CC-HCN911

/ 4.9
1001 reviews | Need a Specific Revision?
Honeywell CC-HCN911 is a coated horizontal C300/CF9 IOTA PWA that combines Series C controller and control-firewall termination on the UHIO backplane.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for CC-HCN911
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for CC-HCN911

  • Manufacturer:
    Honeywell
  • Part Number:
    CC-HCN911
  • Product Family:
    Honeywell Experion PKS ( C200, C300 )
  • Product Type:
    Horizontal C300/CF9 IOTA PWA, Coated
  • Stock:
    1
  • Assembly type:
    Horizontal C300/CF9 IOTA PWA, coated
  • Board function:
    Combined C300 and CF9 IOTA
  • Module pairing:
    CC-PCNT02 and CC-PCF901
  • Mounting platform:
    UHIO horizontal backplane
  • Board dimensions:
    8.66 x 8.37 in
  • Operating temperature:
    0 to +60 deg C
  • Transport and storage:
    -40 to +85 deg C
  • Relative humidity:
    5 to 95% non-condensing
  • Tariff Code:
    8538900000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications UHIO Role Module Pairing Installation

Features:

  • Combined C300 controller and nine-port Control Firewall IOTA functions on one coated horizontal board.
  • IOTA interface for the CC-PCNT02 controller and CC-PCF901 firewall.
  • UHIO migration support for compatible TDC 2000 terminal panels and retained field wiring.
The common horizontal layout places the controller and firewall termination functions on a single 8.66 x 8.37 inch assembly.

Within a UHIO cabinet, the board links Series C processing hardware to the horizontal backplane used for selected TDC 2000 Basic Controller and Extended Controller migrations.

Its coated construction, dedicated backplane mounting, and Series C environmental range suit long-term controller modernization projects.

Apter Power can assist with UHIO configuration matching, official documentation, and pricing for the Honeywell CC-HCN911 Horizontal C300/CF9 IOTA PWA, Coated.
Honeywell CC-HCN911 Horizontal C300/CF9 IOTA PWA, Coated Manuals, Datasheets, Links
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Honeywell CC-HCN911 Horizontal C300/CF9 IOTA PWA, Coated Specs

General

  • ManufacturerHoneywell
  • ModelCC-HCN911
  • ConditionNew Original ready stock
  • Product FamilyHoneywell Experion PKS ( C200, C300 )
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

CC-HCN911 Horizontal Migration Function

  • Purpose: Combines the C300 and CF9 IOTA functions on one horizontal board.
  • Migration: Supports UHIO arrangements used when replacing TDC 2000 CB or EC racks.
  • Retained wiring: The documented migration approach retains the existing TCB terminal panels and field wiring.
  • Backplane: The board mounts on the dedicated UHIO horizontal backplane.

CC-HCN911 Controller and Firewall Matching

  • Controller: The UHIO component table identifies CC-PCNT02 as the C300 module.
  • Firewall: The matched control-firewall module is CC-PCF901 with nine ports.
  • Assembly: Both modules share the horizontal C300/CF9 IOTA.
  • Verification: Confirm module identities and UHIO configuration before replacement.

CC-HCN911 Backplane Installation Checks

  • Mounting: Align the IOTA with the horizontal backplane mounting provisions.
  • Grounding: Maintain the protective-earth connection required by the Series C installation guide.
  • Power state: Install or remove components only under the documented safe power conditions.
  • Configuration: Match the cabinet layout, controller, firewall, and connected UHIO hardware.
Description
CC-HCN911 is a coated horizontal IOTA assembly that combines the C300 controller termination and nine-port Control Firewall termination on one board. Its integrated layout provides the mounting and electrical interface for the CC-PCNT02 controller and CC-PCF901 firewall within a Universal Horizontal I/O configuration.

In a UHIO migration assembly, CC-HCN911 connects the Series C controller and firewall hardware to a horizontal backplane designed around retained TDC 2000 terminal panels and field wiring. This arrangement supports controller modernization without rebuilding the complete field-termination layer.

The 8.66 x 8.37 inch CC-HCN911 board is installed on the dedicated horizontal backplane and is designed for the Series C cabinet environment. The coated construction supports industrial use across the specified 0 to +60 deg C operating range and 5 to 95% non-condensing humidity.
Alternative Names
CCHCN911 CC HCN911 Honeywell CC-HCN911 Honeywell CC HCN911 HNW CC-HCN911 CC-HCN-911 HCN911 C300 CF9 IOTA Honeywell Horizontal C300 CF9 IOTA
Technical notes
CC-HCN911 is Honeywell's coated 8.66 x 8.37 inch horizontal C300/CF9 IOTA PWA. It mounts on the UHIO horizontal backplane with the Series C controller and nine-port control firewall.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is Honeywell CC-HCN911?
Honeywell CC-HCN911 is a coated horizontal C300/CF9 IOTA PWA for a Series C UHIO assembly.
Which modules mount on CC-HCN911?
CC-HCN911 is documented with the Honeywell CC-PCNT02 C300 controller and CC-PCF901 nine-port control firewall.
Where is CC-HCN911 installed?
CC-HCN911 mounts on the UHIO horizontal backplane used in Honeywell controller migration configurations.
What are the CC-HCN911 board dimensions?
CC-HCN911 is documented as an 8.66 x 8.37 inch C300/CF9 IOTA combination board.
Can CC-HCN911 be selected by model alone?
CC-HCN911 selection should also confirm the horizontal backplane, controller, firewall, cabinet layout, and UHIO configuration.
What environment is documented for CC-HCN911?
CC-HCN911 belongs to the UHIO hardware covered by the Series C environmental table, including 0 to +60 deg C operation.
Where can customers request CC-HCN911 documentation?
Customers can request CC-HCN911 documentation, configuration review, and quotation support from Apter Power.
