HOFFMAN LHC252015 is a mild-steel INLINE hinged-door enclosure measuring 250 x 200 x 150 mm. It accepts LP2520 or LP2520G panels, which are ordered separately.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for LHC252015
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for LHC252015

  • Manufacturer:
    HOFFMAN
  • Part Number:
    LHC252015
  • Product Family:
    INLINE Hinged-Door Enclosures
  • Product Type:
    INLINE Hinged-Door Enclosure
  • Stock:
    1
  • Panel:
    LP2520
  • Conductive Panel:
    LP2520G
  • Panel Size:
    231 x 181 mm
  • Mounting:
    232 x 135 mm
  • Mild Steel:
    1.5 mm (16 gauge) steel construction
  • Seams:
    Continuously welded and ground smooth
  • Body Flange:
    External formed body flange
  • Body Opening:
    Large perimeter body opening
  • Enclosure Dimensions:
    250 x 200 x 150 mm
  • Gasket:
    Seamless foam-in-place gasket
  • Grounding:
    Grounding stud on body
  • Bonding:
    Provision on cover or door
  • Hardware Kit:
    Includes panel mounting screws, grounding hardware, sealing washers for wall-mounting holes
  • Door Opening:
    180-degree door opening Hinges: Removable hinge pins
  • Latch:
    Self-grounding, slotted quarter-turn latch
  • Weight:
    9.1712 lbs (4.16 kg)
  • Estimated shipping dimensions:
    22.3 x 15.4 x 25 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Installation Standards Operating Environment

Features:

  • INLINE Hinged-Door Enclosures LP2520 provides a rigid mild steel structure with welded seams for stable industrial installation.
  • LP2520G panel design supports flexible mounting options including direct installation and bracket-based configurations.
  • The enclosure integrates grounding and sealing systems to support consistent structural and electrical integrity.
The HOFFMAN LHC252015 INLINE Hinged-Door Enclosures LP2520 is engineered for industrial panel integration where structural stability and organized mounting are required. Its mild steel construction and welded body design help maintain consistent enclosure geometry during installation. The LP2520 system is commonly used in environments where control components need protected housing with stable physical support.

The LP2520G configuration of the HOFFMAN LHC252015 INLINE Hinged-Door Enclosures focuses on installation flexibility, offering multiple mounting options through rear fastening points or external brackets. The large body opening supports easier internal layout arrangement, allowing technicians to configure systems efficiently. This makes the LP2520 series suitable for structured electrical panel builds.

In operational use, the HOFFMAN LHC252015 INLINE Hinged-Door Enclosures LP2520 provides secure access through a full 180-degree door opening and removable hinge system. Combined with grounding and sealing features, the enclosure maintains structural reliability across installation cycles. The LP2520 design ensures stable performance in standardized industrial enclosure applications.

The LHC252015 HOFFMAN INLINE Hinged-Door Enclosures may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Verified resources for HOFFMAN LHC252015: Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
HOFFMAN LHC252015 INLINE Hinged-Door Enclosure Specs

General

  • ManufacturerHOFFMAN
  • ModelLHC252015
  • ConditionNew Original ready stock
  • Product FamilyINLINE Hinged-Door Enclosures
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • The concealed hinge design supports flexible left or right-side door mounting to adapt to limited on-site operating space.
  • The door opens to a maximum angle of 180 degrees, allowing technicians unobstructed access to internal components during maintenance.
  • Pre-drilled mounting holes at the rear of the cabinet, equipped with self-sealing gaskets, ensure a tight seal during wall mounting.
  • Internal sidewalls feature support pillars, allowing for quick adjustment of the mounting plate depth to flexibly accommodate components of different sizes.
  • Compliant with UL 508A certification and NEMA Type 4/12 rating, ensuring high reliability in harsh industrial environments.
  • CSA certified and compliant with IEC 60529 (IP66) international protection standards, effectively preventing dust intrusion and high-pressure spray.
  • Compliant with RoHS directives, with strict control over the use of hazardous substances during manufacturing to meet environmental compliance requirements.
  • The structural design follows universally accepted industrial metric dimensions, ensuring seamless compatibility with mainstream electrical accessories worldwide.
  • The enclosure is intended for indoor industrial locations covered by its published Type 12 and IP66 ratings.
  • A gasketed hinged door helps limit the entry of dust, dirt, oil, and dripping liquids when fully latched.
  • Select a different enclosure if the site exposure exceeds the listed rating or requires corrosion-resistant material.
Description
HOFFMAN LHC252015 is a 250 x 200 x 150 mm INLINE hinged-door enclosure fabricated from mild steel for wall-mounted industrial controls. Continuously welded and smoothed seams create a rigid body, while the formed flange provides a stable sealing surface around the opening.

The hinged door opens widely for maintenance and can be removed using the hinge pins. A foam-in-place gasket supports the published environmental protection, and internal grounding and bonding provisions help integrate the enclosure into a properly designed electrical installation.

LP2520 and LP2520G mounting panels are sized for the enclosure but are ordered separately. Selection should also account for wall clearances, external mounting brackets, cable-entry work, site exposure, and the certifications required for the finished assembly.
Alternative Names
HOFFMAN LHC252015 HOFFMAN LHC 252015 LHC-252015 nVent HOFFMAN LHC252015 HOFFMAN INLINE LHC252015 LHC252015 Hinged-Door Enclosure HOFFMAN 250 x 200 x 150 mm LHC252015 LHC252015 Mild-Steel Wall-Mount Enclosure
Technical notes
For LHC252015, verify cabinet clearance and LP2520 panel fit before installation; mounting brackets are required to meet UL/CSA external-mounting requirements.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How does the hinged door help service HOFFMAN LHC252015?
The door opens widely and uses removable hinge pins, giving technicians access to mounted controls without removing the enclosure body.
Which internal panel fits HOFFMAN LHC252015?
Use the LP2520 or LP2520G panel listed for this enclosure size; panels are separate accessories and are not included automatically.
When are external mounting brackets required for HOFFMAN LHC252015?
Use the specified external brackets when the installation must meet the published UL or CSA external-mounting arrangement.
Can another INLINE enclosure directly replace HOFFMAN LHC252015?
Only after confirming enclosure dimensions, door style, panel fit, mounting pattern, material, gasket, and required environmental rating.
What site exposure should be checked for HOFFMAN LHC252015?
Confirm that the indoor location and dust or liquid exposure remain within the published Type 12 and IP66 ratings.
Which details are needed to quote HOFFMAN LHC252015?
Provide the full model, quantity, door and latch condition, panel requirement, mounting method, destination, and applicable certification needs.
