Emerson 5X00273G01 is the 16-channel high-side digital-output personality module paired with 5X00270G01.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 5X00273G01
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 5X00273G01

  • Manufacturer:
    Emerson
  • Part Number:
    5X00273G01
  • Product Family:
    Ovation
  • Product Type:
    16-Channel High-Side Digital Output Personality Module
  • Stock:
    1
  • Companion Electronics Module:
    5X00270G01
  • Channels:
    16
  • Associated HSDO Subsystem:
    24 V DC High-Side Digital Output
  • Documented Ovation Version:
    Windows Ovation 3.0.4 or later
  • Personality Module Functions:
    Per-channel voltage suppression and 24 V DC field-power filtering
  • Redundancy Connections:
    Connectors for redundant-mode interconnection
  • Supported Operating Modes:
    Simplex or redundant
  • Output Isolation Design:
    Series isolation diode on each of 16 output channels
  • Tariff Code:
    9032900090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Pairing Channels Assembly Application
  • Personality module for the documented Ovation 16-channel high-side digital-output assembly
  • Pairs with 5X00270G01, the corresponding output electronics module
  • Provides the field-side personality and termination role within the complete assembly

5X00273G01 is an Emerson high-side digital-output personality module designed for the Ovation I/O platform.

It forms the field-side element of a 16-channel high-side output assembly and must be used with the documented 5X00270G01 electronics module.

Before installation or replacement, verify the two catalog numbers, base and connector arrangement, field-power wiring, channel assignments, and installed redundancy design.

Availability, condition, price, and shipping time for 5X00273G01 are confirmed during quotation.

Emerson 5X00273G01 Ovation High-Side Digital Output Personality Module Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • The documented companion electronics module is 5X00270G01
  • 5X00273G01 is the personality-module element of the complete assembly
  • The two catalog numbers identify different functions and are not interchangeable
  • The documented high-side digital-output assembly provides 16 channels
  • Channel wiring terminates through the personality-module side of the assembly
  • Channel mapping must agree with the configured Ovation I/O database
  • The personality module and electronics module form one documented output assembly
  • The installed base and connector arrangement must match the high-side output design
  • Field-power and redundancy wiring must follow the installed Ovation cabinet documentation
  • High-side discrete-output field termination in Ovation process-control cabinets
  • Sixteen-channel actuator and relay command circuits using the documented Ovation output assembly
  • Ovation DCS applications requiring a 5X00270G01 and 5X00273G01 high-side output pair
Description
5X00273G01 is an Emerson Ovation 16-Channel High-Side Digital Output Personality Module for the documented Ovation I/O platform.

The module is paired with 5X00270G01 electronics and provides the personality and field-termination side of the complete high-side digital-output assembly.

Before installation or replacement, confirm both module identifiers, the installed base and connector arrangement, field-power wiring, channel mapping, and redundancy configuration.
Alternative Names
Emerson 5X00273G01 Emerson Ovation 5X00273G01 Ovation 5X00273G01 5X00273 G01 5X00273G01 Personality Module 5X00273G01 Output PMOD Ovation High-Side Output PMOD 5X00273G01
Technical notes
Emerson 5X00273G01 must be matched to electronics module 5X00270G01 and the installed Ovation base, field-power wiring, channel map, and redundancy arrangement.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Is Emerson 5X00273G01 a complete digital-output module by itself?
No. Emerson identifies 5X00273G01 as the personality module used with 5X00270G01 electronics in the complete high-side digital-output assembly.
What must be checked when ordering Emerson 5X00273G01 for a redundant HSDO configuration?
Confirm that each output position uses the documented 5X00270G01 electronics module with the matching 5X00273G01 personality module. Also verify the installed base and connector arrangement, redundancy interconnections, 24 V DC field-power wiring, cabinet positions, and configured channel mapping.
What should be checked if an output does not switch correctly after replacing Emerson 5X00273G01?
Check the 24 V DC field supply, channel-to-terminal wiring, load polarity and current, suppression path, and any field-load short circuit before replacing additional module hardware.
Can Emerson 5X00273G01 replace Emerson 5X00270G01?
No. They perform different functions: 5X00273G01 is the personality module and 5X00270G01 is the electronics module.
Should load-current ratings be taken from Emerson 5X00273G01 alone?
No. Electrical load selection must follow the official specification for the complete high-side output assembly, including its electronics, personality module, base, field supply, and wiring.
What wiring details should be checked before ordering Emerson 5X00273G01?
Check the installed base, connector arrangement, field-power wiring, channel assignments, redundancy configuration, and both module catalog numbers.
Can Emerson 5X00273G01 be used with a different Ovation output type?
The available Emerson documentation specifically identifies it with the 5X00270G01 high-side digital-output assembly; do not assign it to another output type without exact official documentation.
