Features:
- Official ordering identity FS-CPCHAS-0001 V1.1
- 4HE chassis measuring 482.6 mm wide by 280 mm deep
- Documented assembly weight of 5.8 kg
The FS-CPCHAS-0001 V1.1 designation identifies the Safety Manager controller chassis version covered by Honeywell hardware documentation. It is the controller-housing order code, not an I/O chassis or backplane part number.
The chassis carries CE, UL, CSA, TUV, and FM approvals. These approvals belong to the documented FS-CPCHAS-0001 assembly and should not be transferred to adjacent Safety Manager ordering codes.
Honeywell withdrew FS-CPCHAS-0001 from sale on November 1, 2020 and identified FS-CPCHAS-0003 as the successor chassis. The complete installed code and version should be retained when reviewing an existing cabinet.
Honeywell FS-CPCHAS-0001 Safety Manager Controller Chassis is listed as Discontinued / Obsolete by OEM. Apter Power provides quotation assistance and access to official manufacturer documentation.
Honeywell FS-CPCHAS-0001 Safety Manager Controller Chassis Manuals, Datasheets, Links
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Front and rear construction
- Open front: Controller modules enter the chassis through front-facing guide channels.
- Covered rear: A rear enclosure protects the controller backplane area from routine access.
- Magnetic closure: The back cover uses magnetic retention for controlled removal during service.
- Module locks: Quarter-turn fasteners hold inserted modules securely in their operating positions.
V1.1 feeder loading
- 5V-1 demand: Version V1.1 draws 0.05 A from the first 5 V feeder.
- 5V-2 demand: The second 5 V feeder also carries a documented 0.05 A chassis load.
- Dual paths: Separate feeder values support cabinet power-budget calculations for the two controller supply paths.
- Version check: Use the V1.1 suffix when applying these low chassis-consumption figures.
Rear cable bar assignments
- Upper bar: Route 24 V power and 24 V signal wiring along the top cable support.
- Center bar: Keep controller communication cables on the middle horizontal support.
- Lower bar: Place 5 V and watchdog conductors on the bottom cable support.
Controller assembly relationships
- Single path: The chassis can carry a non-redundant Safety Manager controller arrangement.
- Redundant path: A redundant build duplicates the applicable controller modules across two processing sides.
- Shared module: The Battery and Key switch module remains common to both sides of a redundant controller.
- Cabinet position: The controller chassis is normally positioned above the associated I/O chassis.
