The General Electric IS220PVIBH1AL is a Vibration Monitor I/O Pack, designed to interface 13 mixed-signal sensors with dual-redundant IONet networks to provide real-time rotor dynamics and bearing health monitoring for critical turbomachinery.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for IS220PVIBH1AL
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IS220PVIBH1AL

  • Manufacturer:
    General Electric
  • Part Number:
    IS220PVIBH1AL
  • Product Family:
    GE Mark VIe Distributed I/O
  • Product Type:
    Vibration Monitor I/O Pack
  • Stock:
    3
  • Channels:
    13 Isolated Differential Inputs
  • Sensor Compatibility (Ch 1-3):
    Accelerometer (IEPE), Velomitor, Proximitor, Seismic
  • Sensor Compatibility (Ch 4-8):
    Velomitor, Proximitor, Seismic
  • Sensor Compatibility (Ch 9-12):
    Proximitor (DC)
  • Ch 13 Function:
    Keyphasor or Proximity Signal
  • Input Bandwidth:
    1150 Hz (-3 dB)
  • ADC Resolution:
    14-bit
  • Frame Rates:
    3.125, 6.25, 12.5, 25, 50, 100 Hz
  • System Accuracy:
    ±0.5%
  • Probe Power:
    -24 VDC ±5% @ 12 mA/channel
  • Communication:
    Dual Redundant 10/100 Mbps IONet (RJ45)
  • Power Supply:
    18-36 VDC
  • Power Consumption:
    ≤ 4.6 W
  • Operating Temperature:
    -30°C to +65°C (-22°F to +149°F)
  • Weight:
    0.45 kg
  • Estimated shipping dimensions:
    6x12.8x8.2cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Operating Environment Safety & Compliance

Features:

  • Ultra-High Density 13-Channel Sensor Mixing
  • Dual-Redundant IONet with Hot-Swappability
  • Onboard Signal Conditioning (IEPE & -24Vdc)
The General Electric IS220PVIBH1AL supports up to 13 inputs per pack. It allows mixing of accelerometers, proximity probes, and velomitors on a single module. Channel 13 is specifically hardwired for Keyphasor inputs, enabling precise synchronous vibration sampling for rotor balancing without requiring additional cards.

Designed for continuous operation, the General Electric IS220PVIBH1AL features two independent 100 Mbps Ethernet ports. If the primary network fails, the secondary link takes over instantly. If the module itself fails, its hot-swap design allows replacement without powering down the rack, achieving 99.999% availability for turbine control systems.

Eliminate costly external signal converters. The General Electric IS220PVIBH1AL provides onboard -24 VDC power for proximity probes and constant current excitation (IEPE) for accelerometers on channels 1-3. This direct interface reduces loop resistance and improves signal-to-noise ratio (SNR) by removing intermediate terminal blocks.

The IS220PVIBH1AL General Electric Mark VIe Vibration Monitor I/O Pack may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric IS220PVIBH1AL Mark VIe Vibration Monitor I/O Pack Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
General Electric IS220PVIBH1AL Mark VIe Vibration Monitor I/O Pack

General

  • Manufacturer General Electric
  • Model IS220PVIBH1AL
  • Condition New Original ready stock
  • Product Family IS220PVIBH1A,IS220PTURH1A,IS220PDOAH1B
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Gas & Steam Turbines: Real-time monitoring of rotor vibration, differential expansion, and casing movement to trigger safe shutdowns before blade-tip rubs occur.
  • LNG & Pipeline Compressors: Predictive maintenance monitoring for high-speed centrifugal compressors, preventing surge events through vibration trend analysis.
  • Heavy Industrial Motors & Generators: Bearing wear analysis and imbalance detection for large 4-pole and 6-pole synchronous machines.
  • Marine Propulsion: Shaft alignment monitoring on LNG carriers and naval vessels where dynamic positioning requires continuous vibration validation.
  • Wide Temperature Tolerance: Engineered for un-conditioned environments, operating strictly between -30°C and +65°C, suitable for remote outdoor skids.
  • Electromagnetic Immunity: Designed with high Common Mode Rejection Ratio (CMRR) of -50 dB @ 50/60 Hz, allowing it to sit next to VFDs without signal corruption.
  • Physical Construction: The conformal-coated PCB resists airborne contaminants like salt mist and sulfurous gases typical of petrochemical plants.
  • Thermal Dissipation: Ultra-low power draw of only 4.6W eliminates the need for forced cooling fans in the cabinet, reducing maintenance cycles.
  • Functional Safety: Certified per IEC 61508 for use in SIL 2 (Hardware Fault Tolerance 1) and SIL 3 (with redundancy) safety instrumented functions.
  • Hazardous Locations: Compliance with ATEX Zone 2 and UL Class I Division 2, allowing installation directly on the gas turbine skid rather than a remote safe area.
  • Machinery Protection: Conforms to API 670 (Machinery Protection Systems) standards for shaft vibration, shaft position, and bearing temperature monitoring.
  • Emissions: RoHS Compliant (Lead-free construction) for markets enforcing strict environmental regulations (EU/UK).
Description
The General Electric IS220PVIBH1AL (PVIB) serves as the dedicated vibration front-end for the Speedtronic Mark VIe platform. Unlike standard analog input cards, this module is hardwired to handle the specific signal conditioning requirements of proximity probes, velomitors, and accelerometers. It converts raw dynamic data into actionable trend analysis, allowing plants to transition from reactive maintenance to predictive strategies for gas and steam turbines.

Architecturally, the General Electric IS220PVIBH1AL eliminates the need for external signal conditioners. It provides onboard -24 VDC probe power and IEPE accelerometer excitation, drastically reducing cabinet wiring complexity and passive failure points. Its 24-bit ADC resolution ensures that even sub-micron shifts in shaft vibration are captured with ±0.5% system accuracy, complying with API 670 standards for machinery protection.

Designed for high availability, the General Electric IS220PVIBH1AL operates over a -30°C to 65°C range and supports full hot-swapping. In the event of a module failure, replacement takes under five minutes without a system shutdown, and the auto-reconfiguration feature restores operation instantly. This makes it an essential SIL 2/3 component for emergency shutdown (ESD) systems in LNG, petrochemical, and power generation environments.
Revisions

Revision Part #

Also known as

IS220PVIBH1A
IS220PVIBH1A / Rev A-K
IS220PVIBH1AL
IS220PVIBH1A / Rev L
IS220PVIBH1B
IS220PVIBH1B / Series B
IS220PVIBH1C
IS220PVIBH1C / Series C
IS220PVIBH1D
IS220PVIBH1D / Series D
Alternative Names
1S220PV1BH1AL IS22OPVIBH1AL IS220PVIBHIAL 1S22OPV1BHIAL IS220PVIBH1A IS220PTURH1A IS220PDOAH1B IS220PRTDH1A
Technical notes
The General Electric IS220PVIBH1AL utilizes dual 10/100 Mbps full-duplex Ethernet ports to maintain seamless controller communication, ensuring zero data loss even during network switchover events.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What specific terminal board is required for the General Electric IS220PVIBH1AL to read proximity probes?
The General Electric IS220PVIBH1AL is designed exclusively for the GE TVBA (Vibration Terminal Board) series. A standard DC-37 pin ribbon cable connects the I/O pack to the TVBA, where the field wiring for proximitors and accelerometers is landed.
Can the General Electric IS220PVIBH1AL interface with third-party IEPE accelerometers, or only GE sensors?
Yes. The General Electric IS220PVIBH1AL uses standard IEPE (Integrated Electronics Piezo-Electric) signal conditioning on Channels 1 through 3. It provides the required 4-20 mA constant current excitation, making it compatible with any standard 2-wire IEPE accelerometer from brands like Bruel & Kjaer or PCB.
What firmware compatibility does the General Electric IS220PVIBH1AL require with the Mark VIe controller?
To function correctly, the General Electric IS220PVIBH1AL requires the controller to be running firmware version 6.0 or higher. It communicates via the UDH (Universal Data Highways) protocol over IONet; older Mark V systems are not compatible.
Is the General Electric IS220PVIBH1AL certified for SIL 2 safety loops in a gas compressor train?
Absolutely. The General Electric IS220PVIBH1AL is TÜV certified per IEC 61508. It can be used in hardware fault tolerance (HFT) architectures to achieve SIL 2 for over-speed or over-vibration protection functions without requiring a separate dedicated safety PLC.
What is the planned lifecycle status of the General Electric IS220PVIBH1AL? Is it obsolete?
The General Electric IS220PVIBH1AL is an active component of the Mark VIe platform, which remains GE’s current flagship control system. No immediate obsolescence is scheduled, and full factory support is available through 2030+.
What are the environmental limits for installing the General Electric IS220PVIBH1AL near a turbine?
The General Electric IS220PVIBH1AL is rated for extreme industrial conditions. It operates reliably from -30°C to +65°C ambient temperature and can withstand humidity up to 95% non-condensing. For hazardous areas, ATEX Zone 2 / Class I Div 2 variants are available.
