        IS200VVIBH1CAC

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        IS200VVIBH1CAC is a GE Mark VI vibration monitor board processing 14 analog probe signals, digitizing them via 16-bit ADC, and transmitting data over the VME bus for turbine protection.
        In Stock
        Ships by Thursday, October 29
        Fast Shipping Available
        Get a quick price for IS200VVIBH1CAC
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for IS200VVIBH1CAC

        • Manufacturer:
          General Electric
        • Part Number:
          IS200VVIBH1CAC
        • Product Family:
          GE Mark VI Gas Turbine Control
        • Product Type:
          Vibration Monitor Board
        • Stock:
          2
        • Input Channels:
          14 (for vibration/position probes)
        • Analog Resolution:
          16-bit
        • Input Voltage:
          24V DC
        • ADC Sampling Rate:
          51.2 kS/s
        • Isolation Voltage:
          2500 V AC (channel-to-channel)
        • Frequency Response:
          DC to 10 kHz
        • Power Consumption:
          3.5 W (Typical)
        • Operating Temperature:
          -40°C to +70°C
        • Storage Temperature:
          -40°C to +85°C
        • Weight:
          0.28 kg
        • Estimated shipping dimensions:
          2x18.6x26.1cm
        • Tariff Code:
          8537109090
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen, Fujian, China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Specifications Application Diagnostics & Machinery Installation

        Features:

        • Processes up to 14 analog inputs from seismic, proximity, and accelerometer probes
        • Features 16-bit ADC, 2500V isolation, and a sampling rate of 51.2 kS/s
        • Built for the Mark VI series with a -40°C to +70°C temperature range and high MTBF
        The IS200VVIBH1CAC serves as the central interface for up to 14 individual vibration sensors in a turbine control system . By supporting Bently Nevada's Seismic, Proximitor, Velomitor, and Accelerometer probes, it consolidates signal conditioning for multiple protection functions into a single board . This high channel count reduces the need for multiple separate cards, simplifies the backplane layout, and ensures that critical parameters like vibration and rotor position are monitored simultaneously, providing a complete picture of machine health to the Mark VI controller.

        To ensure data integrity in electrically noisy environments, the IS200VVIBH1CAC is equipped with high-precision 16-bit ADCs . It provides a remarkable 2500V AC isolation between channels and ground, effectively breaking ground loops and protecting the main controller from field wiring faults . With a sampling rate of 51.2 kS/s, it captures high-frequency transient events such as bearing fault signatures, allowing the monitoring system to detect failures like outer race defects with high diagnostic accuracy well before they become catastrophic .

        The IS200VVIBH1CAC is physically designed as a 6U VME board, featuring a metal faceplate with LED indicators (Run, Status, Fail) for local diagnostics . It is built to withstand the extreme conditions of a turbine deck, operating reliably across a temperature range of -40°C to +70°C . With a component MTBF exceeding 200,000 hours, the IS200VVIBH1CAC ensures long-term reliability and reduces the risk of unplanned maintenance outages in critical power generation assets .

        The IS200VVIBH1CAC GE Vibration Monitor Board may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

        GE IS200VVIBH1CAC Vibration Monitor Board Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        GE IS200VVIBH1CAC Vibration Monitor Board Specs

        General

        • Manufacturer GE
        • Model IS200VVIBH1CAC
        • Condition New Original ready stock
        • Product Family IS200VCRCH1B,IS200VCRCH1BBC,IS200SRLYH2AAA
        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        • Gas Turbines: Controls GE Frame 6, 7, and 9 heavy-duty gas turbines.
        • Centrifugal Compressors: Protects large pipeline compressors.
        • Mechanical Drives: Monitors critical pump and LNG train turbines.
        • Steam Turbines: Monitored in combined cycle power plants.
        • Radial Vibration: Monitors shaft dynamic movement inside bearings.
        • Axial (Thrust) Position: Detects rotor shifting to prevent rotor-to-stator rubbing.
        • Rotor Eccentricity: Measures shaft bowing during slow-rotation turning gear operation.
        • Differential Expansion (Chassis vs. Rotor): Monitors thermal growth mismatches during startup.
        • Hardware Jumpers: You must manually configure hardware jumpers on the board or its terminal board (TVIB/DVIB) to match the sensor type (e.g., configuring voltage levels for -24V DC proximity probes vs. passive accelerometers).
        • Slot Assignment: Must be placed in its designated slot within the VME rack as configured in the Toolbox software.
        • Power Down: De-energize the specific control core (R, S, or T) before extracting or inserting the board (unless hot-swap is explicitly approved under controlled conditions).
        • ESD Protection: Always wear a grounded electrostatic discharge wrist strap.
        Description
        The IS200VVIBH1CAC is a dedicated Vibration Monitor board manufactured by General Electric for the Mark VI Speedtronic turbine control system . This printed circuit board (PCB) is designed to interface directly with up to 14 external vibration probes, processing their analog signals to provide critical machinery protection.

        Functionally, the IS200VVIBH1CAC is responsible for four key protection functions: vibration, rotor eccentricity, differential expansion, and rotor axial position . The IS200VVIBH1CAC digitizes incoming analog signals using a high-precision 16-bit ADC and transmits the digital data to the main controller via the VME backplane bus for real-time monitoring and control.

        Physically, the IS200VVIBH1CAC is a 6U VME form factor board with a metal faceplate featuring three status LEDs labeled "Run," "Status," and "Fail" . The board is ruggedly designed for extreme industrial environments, with a wide operating temperature range of -40°C to +70°C.
        Revisions

        Revision Part #

        Also known as

        IS200VVIBH1CAB
        IS200VVIBH1CA-B, Series -B, Rev -B
        Get Parts Quote
        IS200VVIBH1CAA
        IS200VVIBH1CA-A, Series -A, Rev -A
        Get Parts Quote
        Alternative Names
        IS200VVIBHICAC IS200BICLH1AED IS200EISBH1A IS200EXAMG1A IS200EXHSG4A IS200TBACIH1B IS200TGENH1A IS200VCRCH1B
        Technical notes
        The IS200VVIBH1CAC is a rugged VME board for GE Mark VI systems, designed for high-precision vibration monitoring. It supports up to 14 inputs (seismic/proximity), features 16-bit resolution, and handles four key protection functions. It operates reliably from -40°C to +70°C.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        What specific turbine control system is the IS200VVIBH1CAC designed for?
        It is designed for GE's Mark VI series, part of the Speedtronic family for managing gas, steam, and wind turbines . It functions as a VME-based Vibration Monitor board.
        How many vibration probes can the IS200VVIBH1CAC support?
        The board supports up to 14 individual probes . It works with Bently Nevada's seismic, proximity, velocity, and accelerometer probes, providing comprehensive machinery protection.
        What are the four key protection functions of the IS200VVIBH1CAC?
        The IS200VVIBH1CAC provides monitoring for Vibration, Rotor Eccentricity, Differential Expansion, and Rotor Axial Position, which are critical for preventing damage in rotating machinery.
        What are the environmental operating limits for the IS200VVIBH1CAC?
        It is rated for a wide industrial temperature range of -40°C to +70°C . It also features a high Mean Time Between Failures (MTBF) of over 200,000 hours.
