The General Electric IS200JPDVG1AAA is a Power Distribution Board manufactured and designed by General Electric as an integral component of the Mark VIe Series used in GE Distributed Turbine Control Systems.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for IS200JPDVG1AAA
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IS200JPDVG1AAA

  • Manufacturer:
    General Electric
  • Part Number:
    IS200JPDVG1AAA
  • Product Family:
    GE Mark VI Gas Turbine Control
  • Product Type:
    Power Distribution Board
  • Stock:
    1
  • Number of channels:
    1 channel
  • Input span:
    1-5V dc
  • Outputs:
    24 V dc
  • Power:
    28 V
  • Generator current inputs:
    0 to 5 A
  • Analog inputs Current inputs:
    4-20 mA
  • Analog output current:
    0-20 mA
  • Weight:
    0.16 kg
  • Estimated shipping dimensions:
    21.8x12x4cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Performance & Efficiency Environmental Ratings

Features:

  • Central Power Distribution Hub for MVRA, MVRF, and Mark VIe Control Components
  • Integrates DLAN+ Signal Filtering with Power Routing to Multiple System Modules
  • Serves as the Communication Interface Between PIOA and Excitation Control via DLAN+
The General Electric IS200JPDVG1AAA Power Distribution Board operates as the JPDV power distribution board within the Mark VIe Series, specifically engineered for GE Distributed Turbine Control Systems. It functions as the central power management hub for the MVRA and MVRF modules, supporting configurations with up to two controllers, an Ethernet switch, and up to two PIOA I/O packs. The IS200JPDVG1AAA also establishes the critical communication interface enabling the PIOA to connect through the DLAN+ network to the excitation control system. The board contains DLAN+ filtering circuitry that passes the signal to BIOA through the DC-37 pin connector, while simultaneously routing power to the PIOA modules, controllers, MVRA and MVRF units, and Ethernet switch.

The IS200JPDVG1AAA provides essential power distribution functions common to the entire Mark VIe control system, and is a critical component of the monitoring and power delivery paths, directly affecting the proper, normal operation of the overall turbine control architecture. One IS200JPDVG1AAA power distribution board is required per system configuration to manage centralized power routing to all connected modules. The board occupies a dedicated interface position within the control system where it consolidates incoming power from the supply and distributes it through its integrated terminal board connectors.

For complete Mark VIe system integration, all power and communication cables must be properly connected to the IS200JPDVG1AAA. In addition to standard power distribution, the installation must also connect the DLAN+ (ARCNET) coax cable to the BNC connector and the Power In Cable from the power supply. Using this configuration, the IS200JPDVG1AAA continually manages power routing to the MVRA, MVRF, controllers, Ethernet switch, and PIOA modules while maintaining DLAN+ signal integrity for excitation control. If the system detects that any power or communication pathway is improperly connected, the corresponding module will not receive adequate power or signal access, affecting overall turbine control operation.

The IS200JPDVG1AAA General Electric Power Distribution Board may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric IS200JPDVG1AAA Power Distribution Board Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
General Electric IS200JPDVG1AAA Power Distribution Board Specs

General

  • Manufacturer General Electric
  • Model IS200JPDVG1AAA
  • Condition New Original ready stock
  • Product Family IS200JPDVG1A,IS200IGPAG2AED
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • GE Mark VIe Systems: Serves as a core power distribution hub within GE Mark VIe turbine control platforms.
  • Controller Interface: Provides dedicated power routing and communication paths for MVRA and MVRF controllers.
  • I/O Pack Mounting: Functions as the mechanical and electrical base for up to two PIOA Input/Output packs.
  • Excitation System Link: Connects the mounted PIOA I/O packs directly to the DLAN+ network for excitation control.
  • Switch Powering: Feeds stable operational power to adjacent control cabinet Ethernet switches.
  • TMR Redundancy: Supports Triple Modular Redundant configurations via separate power inputs to prevent single points of failure.
  • Voltage Input Span: Tracks and regulates precise analog inputs ranging from 1 to 5 V DC.
  • Dual Voltage Output: Delivers constant, clean power distribution across 24 V DC and 28 V DC baselines.
  • Standard Current Loops: Manages industrial signal channels for standard 4–20 mA and 0–20 mA control loops.
  • Generator Current Tracking: Accommodates dedicated generator current inputs spanning from 0 to 5 A.
  • Operating Temperature: Functions reliably in ambient cabinet conditions ranging from 0°C to +60°C.
  • Safety Compliance: Built to meet EN 61010-1 electrical safety, insulation, and shock protection standards.
  • Grid Compatibility: Integrates seamlessly with both 50 Hz and 60 Hz power grid infrastructures.
Description
The IS200JPDVG1AAA is a Power Distribution Board manufactured and designed by General Electric as part of the Mark VIe Series, specifically engineered for deployment within GE Distributed Turbine Control Systems. Serving as the JPDV power distribution board, the IS200JPDVG1AAA functions as a central power management hub for the MVRA and MVRF modules, accommodating configurations with up to two controllers, an Ethernet switch, and up to two PIOA I/O packs. This board also establishes the critical communication interface enabling the PIOA to connect through the DLAN+ network to the excitation control system.

This IS200JPDVG1AAA power distribution board is specifically designed to address centralized power routing and communication distribution challenges within complex turbine control architectures. It solves the critical problem of reliably delivering power to multiple control components—including the MVRA and MVRF units, controllers, Ethernet switch, and PIOA I/O packs—while simultaneously maintaining DLAN+ signal integrity for excitation control pathways. By consolidating these functions onto a single board, the IS200JPDVG1AAA eliminates the need for separate power distribution mechanisms and ensures coordinated operation across the control system.

The IS200JPDVG1AAA finds primary application in power generation and industrial turbine control environments, particularly within GE Mark VIe distributed control architectures deployed in gas turbine power plants, steam turbine facilities, and other heavy industrial settings. In these demanding applications, the IS200JPDVG1AAA provides the robust power distribution backbone necessary for continuous turbine operations, supporting critical control components that manage turbine startup, operation, and protection functions.

For installation and integration of the IS200JPDVG1AAA, connect the power cables going to the MVRA and MVRF modules when present, connect the power cables to the Ethernet switch if equipped, connect the power cables to the controllers when installed, and connect the power cables to the PIOA modules if present. Additionally, the DLAN+ (ARCNET) coax cable must be connected to the BNC connector, and the Power In Cable from the power supply must be properly connected to ensure reliable system energization.
Alternative Names
IS2OOJPDVG1AAA IS200JPDVGIAAA 1S200JPDVG1AAA IS200JPDVG1A IS200IGPAG2AED IS200NATPG1CAA
Technical notes
As a specialized JPDV board, the IS200JPDVG1AAA is engineered specifically to manage and route power for MVRA and MVRF components, accommodating up to two controllers, an Ethernet switch, and up to two PIOA I/O packs. Beyond its primary power regulation capabilities, the IS200JPDVG1AAA serves as the critical communication interface linking the PIOA to the DLAN+ network for excitation control, ensuring seamless data flow within the system architecture.
