IC695ALG616

/ 4.9
1001 reviews | Need a Specific Revision?
General Electric IC695ALG616 is a PACSystems RX3i 16/8-channel current and voltage analog input module.
In Stock
Ships by Saturday, October 17
Fast Shipping Available
Get a quick price for IC695ALG616
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC695ALG616

  • Manufacturer:
    General Electric
  • Part Number:
    IC695ALG616
  • Product Family:
    GE PACSystems RX3i
  • Product Type:
    PACSystems RX3i 16/8-Channel Current/Voltage Analog Input Module
  • Stock:
    1
  • Analog input configuration:
    16 single-ended channels or 8 differential channels
  • Current input ranges:
    0...20 mA; 4...20 mA; ±20 mA
  • Voltage input ranges:
    ±10 V; 0...10 V; ±5 V; 0...5 V; 1...5 V
  • Converter:
    24-bit ADC
  • Data formats:
    IEEE 32-bit floating point or 16-bit integer in a 32-bit field
  • Input filter selections:
    8, 12, 16, 40, 200, or 500 Hz
  • Voltage input impedance:
    Greater than 100 kΩ
  • Current input resistance:
    249 Ω ±1%
  • Open-circuit detection:
    1 second maximum
  • Input protection:
    ±60 V DC continuous voltage; ±28 mA continuous current
  • Backplane power:
    350 mA maximum at 5 V DC; 200 mA maximum at 3.3 V DC
  • Maximum internal dissipation:
    4.25 W
  • Field-to-backplane/chassis isolation:
    250 V AC continuous; 1500 V AC for 1 minute
  • Tariff Code:
    9032900090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Diagnostics Filtering Configuration Application
  • Selectable single-ended or differential acquisition supports different field-signal layouts
  • Per-channel current or voltage range selection supports mixed analog measurement projects
  • Configurable digital filtering supports a documented balance between noise rejection and response

IC695ALG616 is a General Electric PACSystems RX3i analog input module designed for rack-based current and voltage measurement.

The module digitizes field signals through a 24-bit converter and returns channel data to the RX3i system in floating-point or integer format.

Before installation or replacement, verify the selected wiring mode, input range, filter setting, terminal assembly, scaling, alarm configuration, and controller project.

Availability, condition, price, and shipping time for IC695ALG616 are confirmed during quotation.

General Electric IC695ALG616 PACSystems RX3i 16/8-Channel Current/Voltage Analog Input Module Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • The Module OK LED is solid green when the module is configured and operating normally
  • The Field Status LED is green when enabled channels have no faults and yellow when at least one channel fault is present
  • The TB LED is green when the terminal block is present, red when it is absent or not fully seated, and off when backplane power is absent
  • Six selectable input-filter frequencies are available from 8 Hz through 500 Hz
  • The 8 Hz filter provides at least 120 dB common-mode rejection at 50/60 Hz
  • The 12 Hz filter provides at least 110 dB common-mode rejection at 50/60 Hz
  • All channel settings are configured in software; no module jumpers are required
  • Channels can be configured with individual scaling and offsets
  • High, low, high-high, and low-low alarm detection and reporting can be selected per channel
  • Multichannel current and voltage acquisition in PACSystems RX3i process-control systems
  • Machine measurement systems that require selectable single-ended or differential inputs
  • Rack-based monitoring projects that require configurable analog filtering and diagnostics
Description
IC695ALG616 is a General Electric PACSystems RX3i current and voltage analog input module for rack-based control systems.

The unit provides 16 single-ended or 8 differential channels, selectable current and voltage ranges, a 24-bit converter, configurable input filtering, and open-circuit detection.

Before installation or replacement, confirm the complete catalog number, channel wiring mode, input ranges, terminal assembly, filter selections, scaling, alarms, and saved RX3i configuration.
Revisions

Revision Part #

Also known as

IC695ALG616A
IC695ALG616-A, Series A, Rev A
IC695ALG616B
IC695ALG616-B, Series B, Rev B
IC695ALG616C
IC695ALG616-C, Series C, Rev C
IC695ALG616D
IC695ALG616-D, Series D, Rev D
IC695ALG616E
IC695ALG616-E, Series E, Rev E
IC695ALG616F
IC695ALG616-F, Series F, Rev F
IC695ALG616G
IC695ALG616-G, Series G, Rev G
IC695ALG616H
IC695ALG616-H, Series H, Rev H
IC695ALG616J
IC695ALG616-J, Series J, Rev J
IC695ALG616K
IC695ALG616-K, Series K, Rev K
IC695ALG616L
IC695ALG616-L, Series L, Rev L
IC695ALG616M
IC695ALG616-M, Series M, Rev M
Alternative Names
IC695ALG616 IC695 ALG616 GE IC695ALG616 General Electric IC695ALG616 PACSystems RX3i IC695ALG616
Technical notes
IC695ALG616 requires the wiring mode, per-channel input range, terminal assembly, filter selection, scaling, alarm limits, and saved RX3i configuration to be matched before commissioning.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can General Electric IC695ALG616 accept thermocouples or RTDs directly?
No. The documented inputs are current and voltage ranges. Use an appropriate transmitter or a PACSystems temperature-input module for direct thermocouple or RTD signals.
Does General Electric IC695ALG616 support HART communication?
No. Emerson identifies IC695ALG616 as the non-HART current/voltage input module. Select a documented HART-capable RX3i module when HART communication is required.
Can General Electric IC695ALG616 mix current and voltage channels in one module?
Yes. Channel ranges are configured individually, subject to the selected single-ended or differential wiring arrangement and the saved controller configuration.
What should be checked when a 4...20 mA loop reads low on General Electric IC695ALG616?
Check loop power, polarity, terminal assignment, the 249 Ω input path, channel range, scaling, open-circuit status, and field wiring before replacing the module.
Can General Electric IC695ALG616 replace another RX3i analog input without project changes?
Not automatically. Compare channel count, wiring mode, terminal assembly, range, filter, scaling, alarm handling, and controller configuration before substitution.
Which data format should be preserved when replacing General Electric IC695ALG616?
Preserve whether the project uses IEEE floating-point values or the 16-bit integer format in a 32-bit field, because changing the format affects downstream logic and scaling.
What information should accompany an inquiry for General Electric IC695ALG616?
Provide the complete catalog number, terminal assembly, channel wiring mode, required ranges, filter settings, controller and firmware details, quantity, and clear label photos.
