UR6UH

/ 4.9
1001 reviews | Need a Specific Revision?
GE Vernova UR6UH is a Multilin Universal Relay 6U module combining six non-monitored Form-A outputs with four digital contact inputs. It supports compact breaker control, annunciation and interlocking schemes.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for UR6UH
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for UR6UH

  • Manufacturer:
    General Electric
  • Part Number:
    UR6UH
  • Product Family:
    GE Multilin
  • Product Type:
    6U Digital I/O Module
  • Stock:
    1
  • Platform:
    GE Multilin Universal Relay (UR)
  • Output configuration:
    Six Form-A contact outputs without current or voltage monitoring
  • Input configuration:
    Four digital contact inputs
  • Input recognition:
    Less than 1 ms
  • Input debounce:
    0 to 16 ms in 0.5 ms steps
  • Input grouping:
    Four contact inputs per common return
  • Ordering suffix:
    H execution; verify against the installed module label
  • Output monitoring:
    No current or voltage monitoring
  • Weight:
    0.88 kg
  • Estimated shipping dimensions:
    4x18.4x17.2cm
  • Tariff Code:
    85389091
  • Country of origin:
    Canada
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Monitoring & Control Protection Configuration

Features:

  • Combines six Form-A outputs with four digital contact inputs.
  • Uses non-monitored output contacts in the documented 6U configuration.
  • Provides configurable contact-input debounce for event and control logic.
The 6U/H identity fixes a mixed module containing six Form-A outputs and four contact inputs.

FlexLogic commands the output relays and processes the debounced input states inside the UR chassis.

Review trip-coil burden, external supervision, common return and module-slot assignment before replacement.

The mixed I/O module is sourced only after host-relay and output-duty compatibility are confirmed.
Verified resources for GE Vernova UR6UH:Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Operate breaker-control or annunciation circuits from UR FlexLogic.
  • Acquire four permissive or status contacts through the same module position.
  • Consolidate modest input and output requirements in a protection-panel retrofit.
  • Six Form-A relays close their normally open contacts when commanded by the host logic.
  • Four digital inputs feed status and interlock conditions into the relay application.
  • Circuit supervision must be implemented elsewhere where the external scheme requires it.
  • The connected burden must remain within the contact ratings in the UR manual.
  • External fusing and arc suppression must suit the trip, alarm, or auxiliary load.
  • A non-monitored output cannot prove continuity of its external circuit.
  • Input debounce is adjustable from 0 to 16 ms in 0.5 ms steps.
  • The four inputs use the documented common-return grouping.
  • Module position and I/O operands must match the installed UR setting file.
Description
UR6UH provides six non-monitored Form-A contact outputs together with four digital inputs. This combination supports compact breaker-control, annunciation and interlocking schemes within the modular UR platform.

FlexLogic or a protection element commands the Form-A relays, which close their normally open contacts to operate the assigned external circuit. Because the 6U outputs are specified without current or voltage monitoring, circuit supervision must be provided elsewhere when the application requires it.

The four digital inputs use the UR contact-input threshold and debounce functions before their states are presented to logic, events or control equations. All four inputs share the documented common-return grouping.
Alternative Names
UR-6UH UR 6UH UR-6U-H GE UR6UH GE Vernova UR6UH GE Vernova Multilin 6U Digital IO Module Universal Relay UR 6U H
Technical notes
UR6UH outputs have no current or voltage monitoring; confirm external circuit supervision, contact duty and the host relay's H hardware execution before use.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which signals are combined on GE Vernova UR6UH?
The 6U module combines six non-monitored Form-A outputs with four digital contact inputs.
Can GE Vernova UR6UH supervise continuity of its output circuits?
No. GE specifies these outputs without current or voltage monitoring, so external supervision is required when the scheme needs it.
How are GE Vernova UR6UH outputs controlled?
The host relay's FlexLogic or protection elements command the Form-A relays according to the validated setting file.
What input conditioning is available on GE Vernova UR6UH?
The four inputs use threshold evaluation and configurable debounce before their states enter logic and event records.
What must match before moving GE Vernova UR6UH to another chassis?
Check the UR hardware generation, H execution, slot assignment, setting operands, terminal wiring and external contact burden.
Which control-circuit details belong in a GE Vernova UR6UH RFQ?
Provide host relay and slot, module label, output loads, input wetting arrangement, setting-file revision, quantity and destination.
