Emerson EZ1081-03-00-010 EZ1901-090 is a 10.0 m armored AMS EZ 1000 eddy-current measuring chain.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for EZ1081-03-00-010 EZ1901-090
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for EZ1081-03-00-010 EZ1901-090

  • Manufacturer:
    Emerson
  • Part Number:
    EZ1081-03-00-010 EZ1901-090
  • Product Family:
    Epro
  • Product Type:
    8 mm Armored Eddy-Current Sensor and Armored Extension Cable Assembly
  • Stock:
    1
  • Sensor case thread:
    None; armored EZ1081 case
  • Sensor case length:
    30 mm
  • Unthreaded length:
    0 mm
  • Integral sensor cable:
    1.0 m
  • Extension cable:
    9.0 m armored EZ1901
  • Overall system length:
    10.0 m; valid under the official ordering rule
  • Linear range:
    2 mm
  • Initial gap:
    0.5 mm
  • Nominal scale:
    7.87 V/mm API or 8 V/mm ISO, converter configuration dependent
  • Sensor protection:
    IP67; IP68 only when DOC-TEST is assigned
  • Sensor/first 1 m temperature:
    -35 to 180°C
  • Cable/connector temperature:
    -35 to 150°C
  • Target material:
    AISI/SAE 4140 reference steel
  • Tariff Code:
    9031809090
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Compact Mounting Long Cable Route Noise Control Application
  • Keep both exact component numbers and the 10.0 m total system length
  • Verify the 30 mm sensor case suits the bracket and target reach
  • Field-calibrate the complete sensor, cable and converter chain

Emerson EZ1081-03-00-010 EZ1901-090 combines an armored EZ1081 8 mm eddy-current sensor with an armored EZ1901 extension cable for a documented 10.0 m system length.

The exact components specify a 30 mm sensor case, 0 mm unthreaded section, 1.0 m integral sensor cable and 9.0 m extension cable.

Before installation, verify converter compatibility, the compact 30 mm case and noise-controlled 10 m cable route, target material and diameter, bracket geometry, connector sealing, cable route, total electrical length and field calibration.

Availability, condition, price, and shipping time for EZ1081-03-00-010 EZ1901-090 are confirmed during quotation.

Emerson EZ1081-03-00-010 EZ1901-090 Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Use the 30 mm case where bracket depth is restricted
  • Support the armored body without stressing the cable exit
  • Verify free metal clearance around the 8 mm tip
  • Keep the 9 m extension away from motor and switching conductors
  • Protect the inline connector from moisture and vibration
  • Maintain the documented overall 10 m electrical length
  • Check shield and ground practice before changing filters
  • Compare noise with machine load and drive operation
  • Record calibrated scale and baseline signal after installation
  • Radial shaft vibration measurement on turbines and compressors
  • Axial position or differential movement measurement
  • Speed, key and eccentricity sensing with the configured AMS EZ 1000 converter
Description
EZ1081-03-00-010 EZ1901-090 is an Emerson/epro AMS EZ 1000 eddy-current measuring chain formed by two separately ordered components.

The exact order codes define a 30 mm armored sensor with a 1.0 m integral cable and a 9.0 m armored extension cable; do not substitute another length without confirming converter scaling.

Before installation, confirm converter compatibility, target material, bracket geometry and connector sealing, then set the probe gap and field-calibrate the complete chain.
Alternative Names
EZ1081-03-00-010 EZ1901-090 EZ1081 03 00 010 EZ1901 090 Emerson EZ1081-03-00-010 EZ1901-090 Epro EZ1081-03-00-010 EZ1901-090 Emerson Epro EZ1081-03-00-010 EZ1901-090 AMS EZ 1000 EZ1081-03-00-010 EZ1901-090
Technical notes
Emerson EZ1081-03-00-010 EZ1901-090 forms a documented 10.0 m measuring chain. Confirm both components, AMS EZ 1000 compatibility, sealing and field calibration before use.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
When is the 30 mm sensor case in Emerson EZ1081-03-00-010 EZ1901-090 suitable?
The shorter armored case suits restricted brackets, but the holder must still support the body and place the tip at the correct gap without surrounding metal interference.
Is Emerson EZ1081-03-00-010 EZ1901-090 a single bundled order number?
No. It is a valid combination of two exact component order codes. The 1.0 m sensor cable and 9.0 m extension cable form a documented 10.0 m measuring chain.
Can the extension cable in Emerson EZ1081-03-00-010 EZ1901-090 be routed beside motor leads?
Avoid this. Route the signal cable away from high-current and switching conductors, protect the connector and prevent tight coils or unsupported vibration loops.
Why does Emerson EZ1081-03-00-010 EZ1901-090 require field calibration after replacement?
Connector condition, target alloy, total cable length, probe gap and converter configuration influence the installed scale, so calibrate the complete measuring chain rather than only the sensor.
What should be checked if Emerson EZ1081-03-00-010 EZ1901-090 becomes noisy at high machine load?
Compare the cable route with motor and drive currents, then inspect shielding, grounding, connector condition, bracket rigidity, target runout and converter supply.
Can EZ1901-090 in Emerson EZ1081-03-00-010 EZ1901-090 be shortened to remove excess cable?
No field shortening or splicing should be assumed. Preserve the documented 10.0 m electrical length and manage excess cable using the approved bend radius and routing.
How should Emerson EZ1081-03-00-010 EZ1901-090 be commissioned?
Verify connector locking and cable routing, set the mechanical gap, field-calibrate the converter against the actual target, and confirm scale, noise floor and alarms during a controlled run.
