The DELTA 603871-108 is designed for handling complex multi-axis motion control tasks in industrial automation environments, achieving precise timing and real-time response.
Get a quick price for 603871-108
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 603871-108

  • Manufacturer:
    Jetter AG
  • Part Number:
    603871-108
  • Product Family:
    DELTA
  • SRAM Memory:
    256K×24 (for compiled/assembled programs)
  • Flash Memory:
    1M×8 (for user backup and firmware)
  • Maximum Axes Control:
    32 axes
  • Transmission Rate:
    125 Mbits/sec
  • USB Interface:
    USB 2.0
  • Ethernet Interface:
    Supported
  • Serial Interface:
    RS-232
  • Weight:
    0.23 kg
  • Estimated shipping dimensions:
    0.38cm×1.08cm×2.3cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Certifications & Standards Compatibility & Interoperability

Features:

  • Interface Between the Host PC and Multi-Axis Motion Control Systems
  • Combines Capability of High-Speed Motion Processing with Distributed MACRO Ring Control
  • Operates in Conjunction with UMAC MACRO, Geo MACRO Drives and Third-Party MACRO Devices
The DELTA 603871-108 operates as the Turbo Clipper Controller in a PMAC2A-ETH motion control system, providing reliable real-time control to all servo axes within the network. It continuously processes motion commands through an 80 MHz DSP56303 Turbo PMAC CPU and distributes precise control signals through the MACRO ring to support synchronized operation of all drives and motors. Seamless communication is standard with the DELTA 603871-108, however using an optional Redundant Power Configuration will allow seamless switchover to a backup supply in the event of a primary power failure. The DELTA 603871-108 has made improvements in several areas over previous PMAC2 designs in addition to incorporating universal communication capability through USB 2.0, Ethernet and RS-232 interfaces within the motion control architecture.

The DELTA 603871-108 provides essential control functions common to the entire motion system, and is a critical component of the servo control path, directly affecting the proper, normal operation of the overall multi-axis control system. One DELTA 603871-108 controller is required per MACRO ring depending on the desired axis count (up to 32 axes). The DELTA 603871-108 occupies a compact standalone enclosure measuring 38mm × 180mm × 230mm and can be mounted in standard industrial control cabinets.

For High-Axis-Count applications, the PMAC2A-ETH System requires proper configuration of the DELTA 603871-108 controller with appropriate optional interfaces. In addition to standard single-controller operation, the system also performs automatic error detection and correction. The PMAC2A-ETH dual-port RAM configuration executes high-speed data exchange using the internal dual-ported RAM specified in the controller options (Opt 2B). Using this method, the control system continually monitors the health of all servo loops. If the system detects that any axis is no longer following the commanded trajectory (outside configured position/velocity tolerance levels), it will automatically apply corrective action and update the servo status registers.

The DELTA 603871-108 Delta Tau Turbo Clipper Controller may still be available for purchase and support from authorized distributors beyond End-Of-Life (EOL) by the manufacturer (OEM).

DELTA 603871-108 industrial motion control board Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
DELTA 603871-108 industrial motion control board

General

  • Manufacturer DELTA
  • Model 603871-108
  • Condition New Original ready stock
  • Product Family 603871108,603871-109
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Precision Manufacturing: Used in machine tools requiring high-speed, synchronized motion.
  • Specialized Machinery: Integration into woodworking machines, adhesive machines, and printing presses.
  • Entertainment & Robotics: Delta Tau controllers have been used for complex stage automation (e.g., Cirque du Soleil) and industrial robotics.
  • Process Control: Suitable for applications requiring high-resolution current sensing and nano-scale linear positioning.
  • CE Certification: Compliant with European safety and environmental standards.
  • IEC 61131-2: Standard for programmable controllers, specifically regarding vibration and shock resistance.
  • IEC 61131-3: Software compatibility for programming languages (LD, ST, FBD, etc.) through platforms like CODESYS or Delta's ISPSoft.
  • IP20 Rating: Standard protection against solid objects, intended for installation within industrial electrical cabinets.
  • Fieldbus Protocols: Supports high-speed communication via EtherCAT, MACRO, and DMCNET for controlling remote I/O and servo drives.
  • Hardware Interface: Often features RS-232/RS-422 serial interfaces and VME or PCI bus connectivity for integration with industrial PCs.
  • Peripheral Connectivity: Interoperable with various Delta/Omron hardware, including ASDA-A2/A3 servo drives and remote I/O modules.
  • Software Systems: Compatible with Windows-based environments (such as Windows 10 IoT) and real-time operating systems for advanced HMI and PLC integration.
Description
DELTA 603871-108 is a high-performance Turbo Clipper controller from Delta Tau Data Systems' PMAC2A-ETH series, designed specifically for handling complex multi-axis motion control tasks in industrial automation environments. This controller addresses the critical challenge of synchronizing multiple servo motors with precision timing and real-time responsiveness, solving the problem of coordination errors that often plague distributed motion control systems.

DELTA 603871-108 features an 80 MHz DSP56303 Turbo PMAC CPU processor, paired with 256K×24 SRAM for compiled/assembled program storage and 1M×8 flash memory dedicated to user backup and firmware retention. DELTA 603871-108 supports versatile communication interfaces including USB 2.0, Ethernet, and RS-232 serial ports, enabling seamless integration with PC-based control systems. This controller is engineered for standalone MACRO ring controller applications, allowing simplified wiring connections to UMAC MACRO, Geo MACRO drives, and third-party MACRO devices through high-speed fiber optic or twisted-pair copper cabling with RJ45 connectors.

DELTA 603871-108 delivers exceptional motion control capabilities, managing up to 32 axes simultaneously with a transmission rate of 125 Mbits/sec. The controller enables closed-loop current and servo loop control directly on the MACRO ring, providing users with flexible options for distributed intelligence or centralized control architectures. DELTA 603871-108 incorporates two channels of accessory interface circuits per channel, offering differential/single-ended encoder inputs, configurable output command signals in pulse-plus-direction or PWM upper/lower pair modes, ±10V DAC outputs, and dual 12-bit ADC channels. Additionally, DELTA 603871-108 provides direct I/O interface ports for convenient external device connectivity.

DELTA 603871-108 supports multiple optional configurations including MACRO ring fiber optic interface (Opt A), MACRO ring RJ45 interface (Opt C), 32K×16 dual-ported RAM (Opt 2B), and ModBus communication protocol (Opt 15F). This motion control board is specifically designed for high-performance industrial automation applications such as robotic control systems, CNC machine tools, semiconductor manufacturing equipment, packaging machinery, and any application requiring precise multi-axis coordinated motion with real-time synchronization and deterministic control performance.
