CC-TDIL01 51308386-175

/ 4.9
1001 reviews | Need a Specific Revision?
The Honeywell CC-TDIL01 (51308386-175) is a non-redundant 9-inch Series C IOTA for the 32-channel 24 VDC digital input function.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for CC-TDIL01 51308386-175
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for CC-TDIL01 51308386-175

  • Manufacturer:
    Honeywell
  • Part Number:
    CC-TDIL01 51308386-175
  • Product Family:
    Honeywell Experion PKS ( C200, C300 )
  • Product Type:
    Series C Digital Input 24 V IOTA, Non-Redundant
  • Stock:
    1
  • Assembly Type:
    Digital Input 24 V IOTA
  • Redundancy:
    Non-redundant
  • IOTA Size:
    9 in
  • Input Channels:
    32
  • DI Power Voltage:
    18 to 30 VDC
  • Isolation:
    Optical in paired IOM
  • Input Filter Delay:
    5 ms ±20%
  • Weight:
    0.38 kg
  • Estimated shipping dimensions:
    22x12x6.8cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Compatibility Installation

Overview

  • Order configuration: CC-TDIL01, part number 51308386-175.
  • Non-redundant Series C Digital Input 24 V IOTA.
  • 9-inch field-termination assembly for the compatible 32-channel IOM.

The associated digital input function uses an 18 to 30 VDC field-power range.

General

  • ManufacturerHoneywell
  • ModelCC-TDIL01 51308386-175
  • ConditionNew
  • Product FamilyHoneywell Series C I/O

Applications

  • Field termination for the compatible Series C 24 V digital input IOM.
  • 32-channel discrete input assemblies in Experion PKS systems.
  • Non-redundant IOTA installations using the 9-inch form factor.

Compatibility

  • Use with the matched Series C Digital Input 24 V IOM.
  • CC-TDIL01 is non-redundant; CC-TDIL11 is the separate redundant IOTA configuration.
  • Verify terminal plug-in assemblies, field power, and channel wiring.

Installation

  • Confirm the 9-inch IOTA mounting requirement.
  • Check the 18 to 30 VDC field-power range before connection.
  • Follow the Honeywell Series C I/O User Guide for wiring and maintenance procedures.
Description

The Honeywell CC-TDIL01 (51308386-175) is a non-redundant Digital Input 24 V IOTA in the Series C I/O family. It provides field termination for the compatible 32-channel digital input IOM.

Honeywell documentation lists CC-TDIL01 as a 9-inch non-redundant IOTA. The associated digital input function uses an 18 to 30 VDC field-power range and optical isolation in the paired IOM.

Verify the complete part number, paired IOM, terminal plug-in assemblies, field power, and channel wiring before replacement.

Alternative Names
CC-TDIL01 51308386-175 CC TDIL01 51308386 175 CCTDIL01 51308386175 CC-TDIL01 51308386-175 Honeywell CC-TDIL01 Honeywell 51308386-175 Series C Digital Input 24 V IOTA
Technical notes
CC-TDIL01 51308386-175 is a non-redundant 9-inch Series C Digital Input 24 V IOTA. Confirm the paired IOM, field power, and terminal configuration before replacement.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is CC-TDIL01 51308386-175?
It is a non-redundant Honeywell Series C IOTA for the 24 V digital input function.
How many digital input channels are associated with this IOTA?
The compatible Series C digital input function provides 32 channels.
What field-power range is specified?
The associated digital input function uses an 18 to 30 VDC field-power range.
What is the size and redundancy configuration?
CC-TDIL01 is a 9-inch non-redundant IOTA.
Where is optical isolation provided?
Optical isolation is provided in the paired digital input IOM.
How should replacement compatibility be checked?
Verify the complete part number, paired IOM, terminal assemblies, field power, and channel wiring.
How can I request documentation, availability, or a quote?
Contact Apter Power with model CC-TDIL01 51308386-175, the required quantity, and the installed IOM information.
