        RH101DF

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        Foxboro RH101DF is the exact-order Compact FBM217 module used for 32-channel discrete input acquisition on a Compact 200 Series baseplate.
        In Stock
        Ships by Saturday, October 17
        Fast Shipping Available
        Get a quick price for RH101DF
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for RH101DF

        • Manufacturer:
          Invensys
        • Part Number:
          RH101DF
        • Product Family:
          Foxboro
        • Product Type:
          Compact FBM217 Discrete Input Module
        • Stock:
          1
        • Input channels:
          32 group-isolated channels
        • On-state voltage:
          15 to 30 VDC
        • Off-state voltage:
          0 to 5 VDC
        • Maximum pulse count rate:
          250 Hz
        • Filter / debounce:
          No filtering, 4, 8, 16 or 32 ms
        • Baseplate:
          Compact 200 Series 16-slot horizontal baseplate
        • Termination cable:
          Type 4 to main TA; Type 6 to expansion TA
        • Maximum cable length:
          30 m
        • Dimensions:
          2.5 × 13.0 × 15.0 cm
        • Power consumption:
          3 W
        • Heat dissipation:
          5 W
        • Operating temperature:
          -20 to +60°C
        • Storage temperature:
          -40 to +70°C
        • Relative humidity:
          5 to 95%, non-condensing
        • Vibration:
          0.75 g from 5 to 500 Hz
        • Weight:
          0.185 kg
        • Tariff Code:
          8538900000
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen, Fujian, China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Input Architecture Termination Strategy Commissioning Application
        • Confirm the exact RH101DF label rather than relying on the FBM217 family name
        • Match the selected voltage-monitor or contact-sense termination assembly to the field circuit
        • Preserve the main and expansion TA cable arrangement before replacement

        Foxboro RH101DF is the exact-order Compact FBM217 discrete input module for 32-channel status acquisition.

        Selection depends on the field voltage, contact-sense method, required isolation and the matching termination assembly rather than on the module alone.

        Before installation, record baseplate position, TA numbers, Type 4/Type 6 cables, channel mapping and configured debounce values.

        Availability, condition, price, and shipping time for RH101DF are confirmed during quotation.

        Foxboro RH101DF Manuals, Datasheets, Links

        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        • 32 group-isolated discrete input channels
        • Configurable debounce supports stable field-status acquisition
        • Pulse counting is supported within the documented 250 Hz limit
        • TA selection determines voltage, contact-sense and isolation behavior
        • Type 4 cable connects the baseplate to the main TA
        • Type 6 cable links a compatible main TA to its expansion TA
        • Restore the exact slot and channel map before enabling logic
        • Prove every main and expansion TA terminal against the database
        • Verify redundancy and event timing where configured
        • Dense discrete-status acquisition in Compact 200 Series stations
        • Contact-sense monitoring with a documented matching TA
        • Voltage-state monitoring using an approved RH101DF termination arrangement
        Description
        Foxboro RH101DF samples 32 discrete channels and transfers their states to an associated control processor over the redundant 2 Mbps Module Fieldbus.

        Its input behavior is set by the installed termination assemblies, allowing supported low-voltage monitoring, contact sensing and selected high-voltage interfaces without changing the module identity.

        The module is used where dense field-status acquisition, optional redundancy and sequence-of-events support are required in Compact 200 Series stations.
        Alternative Names
        RH 101 DF Foxboro RH101DF Invensys Foxboro RH101DF Compact FBM217 RH101DF FBM217 RH101DF Foxboro FBM217 RH101DF
        Technical notes
        RH101DF is the module order number for Compact FBM217. Confirm all termination assemblies and both termination-cable types separately; they are not implied by the module number.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        Can Foxboro RH101DF replace a standard FBM217 without checking the baseplate?
        No. RH101DF mounts on the Compact 200 Series 16-slot horizontal baseplate, so the physical platform, fieldbus arrangement and termination-cable interface must match.
        Which termination assembly should be ordered with Foxboro RH101DF?
        Choose it from the exact field circuit: voltage level, contact-sense power source, isolation method and terminal style. The official matrix lists different TAs for these arrangements.
        Can Foxboro RH101DF use only one termination assembly for all 32 channels?
        Some installations use a main TA plus an expansion TA. Confirm the selected TA family and whether all 32 channels require both assemblies before ordering cables.
        Why can half the channels remain offline after replacing Foxboro RH101DF?
        Inspect the main-to-expansion Type 6 cable, expansion TA power or commons, connector seating and the channel declaration in the control database.
        Can Foxboro RH101DF be used for high-speed pulse counting?
        It supports the documented pulse-count function up to 250 Hz, but it is not a substitute for a dedicated high-speed counter when the signal exceeds that limit or needs different timing behavior.
        What must be recorded before removing Foxboro RH101DF?
        Record the baseplate slot, main and expansion TA part numbers, both cable part numbers and lengths, channel-to-terminal map, debounce settings, redundancy pairing and active forcing.
        How should Foxboro RH101DF be validated after installation?
        Check every input from the field terminal through the control database, verify debounce and alarm behavior, test any redundant partner, and confirm safe sequence-of-events handling under controlled conditions.
