8C-TAIX51 51306979-175

/ 4.9
1001 reviews | Need a Specific Revision?
Honeywell 8C-TAIX51 51306979-175 is a coated, non-redundant Series C analog input IOTA for sixteen 4–20 mA channels. It terminates two-wire transmitters and supports selected self-powered inputs.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 8C-TAIX51 51306979-175
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 8C-TAIX51 51306979-175

  • Manufacturer:
    Honeywell
  • Part Number:
    8C-TAIX51 51306979-175
  • Product Family:
    Honeywell Experion PKS ( C200, C300 )
  • Product Type:
    Analog Input IOTA module
  • Stock:
    1
  • Input Type:
    current (2-wire or self-powered transmitters)
  • Input Channels:
    16 Channels (All 16 Single Ended)
  • A/D Converter Resolution:
    16 bits
  • Input Range:
    4-20 mA (through 200 Ω)
  • Normal Mode Rejection Ratio, at 60 Hz:
    19 dB
  • Input Scan Rate:
    50 ms
  • Normal Mode Filter Response:
    Single-pole RC, -3 dB @ 6.5 Hz
  • Crosstalk, dc to 60 Hz (channel-to-channel):
    -60 dB
  • Weight:
    0.5732 lbs (0.26 kg)
  • Estimated shipping dimensions:
    14.5x12x6.5cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Installation Environmental Ratings Monitoring & Control

Features:

  • The coated IOTA provides cabinet termination for sixteen single-ended analog current channels.
  • Each input path is intended for compatible 4-20 mA two-wire or self-powered transmitters.
  • Integrated conditioning includes conversion, filtering, and channel-to-channel isolation performance defined for Series 8 analog input service.
The current order identity is the coated 8C-TAIX51 IOTA and must not be conflated with uncoated or alternate-channel assemblies.

It brings multiple process-transmitter loops into the Series 8 analog input signal chain at the cabinet termination layer.

Confirm paired electronics, connector keying, cabinet position, shunt arrangement, loop polarity, and field drawings before installation.

Availability is reviewed against the exact coated IOTA identity and requested supply condition.
Verified resources for Honeywell 8C-TAIX51 51306979-175:Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Terminates sixteen two-wire transmitter loops for Series C process measurements.
  • Supports pressure, flow, level, temperature, and other compatible 4–20 mA field signals.
  • Fits non-redundant Experion I/O cabinets that use the approved analog-input electronics.
  • Match the non-redundant connector layout, keying, and cabinet position before mounting.
  • Maintain loop polarity, shield routing, and channel allocation from the approved field drawing.
  • Isolate field energy and inspect terminal condition before transferring conductors.
  • The coated IOTA is intended for protected industrial cabinet installation.
  • Cabinet sealing, contamination control, and grounding provide the environmental protection for the open assembly.
  • Do not assign an enclosure rating to the IOTA independently of the completed cabinet.
  • Channel values are processed by the paired Series C analog-input electronics.
  • Field-short protection supports fault containment but does not replace loop testing and alarm review.
  • Compare transmitter output, terminal voltage, engineering value, and controller diagnostics during troubleshooting.
Description
Honeywell 8C-TAIX51 is a Series 8 analog-input IOTA that terminates sixteen single-ended current channels for the matching input electronics. It supports both two-wire and self-powered transmitters used for 4–20 mA process measurements.

The assembly organizes field-loop connections and links them to the Series 8 module so the controller can acquire, filter, and convert the channel signals. The documented input network and scan behavior support stable measurement of pressure, flow, level, temperature-transmitter, and other continuous variables.

Installation must match the assigned Series 8 electronics, IOTA keying, channel terminal map, shield practice, and loop-power polarity. De-energize affected circuits before moving conductors, then verify zero, span, and channel identification through the control system after replacement.
Alternative Names
8C-TAIX51 8C TAIX51 8CTAIX51 Honeywell 8C-TAIX51 Honeywell 8C TAIX51 Honeywell 8CTAIX51 Honeywell Series 8 8C-TAIX51 8C-TAIX51 Analog Input IOTA
Technical notes
Match 8C-TAIX51 51306979-175 with the non-redundant Series C input assembly and observe the documented field-short protection limits when landing two-wire transmitters.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How is Honeywell 8C-TAIX51 51306979-175 distinguished from adjacent IOTAs?
Match the complete coated, non-redundant analog-input IOTA identity and reject alternate channel or redundancy variants unless engineering approves them.
What must mate with Honeywell 8C-TAIX51 51306979-175?
Confirm the approved Series C analog-input electronics, connector alignment, cabinet position, loop polarity, and field-wiring drawing.
Which signals are commonly terminated on Honeywell 8C-TAIX51 51306979-175?
It accepts two-wire analog transmitter loops used for process measurements such as pressure, flow, level, and temperature.
How does Honeywell 8C-TAIX51 51306979-175 protect field wiring?
The documented Series C input design provides field-short protection; installation must remain within the published circuit limits.
Why is keying important when replacing Honeywell 8C-TAIX51 51306979-175?
The IOTA must preserve the original electronics pairing, channel allocation, shield routing, and loop-power assignments.
Which records support a Honeywell 8C-TAIX51 51306979-175 quotation?
Provide the full product code, paired electronics, cabinet photographs, required condition, quantity, destination, and delivery date.
