General Electric IC693CMM321 is a single-slot Series 90-30 Ethernet interface that links a modular PLC rack to a 10 Mbit/s TCP/IP network.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for IC693CMM321
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC693CMM321

  • Manufacturer:
    General Electric
  • Part Number:
    IC693CMM321
  • Product Family:
    GE 90-30 Series PLC
  • Product Type:
    Ethernet TCP/IP Interface Module
  • Stock:
    1
  • Form Factor:
    Single-slot Series 90-30 module
  • Network Speed:
    10 Mbit/s Ethernet
  • Primary Protocol:
    SRTP over TCP/IP
  • Modbus TCP:
    Master and slave on supported firmware
  • SRTP Server Port:
    TCP 18245
  • Modbus TCP Server Port:
    TCP 502
  • Server Connections:
    Up to 16
  • Physical Media:
    Hardware-revision dependent
  • 10Base-T:
    Added with revision FG and later
  • AAUI:
    Present on earlier hardware; removed by revision KL
  • Station Manager:
    Serial service for configuration and diagnostics
  • Firmware Update Cable:
    IC693CBL316 Station Manager cable
  • Latest Documented Revision:
    IC693CMM321-KN
  • Latest Documented Firmware:
    Version 3.20
  • Modbus TCP Introduction:
    Firmware 3.10 on supported Fx-and-later hardware
  • Backplane Current:
    750 mA at 5 VDC
  • Compatible Networks:
    Series 90 and supported PACSystems/VersaMax TCP/IP Ethernet interfaces
  • Hand-Held Programmer:
    Not supported for Ethernet-interface configuration
  • Tariff Code:
    8538900000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Media Interfaces Protocol Services Diagnostics

Features:

  • Adds 10 Mbit/s TCP/IP Ethernet communication to a modular Series 90-30 rack.
  • Supports SRTP services and revision-dependent Modbus TCP master and slave operation.
  • Uses hardware-specific media interfaces that must be matched by complete revision suffix.
The current catalog family is the IC693CMM321 Ethernet interface, whose exact media hardware and firmware capability are identified by the two-letter suffix.

It lets PLC logic initiate network transfers while host systems and compatible controllers access selected Series 90-30 data over TCP/IP.

Before replacement, record the full suffix, firmware, IP parameters, transceiver or RJ45 arrangement, Station Manager access and every configured exchange or communication request.

Availability is subject to Apter Power inventory and sourcing confirmation.
General Electric IC693CMM321 Series 90-30 Ethernet interface module Manuals, Datasheets, LinksImportant Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Connects legacy Series 90-30 controller data to compatible HMI and supervisory systems over industrial Ethernet.
  • Supports PLC-initiated communication with compatible GE controllers and network devices through configured requests.
  • Provides a retained Ethernet path during staged migration of installed Series 90-30 control systems.
  • Early revisions use an AAUI connection and require a matching external transceiver for the selected Ethernet medium.
  • Revision FG introduced a direct 10Base-T interface while retaining revision-specific hardware differences.
  • Revision KL and the later KN release omit the AAUI port, so connector availability must be checked from the label.
  • SRTP provides native GE controller and programming communications across the Ethernet LAN.
  • Supported firmware implements Modbus TCP master and slave functions for external data exchange.
  • PLC logic uses configured communication requests while the interface reports completion and network status.
  • Station Manager provides local commands for network setup, statistics, exception review and service functions.
  • Front indicators report module, LAN, serial or duplex activity according to the installed hardware revision.
  • Firmware updates require the documented Station Manager connection and uninterrupted rack power throughout flash programming.
Description
General Electric IC693CMM321 adds industrial Ethernet communication to a modular Series 90-30 PLC without changing the controller's established rack architecture. It provides a network path for programming, supervisory access and controller data exchange, helping installed automation systems communicate with plant-level equipment through standard TCP/IP infrastructure.

SRTP services form the native communications layer, while supported hardware and firmware revisions also provide Modbus TCP master and slave functions. This combination allows the interface to serve GE controller traffic and selected open-protocol integrations, making it useful when an existing Series 90-30 system must exchange data with newer HMIs or supervisory hosts.

The module family spans several physical-interface generations, so its connector layout is part of the product identity rather than a cosmetic variation. Early hardware relies on AAUI media equipment, later revisions add direct twisted-pair Ethernet, and the latest documented units omit AAUI, making the complete revision suffix essential during maintenance planning.
Revisions

Revision Part #

Also known as

IC693CMM321AA
IC693CMM321-AA, Series AA, Rev AA
IC693CMM321BA
IC693CMM321-BA, Series BA, Rev BA
IC693CMM321CB
IC693CMM321-CB, Series CB, Rev CB
IC693CMM321CC
IC693CMM321-CC, Series CC, Rev CC
IC693CMM321CD
IC693CMM321-CD, Series CD, Rev CD
IC693CMM321DD
IC693CMM321-DD, Series DD, Rev DD
IC693CMM321DE
IC693CMM321-DE, Series DE, Rev DE
IC693CMM321EE
IC693CMM321-EE, Series EE, Rev EE
IC693CMM321EF
IC693CMM321-EF, Series EF, Rev EF
Alternative Names
IC 693 CMM321 IC693-CMM321 GE IC693CMM321 GE Fanuc IC693CMM321 Series 90-30 IC693CMM321 CMM321 IC693 CMM321 1C693CMM321
Technical notes
IC693CMM321 media hardware is revision-dependent; verify the full suffix before specifying an AAUI transceiver, direct 10Base-T cable or firmware update.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Why is the complete IC693CMM321 revision suffix required?
The suffix identifies the physical Ethernet interface and supported firmware path. An AAUI-era unit and a later RJ45-only unit are not connected in the same way.
Which IC693CMM321 revisions support Modbus TCP?
GE introduced Modbus TCP master and slave operation with firmware 3.10 for supported Fx-and-later hardware; confirm the installed suffix and firmware before configuration.
Does every IC693CMM321 require an external Ethernet transceiver?
No. Early AAUI hardware does, while later versions provide direct 10Base-T and the documented KL/KN hardware removes AAUI.
What is the main risk during an IC693CMM321 firmware update?
Interrupting rack power while flash memory or the software loader is being programmed can leave affected hardware inoperative.
What security check is needed on an IC693CMM321-KN?
The Station Manager password must be changed from its default value and network access should follow the controls described for firmware 3.20.
Which manuals should be used for IC693CMM321 engineering?
Use GFK-1541 for TCP/IP Ethernet communications, GFK-1186 for Station Manager and the matching GFK-1085 product-information revision.
What should accompany an IC693CMM321 quotation request?
Send the complete two-letter suffix, firmware, existing connector layout, IP configuration, required condition, destination and quantity.
