Features:
- Connection Between the UCN Network Infrastructure and Honeywell TDC 3000/TPS DCS Nodes
- Integrates RG-11 Coaxial Cable Construction with Pre-Assembled BNC Connector Termination
- Functions in Conjunction with the Universal Control Network and Standard Honeywell Process Control Modules
The 51195199-010 serves as the UCN Trunk Cable Set in a Honeywell distributed control system, providing reliable signal transmission between all nodes across the network. It continuously carries communication signals across a standard 10-meter length with 75-ohm characteristic impedance and distributes these signals through BNC connectors to support steady state operation of all UCN devices and modules. Consistent signal integrity is standard with the 51195199-010, however using proper cable routing and shielding practices will allow seamless network performance in the event of electromagnetic interference or environmental disturbances. The 51195199-010 has been designed to meet the demanding requirements of industrial process control networks in addition to incorporating pre-assembled connector capability within the UCN infrastructure.
The 51195199-010 provides essential communication functions common to the entire UCN network, and is a critical component of the control system data path, directly affecting the proper, normal operation of the overall monitor and control system. One or more 51195199-010 cable sets are required per network depending on the desired node spacing and physical layout. The 51195199-010 occupies routing space between UCN nodes and is always installed along the dedicated UCN trunk path connecting all network devices.
For extended network applications, the Honeywell UCN system requires additional 51195199-010 cable sets or related length variants installed between distant nodes. In addition to standard single segment operation, the UCN network configuration also supports proper termination. The UCN cable system maintains signal quality using the impedance-matched construction specified in the cable design. Using this method, the UCN network continually monitors the health of signal transmission. If the system detects that a cable segment is no longer providing stable signal transmission (outside configured impedance/tolerance levels), it will indicate communication faults and require inspection or replacement of the affected 51195199-010 cable set.
The 51195199-010 Honeywell CABLE SET may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Honeywell 51195199-010 CABLE SET Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Honeywell 51195199-010 CABLE SET Specs
General
- Manufacturer Honeywell
- Model 51195199-010
- Condition New Original ready stock
- Product Family 51195199-005,51195199-020,51195199-030
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
- Process Automation: Facilitates high-speed data communication between controllers, I/O modules, and workstations.
- System Networking: Serves as the backbone for Honeywell Universal Control Networks, connecting specialized process hardware.
- Industrial Connectivity: Ideal for power plants, chemical refineries, and pharmaceutical manufacturing where reliable network uptime is critical.
- Shielding & EMC: Features double-shielded RG-11 coaxial construction to provide superior Electromagnetic Interference (EMI) and Radio Frequency Interference (RFI) protection.
- Chemical & Physical Resistance: The outer jacket is typically made of FEP (Fluorinated Ethylene Propylene) or Teflon, offering extreme resistance to oils, chemicals, and UV radiation.
- Signal Integrity: Precision 75-ohm impedance matching and high-quality BNC connectors ensure low signal attenuation and prevent data packet loss.
- Flame Retardancy: Meets Plenum-rated standards (e.g., UL 910), ensuring the cable does not emit toxic smoke or spread flames in air ducts or confined spaces.
- Operating Temperature: -40°C to +85°C (-40°F to +185°F).
- Storage Temperature: -55°C to +100°C.
- Humidity: 5% to 95% RH (Non-condensing).
- Ingress Protection: Rated IP67 (when properly mated) to resist dust and moisture penetration.
