Features:
- Two-metre bus section: the cable extends an AADvance backplane I/O path
- Base-unit connection: expansion adapters join documented processor and I/O base positions
- Length-controlled architecture: the installed cable counts toward the 8 m I/O bus limit
T9310-02 extends the AADvance I/O bus between base-unit sections rather than carrying ordinary field or Ethernet traffic.
Its engineering value depends on correct endpoint orientation, secure adapters, protected routing, and the cumulative length of every cable on the bus.
A service drawing should retain base identities, physical order, cable lengths, route, bend protection, adapter hardware, and the post-installation module map.
Apter Power can review T9310-02 length, endpoints, base layout, routing, condition, and documentation before quotation.
ICS Triplex T9310-02 AADvance 2 m Backplane Expansion Cable Manuals, Datasheets, Links
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
- Fixed segment: include the 2 m cable in the full I/O bus calculation.
- Total boundary: keep all installed expansion cable within the documented 8 m maximum.
- Route record: document each segment and endpoint before adding another I/O base.
- Bend protection: avoid sharp bends, crushing, or tension behind base units.
- Service clearance: keep module retention and terminal access unobstructed.
- Identification: label both ends for their processor-base and I/O-base positions.
- Correct side: place each expansion adapter in the specified base-unit connector.
- Retaining screws: secure the hardware evenly without forcing alignment.
- Final inspection: verify seating, module order, and I/O-bus status after assembly.
- AADvance I/O expansion: connect a documented T9300 I/O base to the processor-base arrangement.
- Separated cabinet layout: route the expansion bus across a controlled 2 m section.
- Maintenance replacement: restore a damaged expansion cable after endpoint and total-length verification.
