DKC03.3-100-7-FW

/ 4.9
1001 reviews | Need a Specific Revision?
Bosch Rexroth Indramat DKC03.3-100-7-FW is a 100 A ECODRIVE03 servo drive controller with PROFIBUS-DP interface, an integrated mains power section and separately selected application firmware.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for DKC03.3-100-7-FW
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DKC03.3-100-7-FW

  • Manufacturer:
    Rexroth
  • Part Number:
    DKC03.3-100-7-FW
  • Product Family:
    Rexroth
  • Product Type:
    ECODRIVE03 Servo Drive Controller
  • Stock:
    1
  • Command communication:
    PROFIBUS-DP interface
  • Mains connection:
    1 × AC or 3 × AC 200–480 V, ±10%; 50–60 Hz ±2 Hz
  • Switching frequency:
    4 or 8 kHz
  • Type current / peak current 1:
    100 A
  • Peak current 2:
    40 A at 4 kHz; 32 A at 8 kHz
  • Continuous current:
    32–40 A at 4 kHz; 21–32 A at 8 kHz, duty dependent
  • Maximum output frequency:
    400 Hz at 4 kHz; 800 Hz at 8 kHz
  • DC bus voltage:
    300–800 V DC
  • DC bus capacitance:
    0.675 mF ±20%
  • Device power dissipation:
    420 W, excluding internal bleeder dissipation
  • Braking data:
    120 kW peak; 0.5 kW continuous; 31 kWs maximum energy dissipation
  • Internal dynamic brake:
    6 ohms
  • 24 V control input:
    19.2–28.8 V DC; 25 W without external loads
  • Protection / cooling:
    IP20; internal forced-air cooling, approximately 48 m³/h
  • Ambient temperature:
    +5 to +45°C at rated data; derated operation to +55°C
  • Storage temperature:
    -30 to +85°C
  • Maximum humidity:
    95% RH; no condensation
  • Dimensions:
    10.5 × 36.0 × 21.0 cm
  • Weight:
    9.7 kg
  • Tariff Code:
    8503009090
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals PROFIBUS Mapping Power Integration Motion Validation Application
  • Match the complete DKC03.3-100-7-FW type code and separately ordered firmware before replacement
  • Preserve the PROFIBUS-DP network configuration, addressing and physical topology
  • Record mains, DC-bus, motor, feedback, brake and machine parameters before removal

DKC03.3-100-7-FW is a Bosch Rexroth ECODRIVE03 servo drive controller with a PROFIBUS-DP interface.

Its complete type code identifies the DKC03 hardware series, design version, 100 A current class and voltage code 7. The FW suffix denotes separately selected application firmware.

Before installation, verify the complete nameplate, firmware, PROFIBUS-DP configuration, mains and DC-bus design, motor compatibility, wiring and approved commissioning file.

Availability, condition, price, and shipping time for DKC03.3-100-7-FW are confirmed during quotation.

Bosch Rexroth DKC03.3-100-7-FW ECODRIVE03 Servo Drive Controller Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Restore the station address and documented bus termination
  • Match GSD project, I/O lengths and command/status mapping
  • Verify connector direction, shield bonding and baud-rate cable limits
  • Review the 100 A branch protection and DC-bus grouping
  • Verify precharge, regeneration and internal dynamic-brake design
  • Maintain the documented 48 m³/h airflow and cabinet clearances
  • Prove stable cyclic data before enabling motion
  • Test each PLC command/status function at low load
  • Validate positioning, braking, current limits and bus recovery
  • PROFIBUS-DP-controlled handling and mounting systems
  • PROFIBUS-DP packaging and foodstuff machine axes
  • PROFIBUS-DP machine-tool positioning axes
Description
DKC03.3-100-7-FW is a Bosch Rexroth Indramat ECODRIVE03 drive controller with a PROFIBUS-DP command interface for PLC-integrated motion systems.

The 100 A, voltage-code 7 unit accepts 1 × AC or 3 × AC 200–480 V mains, supports 4 or 8 kHz switching, and provides an internal 6 Ω dynamic-brake path with forced-air cooling.

For replacement, retain the PROFIBUS station address, connector direction, bus termination, shield bonding, GSD and I/O mapping, and separately selected application firmware before motion is enabled.
Alternative Names
DKC03.3-100-7-FW DKC03 3 100 7 FW DKC0331007FW Bosch Rexroth DKC03.3-100-7-FW Rexroth DKC03.3-100-7-FW
Technical notes
DKC03.3-100-7-FW is the 100 A drive-controller hardware identity; application firmware is separate. Match the PROFIBUS-DP interface, power design, motor/feedback system and approved parameters before replacement.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which PROFIBUS project data must agree with DKC03.3-100-7-FW?
Match the station address, connector direction, end termination, baud-rate cable limits, shield bonding, GSD or PLC project entry, cyclic I/O lengths, command/status mapping and application firmware.
Can DKC03.3-100-7-FW replace DKC03.3-040-7-FW without cabinet and power changes?
No. The 100 A controller is wider and has different current, cooling, DC-bus capacitance and braking data. Recheck mounting, fusing, wiring, motor duty, bus grouping and the saved drive project.
Why can DKC03.3-100-7-FW appear online while the PLC receives the wrong process words?
The physical bus can be healthy while the configured module, I/O lengths, word order or command/status allocation is wrong. Compare the approved PLC project and firmware function with the installed drive.
What should be checked when downstream PROFIBUS nodes disappear after replacing DKC03.3-100-7-FW?
Confirm whether the drive is an end station, both connector directions, switchable termination, cable continuity, shield bonding, address uniqueness and that no unterminated spur was introduced.
Can the PROFIBUS address of DKC03.3-100-7-FW be changed without updating the PLC project?
No. The address configured for the drive must match the PLC hardware configuration and must remain unique on the segment. Apply the change using the documented procedure, restart communication when required and verify that the master reconnects to the intended drive.
Why can PROFIBUS communication with DKC03.3-100-7-FW become unstable only when the motor is enabled?
Motor-output interference may be coupling into the bus cable. Check PROFIBUS shielding and connector grounding, protective-earth bonding, cable separation from motor conductors, termination, routing and cabinet equipotential bonding.
What should DKC03.3-100-7-FW do if PROFIBUS communication is lost during operation?
It must follow the approved communication-loss response defined by the PLC and drive configuration. Under a controlled test, verify the resulting torque or stop behavior, fault indication, PLC alarm, recovery sequence and prevention of an unexpected automatic restart.
