurements.

The official PR6424/010-140 code specifies M18×1.5 mounting, a 40 mm sleeve, 52.5 mm total sensor length, no intermediate adapter, a continuous 10 m lead and LEMO end.

Before installation or replacement, verify shaft diameter, target alloy and surface, probe reach and angle, working gap, 10 m cable route, converter pairing and monitor range.

Availability, condition, price, and shipping time for PR6424-010-140 are confirmed during quotation.


Emerson PR6424-010-140 Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Choose PR6424 when the required movement exceeds the practical PR6423 range
  • Confirm the target remains inside the linear region over all machine states
  • Reserve gap margin for thermal growth and axial movement
  • Use the M18×1.5 thread and documented 40 mm sleeve reach
  • Keep the probe square to the target and the holder rigid
  • Verify shaft diameter, target surface and surrounding metal clearance
  • Treat the 10 m lead as a continuous calibrated part of the sensor
  • Observe the 35 mm bend radius and provide strain relief
  • Keep the LEMO connector dry, clean and fully latched
  • Large-shaft radial vibration monitoring
  • Axial position or differential movement measurement within the verified range
  • Eccentricity and shaft-position monitoring on turbines, compressors, pumps and fans
Description
Emerson PR6424-010-140 is a 16 mm armored eddy current sensor for larger non-contact shaft displacement and vibration measurements.

The official PR6424/010-140 code specifies M18×1.5 mounting, a 40 mm sleeve, 52.5 mm total sensor length, no intermediate adapter, a continuous 10 m lead and LEMO end.

Before installation or replacement, verify shaft diameter, target alloy and surface, probe reach and angle, working gap, 10 m cable route, converter pairing and monitor range.
Alternative Names
PR6424-010-140 PR6424/010-140 PR 6424-010-140 PR 6424/010-140 Emerson PR6424-010-140 Emerson PR6424/010-140 Emerson Epro PR6424-010-140 Emerson Epro PR6424/010-140 Epro PR6424-010-140 Epro PR6424/010-140
Technical notes
PR6424-010-140 has a continuous armored 10 m lead without an intermediate adapter. Do not substitute a sectional cable arrangement without confirming the complete calibrated measuring chain.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
When is Emerson PR6424-010-140 preferable to an 8 mm PR6423 probe?
Use it when the application needs the PR6424's larger measurement range and the shaft and mounting area satisfy its larger target and clearance requirements.
Can the 10 m lead on Emerson PR6424-010-140 be shortened or separated?
No field alteration should be assumed. The order code specifies a continuous lead without an intermediate adapter; changing cable length can invalidate the calibrated chain.
What target checks matter before installing Emerson PR6424-010-140?
Confirm a sufficiently large shaft, the documented ferromagnetic reference or an approved material calibration, adequate surface finish and no nearby metal inside the required free zone.
Can Emerson PR6424-010-140 use the converter from another PR6424 probe?
Only after verifying sensor type, serial-number pairing, cable configuration and calibration. A connector fit does not prove the scale and linearity are correct.
Why might Emerson PR6424-010-140 reach the monitor limit during thermal growth?
The cold gap may not leave enough travel for the expected shaft movement, or the configured monitor range and mechanical direction may not match the installation.
What should be checked when Emerson PR6424-010-140 is noisy only at high load?
Check target runout, shaft movement, bracket resonance, armored-cable routing, grounding and converter supply, then compare the signal with machine speed and load.
How should Emerson PR6424-010-140 be recommissioned after replacement?
Verify the cold gap and signal direction, check movement through the required range, confirm monitor scale and alarm setpoints, and perform a controlled machine run while watching bias and vibration.
